固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRR6040A-820MFIXED IND 82UH 700MA 290MOHM SMD Bourns Inc. |
4,000 | - |
|
数据表 |
SRR6040A | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | - | Ferrite | ±20% | 700 mA | 630mA | - | Shielded | 290mOhm Max | 82 µH | - | - | Surface Mount | AEC-Q200 | 0.264" L x 0.264" W (6.70mm x 6.70mm) | - | -40°C ~ 125°C | 10 kHz | 0.157" (4.00mm) |
|
SRU1028A-680YFIXED IND 68UH 1A 300 MOHM SMD Bourns Inc. |
3,985 | - |
|
数据表 |
SRU1028A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 1 A | 900mA | - | Shielded | 300mOhm Max | 68 µH | 20 @ 2.52MHz | 9MHz | Surface Mount | AEC-Q200 | 0.394" L x 0.394" W (10.00mm x 10.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.122" (3.10mm) |
|
|
SRU1028A-220YFIXED IND 22UH 1.6A 135 MOHM SMD Bourns Inc. |
3,813 | - |
|
数据表 |
SRU1028A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 1.6 A | 1.4A | - | Shielded | 135mOhm Max | 22 µH | 26 @ 2.52MHz | 16MHz | Surface Mount | AEC-Q200 | 0.394" L x 0.394" W (10.00mm x 10.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.122" (3.10mm) |
|
|
SRR6040A-120MFIXED IND 12UH 1.7A 55 MOHM SMD Bourns Inc. |
3,505 | - |
|
数据表 |
SRR6040A | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | - | Ferrite | ±20% | 1.7 A | 1.61A | - | Shielded | 55mOhm Max | 12 µH | - | - | Surface Mount | AEC-Q200 | 0.264" L x 0.264" W (6.70mm x 6.70mm) | - | -40°C ~ 125°C | 10 kHz | 0.157" (4.00mm) |
|
SRU1038A-151YFIXED IND 150UH 900MA 476MOHM SM Bourns Inc. |
3,200 | - |
|
数据表 |
SRU1038A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 900 mA | 800mA | - | Shielded | 476mOhm Max | 150 µH | 20 @ 796kHz | 5MHz | Surface Mount | AEC-Q200 | 0.394" L x 0.394" W (10.00mm x 10.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.161" (4.10mm) |
|
|
SRR6040A-680MFIXED IND 68UH 750MA 240MOHM SMD Bourns Inc. |
2,118 | - |
|
数据表 |
SRR6040A | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | - | Ferrite | ±20% | 750 mA | 700mA | - | Shielded | 240mOhm Max | 68 µH | - | - | Surface Mount | AEC-Q200 | 0.264" L x 0.264" W (6.70mm x 6.70mm) | - | -40°C ~ 125°C | 10 kHz | 0.157" (4.00mm) |
|
|
SRR6040A-101MFIXED IND 100UH 650MA 345MOHM SM Bourns Inc. |
1,819 | - |
|
数据表 |
SRR6040A | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | - | Ferrite | ±20% | 650 mA | 570mA | - | Shielded | 345mOhm Max | 100 µH | - | - | Surface Mount | AEC-Q200 | 0.264" L x 0.264" W (6.70mm x 6.70mm) | - | -40°C ~ 125°C | 10 kHz | 0.157" (4.00mm) |
|
|
SRU1038A-221YFIXED IND 220UH 650MA 740MOHM SM Bourns Inc. |
1,770 | - |
|
数据表 |
SRU1038A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 650 mA | 650mA | - | Shielded | 740mOhm Max | 220 µH | 22 @ 796kHz | 4MHz | Surface Mount | AEC-Q200 | 0.394" L x 0.394" W (10.00mm x 10.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.161" (4.10mm) |
|
SRR1208-821KLFIXED IND 820UH 550MA 1.15OHM SM Bourns Inc. |
109 | - |
|
数据表 |
SRR1208 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 550 mA | 770mA | - | Shielded | 1.15Ohm Max | 820 µH | 12 @ 796kHz | 1.2MHz | Surface Mount | - | 0.500" L x 0.500" W (12.70mm x 12.70mm) | - | -40°C ~ 125°C | 1 kHz | 0.335" (8.50mm) |
|
|
SRU1028A-150YFIXED IND 15UH 2A 90 MOHM SMD Bourns Inc. |
595 | - |
|
数据表 |
SRU1028A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 2 A | 2A | - | Shielded | 90mOhm Max | 15 µH | 26 @ 2.52MHz | 22MHz | Surface Mount | AEC-Q200 | 0.394" L x 0.394" W (10.00mm x 10.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.122" (3.10mm) |
