直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
OD2506-05LLBFAN AXIAL 25X6MM BALL 5VDC WIRE |
0 | - |
|
数据表 |
OD2506 | Bulk | Obsolete | 5VDC | Square - 25mm L x 25mm H | 1.2 CFM (0.034m³/min) | 0.050 in H2O (12.4 Pa) | Ball | - | Tubeaxial | - | 6.00mm | 13.0dB(A) | - | cURus | 7000 RPM | -4 ~ 158°F (-20 ~ 70°C) | 2 Wire Leads | - |
|
612FFAN AXIAL 60X15MM 12VDC WIRE |
1,782 | - |
|
数据表 |
600F | Box | Active | 12VDC | Square - 60mm L x 60mm H | 17.1 CFM (0.479m³/min) | - | Sintec | 0.066 lb (29.94 g) | Tubeaxial | - | 15.00mm | 27.0dB(A) | 1 W | CE, CSA, UL, VDE | 3900 RPM | -4 ~ 158°F (-20 ~ 70°C) | 2 Wire Leads | - |
|
|
OD2506-05MSS01AFAN AXIAL 25X6MM 5VDC WIRE |
0 | - |
|
数据表 |
OD2506 | Bulk | Active | 5VDC | Square - 25mm L x 25mm H | 2.1 CFM (0.059m³/min) | 0.160 in H2O (39.8 Pa) | Sealed Sleeve | - | Tubeaxial | Speed Sensor (Tach) | 6.00mm | 28.0dB | - | cURus | 12000 RPM | -4 ~ 158°F (-20 ~ 70°C) | 3 Wire Leads | - |
|
OD2510-05HSS01AFAN AXIAL 25X10MM 5VDC WIRE |
0 | - |
|
数据表 |
OD2510 | Bulk | Active | 5VDC | Square - 25mm L x 25mm H | - | - | Sealed Sleeve | 0.022 lb (9.98 g) | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 10.00mm | 31.0dB | - | - | - | - | 3 Wire Leads | - |
|
|
OD2510-05LSS01AFAN AXIAL 25X10MM 5VDC WIRE |
0 | - |
|
数据表 |
OD2510 | Bulk | Active | 5VDC | Square - 25mm L x 25mm H | - | - | Sealed Sleeve | 0.022 lb (9.98 g) | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 10.00mm | - | - | - | - | - | 3 Wire Leads | - |
|
|
OD2510-05MSS01AFAN AXIAL 25X10MM 5VDC WIRE |
0 | - |
|
数据表 |
OD2510 | Bulk | Active | 5VDC | Square - 25mm L x 25mm H | - | - | Sealed Sleeve | 0.022 lb (9.98 g) | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 10.00mm | 24.0dB | - | - | - | - | 3 Wire Leads | - |
|
OD9220-12HB01AFAN AXIAL 92X20MM 12VDC WIRE |
0 | - |
|
数据表 |
OD9220 | Bulk | Active | 12VDC | Square - 92mm L x 92mm H | 32.0 CFM (0.896m³/min) | 0.130 in H2O (32.4 Pa) | Ball | - | Tubeaxial | Speed Sensor (Tach) | 20.00mm | 33.0dB | - | cURus, TUV | 2700 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
OD9220-24HB01AFAN AXIAL 92X20MM 24VDC WIRE |
0 | - |
|
数据表 |
OD9220 | Bulk | Active | 24VDC | Square - 92mm L x 92mm H | 32.0 CFM (0.896m³/min) | 0.125 in H2O (31.1 Pa) | Ball | - | Tubeaxial | Speed Sensor (Tach) | 20.00mm | 33.0dB | - | cURus, TUV | 2700 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
DC0402012L2B-2T0FAN AXIAL 40X20MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 40mm L x 40mm H | 9.4 CFM (0.263m³/min) | 0.350 in H2O (87.2 Pa) | Ball | 0.045 lb (20.41 g) | Tubeaxial | Locked Rotor Protection | 20.00mm | 33.0dB(A) | 960 mW | CE, cURus, TUV | 8000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
DC0382012H2B-2T0FAN AXIAL 38X20MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 38mm L x 38mm H | 8.6 CFM (0.241m³/min) | 0.390 in H2O (97.1 Pa) | Ball | 0.067 lb (30.39 g) | Tubeaxial | Locked Rotor Protection | 20.00mm | 42.0dB(A) | 1.56 W | CE, cURus, TUV | 8900 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
