单个二极管
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 技术 | 电压 - 直流反向 (Vr)（最大值） | 电压 - 正向 (Vf)（最大值）@ If | 速度 | 反向恢复时间 (trr) | 电流 - 反向漏电 @ Vr | 电容 @ Vr, F | 电流 - 平均整流（Io） | 等级 | 认证 | 安装类型 | 供应商设备封装 | 工作温度 - 结点 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DSEI30-10ARDIODE GP 1KV 30A ISOPLUS247 IXYS |
4,177 | - |
|
数据表 |
- | ISOPLUS247™ | Tube | Active | Standard | 1000 V | 2.4 V @ 36 A | Fast Recovery =< 500ns, > 200mA (Io) | 50 ns | 750 µA @ 1000 V | - | 30A | - | - | Through Hole | ISOPLUS247™ (BR) | -40°C ~ 150°C |
|
DSEP60-12AZ-TUBDIODE GEN PURP 1.2KV 60A TO268AA IXYS |
15 | - |
|
数据表 |
- | TO-268-3, D3PAK (2 Leads + Tab), TO-268AA | Tube | Active | Standard | 1200 V | 2.66 V @ 60 A | Fast Recovery =< 500ns, > 200mA (Io) | 80 ns | 650 µA @ 1200 V | 30pF @ 600V, 1MHz | 60A | - | - | Surface Mount | TO-268AA (D3Pak-HV) | -55°C ~ 175°C |
|
DSA75-16BDIODE AVAL 1.6KV 110A DO203AB IXYS |
8,357 | - |
|
数据表 |
- | DO-203AB, DO-5, Stud | Bulk | Obsolete | Avalanche | 1600 V | 1.17 V @ 150 A | Standard Recovery >500ns, > 200mA (Io) | - | 6 mA @ 1600 V | - | 110A | - | - | Chassis, Stud Mount | DO-203AB | -40°C ~ 180°C |
|
DSAI75-16BDIODE AVAL 1.6KV 110A DO203AB IXYS |
6,750 | - |
|
数据表 |
- | DO-203AB, DO-5, Stud | Bulk | Obsolete | Avalanche | 1600 V | 1.17 V @ 150 A | Standard Recovery >500ns, > 200mA (Io) | - | 6 mA @ 1600 V | - | 110A | - | - | Chassis, Stud Mount | DO-203AB | -40°C ~ 180°C |
|
DSA75-18BDIODE AVAL 1.8KV 110A DO203AB IXYS |
9,288 | - |
|
数据表 |
- | DO-203AB, DO-5, Stud | Box | Obsolete | Avalanche | 1800 V | 1.17 V @ 150 A | Standard Recovery >500ns, > 200mA (Io) | - | 6 mA @ 1800 V | - | 110A | - | - | Chassis, Stud Mount | DO-203AB | -40°C ~ 180°C |
|
DSAI75-18BDIODE AVAL 1.8KV 110A DO203AB IXYS |
4,857 | - |
|
数据表 |
- | DO-203AB, DO-5, Stud | Box | Obsolete | Avalanche | 1800 V | 1.17 V @ 150 A | Standard Recovery >500ns, > 200mA (Io) | - | 6 mA @ 1800 V | - | 110A | - | - | Chassis, Stud Mount | DO-203AB | -40°C ~ 180°C |
|
DSS60-0045BDIODE SCHOTTKY 45V 60A TO247AD IXYS |
9,440 | - |
|
数据表 |
- | TO-247-2 | Tube | Active | Schottky | 45 V | 600 mV @ 60 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 10 mA @ 45 V | - | 60A | - | - | Through Hole | TO-247AD | -55°C ~ 150°C |
|
|
LSIC2SD065D40CC650 V SiC Schottky Barrier Diode IXYS |
5,005 | - |
|
数据表 |
* | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
DSEI8-06ADIODE GEN PURP 600V 8A TO220AC IXYS |
6,543 | - |
|
数据表 |
FRED | TO-220-2 | Tube | Active | Standard | 600 V | 1.5 V @ 8 A | Fast Recovery =< 500ns, > 200mA (Io) | 50 ns | 20 µA @ 600 V | - | 8A | - | - | Through Hole | TO-220AC | -40°C ~ 150°C |
|
|
DSEI12-12ADIODE GEN PURP 1.2KV 11A TO220AC IXYS |
3,847 | - |
|
数据表 |
- | TO-220-2 | Tube | Active | Standard | 1200 V | 2.6 V @ 12 A | Fast Recovery =< 500ns, > 200mA (Io) | 70 ns | 250 µA @ 1200 V | - | 11A | - | - | Through Hole | TO-220AC | -40°C ~ 150°C |
