直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
05115GS-24N-AAD-0DC BLOWER |
0 | - |
|
数据表 |
- | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
CFM-8038S-140-449-20FAN AXIAL 80X37.6MM 12VDC WIRE |
0 | - |
|
数据表 |
CFM-80S | Box | Active | 12VDC | Square - 80mm L x 80mm H | 49.4 CFM (1.38m³/min) | 0.370 in H2O (92.2 Pa) | Sleeve | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 37.60mm | 45.0dB(A) | 4.56 W | CE, cURus, TUV | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
CFM-8038S-230-387-20FAN AXIAL 80X37.6MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-80S | Box | Active | 24VDC | Square - 80mm L x 80mm H | 37.1 CFM (1.04m³/min) | 0.210 in H2O (52.3 Pa) | Sleeve | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 37.60mm | 38.7dB(A) | 3.6 W | CE, cURus, TUV | 3000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
OD6010-05MBFAN AXIAL 60X10MM BALL 5VDC WIRE |
0 | - |
|
数据表 |
OD6010 | Bulk | Active | 5VDC | Square - 60mm L x 60mm H | - | - | Ball | - | Tubeaxial | - | 10.00mm | - | - | cURus, TUV | - | - | 2 Wire Leads | - |
|
|
CFM-A225BG-115-281-20DC AXIAL FAN, 120 MM SQUARE, 25 |
0 | - |
|
数据表 |
CFM-A2BG | Box | Active | 12VDC | Square - 120mm L x 120mm H | 51.8 CFM (1.45m³/min) | 0.080 in H2O (19.9 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 25.00mm | 26.7dB(A) | 1.44 W | CE, cURus, TUV | 1500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
06015VA-12L-AL-00FAN AXIAL 60X15MM 12VDC WIRE |
0 | - |
|
数据表 |
06015VA | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 14.5 CFM (0.406m³/min) | 0.160 in H2O (39.8 Pa) | Ball | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 15.00mm | 28.5dB | 1 W | - | 4100 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
06015VA-12K-AT-00DC AXIAL FAN |
0 | - |
|
数据表 |
- | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
MF60151V3-B00U-A99FAN BLOWER 60X15MM 12VDC WIRE |
0 | - |
|
数据表 |
MagLev® MF | Bulk | Obsolete | 12VDC | Square - 60mm L x 60mm H | 3.9 CFM (0.109m³/min) | 0.190 in H2O (47.3 Pa) | Vapo-Bearing™ | 0.081 lb (36.74 g) | Blower | Auto Restart | 15.00mm | 28.8dB(A) | 480 mW | cURus, TUV | 3400 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
MR3010L05D-RSRFAN AXIAL 30X10MM 5VDC WIRE |
0 | - |
|
数据表 |
MR3010 | Box | Active | 5VDC | Square - 30mm L x 30mm H | 4.1 CFM (0.115m³/min) | 0.110 in H2O (27.4 Pa) | Sleeve | 0.018 lb (8.16 g) | Tubeaxial | Auto Restart | 10.00mm | 20.5dB(A) | - | CE, cUL, TUV, UL | 6000 RPM | - | 2 Wire Leads | - |
|
|
MF35060V1-1000U-F995VDC FAN 35X6MM TACH |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 35mm L x 35mm H | 5.5 CFM (0.154m³/min) | 0.110 in H2O (27.4 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 6.00mm | 26.0dB(A) | 0.6 W | CCC, CE, cURus, TUV, UKCA | 7600 RPM | - | 3 Wire Leads | - |
|
|
MF35060V2-1000U-S995VDC FAN 35X6MM TACH/PWM |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 35mm L x 35mm H | 4.3 CFM (0.120m³/min) | 0.070 in H2O (17.4 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 6.00mm | 18.3dB(A) | 0.33 W | CCC, CE, cURus, TUV, UKCA | 5800 RPM | - | 4 Wire Leads | - |
|
|
MF35060V1-1000U-S995VDC FAN 35X6MM TACH/PWM |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 35mm L x 35mm H | 5.5 CFM (0.154m³/min) | 0.110 in H2O (27.4 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 6.00mm | 26.0dB(A) | 0.6 W | CCC, CE, cURus, TUV, UKCA | 7600 RPM | - | 4 Wire Leads | - |
|
|
MF35060V2-1000U-F995VDC FAN 35X6MM TACH |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 35mm L x 35mm H | 4.3 CFM (0.120m³/min) | 0.070 in H2O (17.4 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 6.00mm | 18.3dB(A) | 0.33 W | CCC, CE, cURus, TUV, UKCA | 5800 RPM | - | 3 Wire Leads | - |
|
CFM-9238S-140-473-20FAN AXIAL 92X37.5MM 12VDC WIRE |
0 | - |
|
数据表 |
CFM-92S | Box | Active | 12VDC | Square - 92mm L x 92mm H | 76.9 CFM (2.15m³/min) | 0.440 in H2O (109.6 Pa) | Sleeve | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 37.50mm | 47.3dB(A) | 6.48 W | CE, cURus, TUV | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
CFM-9232S-240-461-20FAN AXIAL 92.2X32MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-92S | Box | Active | 24VDC | Square - 92.2mm L x 92.2mm H | 82.2 CFM (2.30m³/min) | 0.400 in H2O (99.6 Pa) | Sleeve | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 32.00mm | 46.2dB(A) | 9.36 W | CE, cURus, TUV | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
CFM-9232S-140-461-20FAN AXIAL 92.2X32MM 12VDC WIRE |
0 | - |
|
数据表 |
CFM-92S | Box | Active | 12VDC | Square - 92.2mm L x 92.2mm H | 82.2 CFM (2.30m³/min) | 0.400 in H2O (99.6 Pa) | Sleeve | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 32.00mm | 46.2dB(A) | 6.48 W | CE, cURus, TUV | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
CFM-9238S-240-473-20FAN AXIAL 92X37.5MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-92S | Box | Active | 24VDC | Square - 92mm L x 92mm H | 76.9 CFM (2.15m³/min) | 0.440 in H2O (109.6 Pa) | Sleeve | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 37.50mm | 47.3dB(A) | 9.6 W | CE, cURus, TUV | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
2004KL-05W-B30-B00DC AXIAL FAN |
0 | - |
|
数据表 |
2004KL | Box | Active | 24VDC | Square - 50mm L x 50mm H | 6.4 CFM (0.180m³/min) | 0.064 in H2O (16.0 Pa) | Ball | - | Tubeaxial | Auto Restart | 10.00mm | 23.0dB | 0.6 W | - | 3500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
2004KL-05W-B50-B00DC AXIAL FAN |
0 | - |
|
数据表 |
2004KL | Box | Active | 24VDC | Square - 50mm L x 50mm H | 10.2 CFM (0.286m³/min) | 0.141 in H2O (35.1 Pa) | Ball | - | Tubeaxial | Auto Restart | 10.00mm | 34.0dB | 1.2 W | - | 5500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
2004KL-05W-B40-B00DC AXIAL FAN |
0 | - |
|
数据表 |
2004KL | Box | Active | 24VDC | Square - 50mm L x 50mm H | 8.2 CFM (0.230m³/min) | 0.104 in H2O (26.0 Pa) | Ball | - | Tubeaxial | Auto Restart | 10.00mm | 28.5dB | 1.08 W | - | 4500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
