直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
OD8025-12HBIP68FAN AXIAL 80X25MM 12VDC WIRE |
649 | - |
|
数据表 |
OD8025 | Box | Active | 12VDC | Square - 80mm L x 80mm H | 40.0 CFM (1.12m³/min) | 0.230 in H2O (57.3 Pa) | Ball | 0.191 lb (86.64 g) | Tubeaxial | Auto Restart | 25.00mm | 33.0dB | 2.2 W | cURus, TUV | 3300 RPM | 5 ~ 149°F (-15 ~ 65°C) | 2 Wire Leads | IP68 - Dust Tight, Waterproof |
|
OD8025-24HBIP68FAN AXIAL 80X25MM 24VDC WIRE |
190 | - |
|
数据表 |
OD8025 | Box | Active | 24VDC | Square - 80mm L x 80mm H | 40.0 CFM (1.12m³/min) | 0.230 in H2O (57.3 Pa) | Ball | 0.191 lb (86.64 g) | Tubeaxial | Auto Restart | 25.00mm | 33.0dB | 2.9 W | cURus, TUV | 3300 RPM | 5 ~ 149°F (-15 ~ 65°C) | 2 Wire Leads | IP68 - Dust Tight, Waterproof |
|
AFB0612EH-ABFAN AXIAL 60X25.4MM 12VDC WIRE |
2,437 | - |
|
数据表 |
AFB | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 38.4 CFM (1.08m³/min) | 0.544 in H2O (135.5 Pa) | Ball | 0.176 lb (80.00 g) | Tubeaxial | Locked Rotor Protection | 25.40mm | 46.5dB(A) | 4.56 W | CE, CSA, UL, VDE | 6800 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
QFR0812UH-CX14FAN AXIAL 80X25.4MM 12VDC WIRE |
2,066 | - |
|
数据表 |
QFR | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 70.2 CFM (1.97m³/min) | 0.551 in H2O (137.2 Pa) | Ball | 0.195 lb (88.45 g) | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 25.40mm | 50.5dB(A) | 6.6 W | CE, cURus, VDE | 5600 RPM | 14 ~ 140°F (-10 ~ 60°C) | 4 Wire Leads | - |
|
9GA0405P6F001FAN AXIAL 40X20MM BALL 5VDC WIRE |
727 | - |
|
数据表 |
San Ace 40 | Box | Active | 5VDC | Square - 40mm L x 40mm H | 7.4 CFM (0.207m³/min) | 0.319 in H2O (79.5 Pa) | Ball | 0.077 lb (34.93 g) | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 20.00mm | 28.0dB(A) | 900 mW | CSA, TUV, UL | 8000 RPM | -4 ~ 158°F (-20 ~ 70°C) | 4 Wire Leads | - |
|
AFB0624EH-AFAN AXIAL 60X25.4MM 24VDC WIRE |
2,534 | - |
|
数据表 |
AFB | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 38.4 CFM (1.08m³/min) | 0.544 in H2O (135.5 Pa) | Ball | 0.176 lb (80.00 g) | Tubeaxial | Locked Rotor Protection | 25.40mm | 46.5dB(A) | 5.76 W | CE, CSA, UL, VDE | 6800 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
17000183AFAN AXIAL 12VDC CR0812MB-Y51(N) |
0 | - |
|
数据表 |
- | Bulk | Obsolete | 12VDC | Square - 80mm L x 80mm H | 44.8 CFM (1.25m³/min) | 0.240 in H2O (59.8 Pa) | Ball | 0.238 lb (107.95 g) | Tubeaxial | Auto Restart, Locked Rotor Protection | 32.00mm | 36.7dB(A) | 1.92 W | CE, cUL, TUV, UL | 3400 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
17000185AFAN 80X32MM CR0824UB-Y51(NCU) |
0 | - |
|
数据表 |
- | Bulk | Obsolete | 24VDC | Square - 80mm L x 80mm H | 52.4 CFM (1.47m³/min) | 0.320 in H2O (79.7 Pa) | Ball | 0.24 lb (108.86 g) | Tubeaxial | Auto Restart, Locked Rotor Protection | 32.00mm | 44.0dB(A) | 3.6 W | CE, cUL, TUV, UL | 4200 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
OD2510-05LLBFAN AXIAL 25X10MM BALL 5VDC WIRE |
0 | - |
|
数据表 |
OD2510 | Bulk | Active | 5VDC | Square - 25mm L x 25mm H | - | - | Ball | 0.022 lb (9.98 g) | Tubeaxial | Auto Restart | 10.00mm | - | - | cURus, TUV | - | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
CBM-979433B-235-540-20FAN BLOWER 97.68X32.7MM 24VDC |
0 | - |
|
数据表 |