DC0382012L2B-2T0FAN AXIAL 38X20MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 38mm L x 38mm H | 6.3 CFM (0.176m³/min) | 0.220 in H2O (54.8 Pa) | Ball | 0.067 lb (30.39 g) | Tubeaxial | Locked Rotor Protection | 20.00mm | 36.0dB(A) | 1.2 W | CE, cURus, TUV | 6700 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
DC0802512H2B-2T0FAN AXIAL 80X25.4MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 80mm L x 80mm H | 74.3 CFM (2.08m³/min) | 0.270 in H2O (67.3 Pa) | Ball | 0.188 lb (85.28 g) | Tubeaxial | Locked Rotor Protection | 25.40mm | 46.0dB(A) | 9.72 W | CE, cURus, TUV | 5500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
DC0402012U2B-2T0FAN AXIAL 40X20MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 40mm L x 40mm H | 16.8 CFM (0.470m³/min) | 1.080 in H2O (269.0 Pa) | Ball | 0.045 lb (20.41 g) | Tubeaxial | Locked Rotor Protection | 20.00mm | 49.0dB(A) | 3 W | CE, cURus, TUV | 14000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
DC0402012H2B-2T0FAN AXIAL 40X20MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 40mm L x 40mm H | 14.3 CFM (0.400m³/min) | 0.790 in H2O (196.8 Pa) | Ball | 0.045 lb (20.41 g) | Tubeaxial | Locked Rotor Protection | 20.00mm | 44.0dB(A) | 2.04 W | CE, cURus, TUV | 12000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
DC0251005H2B-3T0FAN 25X10MM 5VDC TACH |
0 | - |
|
数据表 |
- | Bulk | Active | 5VDC | Square - 25mm L x 25mm H | 2.4 CFM (0.067m³/min) | 0.290 in H2O (72.2 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 10.00mm | 28.0dB(A) | 400 mW | CE, cURus | 13000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
514FFAN AXIAL 50X15MM 24VDC WIRE |
810 | - |
|
数据表 |
500F | Box | Active | 24VDC | Square - 50mm L x 50mm H | 11.8 CFM (0.330m³/min) | - | Sintec | 0.055 lb (24.95 g) | Tubeaxial | - | 15.00mm | 30.0dB(A) | 1 W | CE, CSA, UL, VDE | 5000 RPM | -4 ~ 158°F (-20 ~ 70°C) | 2 Wire Leads | - |
|
BFB0512LA-CF00FAN BLOWER 50X10.3MM 12VDC WIRE |
0 | - |
|
数据表 |
BFB | Box | Active | 12VDC | Square - 50mm L x 50mm H | 2.2 CFM (0.061m³/min) | 0.208 in H2O (51.8 Pa) | Ball | 0.05 lb (22.68 g) | Blower | Locked Rotor Protection, Speed Sensor (Tach) | 10.30mm | 22.5dB(A) | 600 mW | CE, CSA, UL, VDE | 3500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
OD4028-12HBXEFAN AXIAL 40X28MM 12VDC WIRE |
183 | - |
|
数据表 |
OD4028 | Box | Active | 12VDC | Square - 40mm L x 40mm H | 31.5 CFM (0.882m³/min) | 3.000 in H2O (747.3 Pa) | Ball | - | Tubeaxial | Auto Restart | 28.00mm | 64.2dB(A) | 16.8 W | CE, cURus, TUV, UR | 22750 RPM | -4 ~ 149°F (-20 ~ 65°C) | 2 Wire Leads | - |
|
BFB0512HA-CF00FAN BLOWER 50X10.3MM 12VDC WIRE |
0 | - |
|
数据表 |
BFB | Box | Active | 12VDC | Square - 50mm L x 50mm H | 3.5 CFM (0.098m³/min) | 0.563 in H2O (140.2 Pa) | Ball | 0.05 lb (22.68 g) | Blower | Locked Rotor Protection, Speed Sensor (Tach) | 10.30mm | 32.5dB(A) | 1.44 W | CE, CSA, UL, VDE | 5100 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
TFA0412CN-CNFAN AXIAL 40X28MM 12VDC WIRE |
1,288 | - |
|
数据表 |
TFA | Box | Active | 12VDC | Square - 40mm L x 40mm H | 25.3 CFM (0.708m³/min) | 1.868 in H2O (465.3 Pa) | Ball | 0.098 lb (44.45 g) | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 28.00mm | 55.0dB(A) | 7.2 W | CE, cURus, TUV | 17600 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | IP51 - Dust Protected |