CBM-97B-2 | Box | Active | 24VDC | Rectangular/Rounded - 97.68mm L x 94.18mm H | 23.9 CFM (0.669m³/min) | 0.900 in H2O (224.2 Pa) | Ball | - | Blower | Auto Restart, Speed Sensor (Tach) | 32.70mm | 54.1dB(A) | 12.24 W | CE, cURus, TUV | 3500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
DC0351012W2B-2T2FAN 35X10MM 12VDC MOLEX 22-01-10 |
0 | - |
|
数据表 |
- | Bulk | Active | 12VDC | Square - 35mm L x 35mm H | 6.3 CFM (0.176m³/min) | 0.220 in H2O (54.8 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection | 10.00mm | 28.0dB(A) | 840 mW | CE, cURus, TUV | 9000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Position Rectangular Connector | - |
|
|
PMD2406PKV1-A.GNFAN AXIAL 60X20MM 24VDC WIRE |
0 | - |
|
数据表 |
MagLev® PMD | Bulk | Obsolete | 24VDC | Square - 60mm L x 60mm H | 27.5 CFM (0.770m³/min) | 0.280 in H2O (69.7 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart | 20.00mm | 38.0dB(A) | 3 W | - | 5000 RPM | - | 2 Wire Leads | - |
|
|
PMD2406PKVX-A.GNFAN AXIAL 60X20MM 24VDC WIRE |
0 | - |
|
数据表 |
MagLev® PMD | Bulk | Obsolete | 24VDC | Square - 60mm L x 60mm H | 30.5 CFM (0.854m³/min) | 0.350 in H2O (87.2 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart | 20.00mm | 40.0dB(A) | 3.8 W | - | 5500 RPM | - | 2 Wire Leads | - |
|
|
109P0412S7D01FAN AXIAL 40X15MM 12VDC WIRE |
0 | - |
|
数据表 |
San Ace 40 | Box | Active | 12VDC | Square - 40mm L x 40mm H | 7.1 CFM (0.199m³/min) | 0.369 in H2O (91.9 Pa) | Ball | 0.071 lb (32.21 g) | Tubeaxial | Locked Rotor Sensor | 15.00mm | 32.0dB(A) | 2.16 W | CSA, TUV, UL | 8600 RPM | -4 ~ 158°F (-20 ~ 70°C) | 3 Wire Leads | - |
|
|
109P0412R702FAN AXIAL 40X15MM 12VDC WIRE |
0 | - |
|
数据表 |
San Ace 40 | Box | Active | 12VDC | Square - 40mm L x 40mm H | 8.0 CFM (0.224m³/min) | 0.449 in H2O (111.8 Pa) | Ball | 0.071 lb (32.21 g) | Tubeaxial | Locked Rotor Protection | 15.00mm | 34.0dB(A) | 1.56 W | CSA, TUV, UL | 9700 RPM | -4 ~ 158°F (-20 ~ 70°C) | 2 Wire Leads | - |
|
|
06023GA-12M-AA-00FAN BLOWER BALL 12VDC WIRE |
0 | - |
|
数据表 |
06023GA | Box | Active | 12VDC | - | 7.8 CFM (0.218m³/min) | - | Ball | 0.132 lb (59.87 g) | Blower | - | - | 37.0dB | 2.76 W | - | 4500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
06920GA-12N-AA-00FAN BLOWER 70.6X20MM 12VDC WIRE |
0 | - |
|
数据表 |
06920GA | Bulk | Active | 12VDC | Square/Rounded - 70.6mm L x 68.5mm H | 7.1 CFM (0.199m³/min) | 0.600 in H2O (149.5 Pa) | Ball | - | Blower | Auto Restart | 20.00mm | 33.0dB | 3 W | - | 4100 RPM | - | 2 Wire Leads | - |
|
|
06023GA-12N-AA-00FAN BLOWER BALL 12VDC WIRE |
0 | - |
|
数据表 |
06023GA | Box | Active | 12VDC | - | 8.5 CFM (0.238m³/min) | - | Ball | 0.132 lb (59.87 g) | Blower | - | - | 41.0dB | 3.12 W | - | 5000 RPM | 14 ~ 140°F (-10 ~ 60°C) | 2 Wire Leads | - |
|
|
06023GA-24N-AA-00FAN BLOWER 60.6X23MM 24VDC WIRE |
0 | - |
|
数据表 |
06023GA | Bulk | Active | 24VDC | Square/Rounded - 60.6mm L x 59.9mm H | - | - | Ball | - | Blower | Auto Restart | 23.00mm | - | - | - | - | 14 ~ 140°F (-10 ~ 60°C) | 2 Wire Leads | - |
|
CFM-8025BG-150-444-20FAN AXIAL 80X25.4MM 12VDC WIRE |
0 | - |
|
数据表 |
CFM-80BG | Box | Active | 12VDC | Square - 80mm L x 80mm H | 51.7 CFM (1.45m³/min) | 0.430 in H2O (107.1 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 25.40mm | 44.5dB(A) | 4.2 W | CE, cURus, TUV | 5000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
