直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
OD5010-12MBFAN AXIAL 50X10.5MM 12VDC WIRE |
0 | - |
|
数据表 |
OD5010 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | - | - | Ball | - | Tubeaxial | - | 10.50mm | - | - | cURus | - | - | 2 Wire Leads | - |
|
OD8015-12LBFAN AXIAL 80X15MM 12VDC WIRE |
0 | - |
|
数据表 |
OD8015 | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | - | - | Ball | - | Tubeaxial | - | 15.00mm | - | - | cURus, TUV | - | - | 2 Wire Leads | - |
|
OD8025-12LLBFAN AXIAL 80X25MM 12VDC WIRE |
0 | - |
|
数据表 |
OD8025 | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 19.0 CFM (0.532m³/min) | 0.070 in H2O (17.4 Pa) | Ball | 0.191 lb (86.64 g) | Tubeaxial | Auto Restart | 25.00mm | 19.0dB | 490 mW | cURus, TUV | 1600 RPM | -4 ~ 167°F (-20 ~ 75°C) | 2 Wire Leads | - |
|
NP973427-001 REV ANP973427-001 REV A |
0 | - |
|
数据表 |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
CFM-8038B-140-449-20FAN AXIAL 80X37.6MM 12VDC WIRE |
0 | - |
|
数据表 |
CFM-80B | Box | Active | 12VDC | Square - 80mm L x 80mm H | 49.4 CFM (1.38m³/min) | 0.370 in H2O (92.2 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 37.60mm | 45.0dB(A) | 4.56 W | CE, cURus, TUV | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
CFM-8038B-240-449-20FAN AXIAL 80X37.6MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-80B | Box | Active | 24VDC | Square - 80mm L x 80mm H | 49.4 CFM (1.38m³/min) | 0.370 in H2O (92.2 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 37.60mm | 45.0dB(A) | 5.04 W | CE, cURus, TUV | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
G4020E24B-RS-CCFAN AXIAL 40X20MM 24VDC WIRE |
0 | - |
|
数据表 |
G4020 | Bulk | Obsolete | 24VDC | Square - 40mm L x 40mm H | 11.7 CFM (0.328m³/min) | 0.230 in H2O (57.3 Pa) | Ball | 0.062 lb (28.12 g) | Tubeaxial | Conformal Coating, Thermal Overload Protector (TOP) | 20.00mm | 32.0dB(A) | - | CE, cUL, TUV, UL | 8000 RPM | - | 2 Wire Leads | - |
|
2410ML-05W-B40-B00FAN AXIAL 60X25MM 24VDC WIRE |
0 | - |
|
数据表 |
2410ML | Bulk | Obsolete | 24VDC | Square - 60mm L x 60mm H | 21.5 CFM (0.602m³/min) | 0.208 in H2O (51.8 Pa) | Ball | 0.144 lb (65.32 g) | Tubeaxial | Auto Restart | 25.00mm | 33.5dB | 2.16 W | CE, CSA, UL, VDE | 4550 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
DC0401005M2B-BT0FAN 40X10MM 5VDC PWM/TACH |
0 | - |
|
数据表 |
- | Bulk | Active | 5VDC | Square - 40mm L x 40mm H | 4.8 CFM (0.134m³/min) | 0.060 in H2O (14.9 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 10.00mm | 21.0dB(A) | 250 mW | CE, cURus | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
DC0401005U2B-BT0FAN 40X10MM 5VDC PWM/TACH |
0 | - |
|
数据表 |
- | Bulk | Active | 5VDC | Square - 40mm L x 40mm H | 9.3 CFM (0.260m³/min) | 0.200 in H2O (49.8 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 10.00mm | 35.0dB(A) | 1 W | CE, cURus | 8000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
DC0401024U2B-BT0FAN 40X10MM 24VDC PWM/TACH |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Square - 40mm L x 40mm H | 9.3 CFM (0.260m³/min) | 0.200 in H2O (49.8 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 10.00mm | 35.0dB(A) | 1.44 W | CE, cURus | 8000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
DC0401024M2B-BT0FAN 40X10MM 24VDC PWM/TACH |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Square - 40mm L x 40mm H | 4.8 CFM (0.134m³/min) | 0.060 in H2O (14.9 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 10.00mm | 21.0dB(A) | 480 mW | CE, cURus | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
DC0401005H2B-BT0FAN 40X10MM 5VDC PWM/TACH |
0 | - |
|
数据表 |
- | Bulk | Active | 5VDC | Square - 40mm L x 40mm H | 7.2 CFM (0.202m³/min) | 0.110 in H2O (27.4 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 10.00mm | 26.0dB(A) | 550 mW | CE, cURus | 6000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
DC0401024H2B-BT0FAN 40X10MM 24VDC PWM/TACH |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Square - 40mm L x 40mm H | 7.2 CFM (0.202m³/min) | 0.110 in H2O (27.4 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 10.00mm | 26.0dB(A) | 720 mW | CE, cURus | 6000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
AFB03505LA-CF00FAN AXIAL 35X10MM BALL 5VDC WIRE |
0 | - |
|
数据表 |
AFB | Bulk | Active | 5VDC | Square - 35mm L x 35mm H | 3.4 CFM (0.095m³/min) | 0.048 in H2O (11.9 Pa) | Ball | 0.024 lb (10.89 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 10.00mm | 10.0dB(A) | 300 mW | - | 4500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
AFB03505HA-CF00FAN AXIAL 35X10MM BALL 5VDC WIRE |
0 | - |
|
数据表 |
AFB | Bulk | Active | 5VDC | Square - 35mm L x 35mm H | 5.5 CFM (0.154m³/min) | 0.106 in H2O (26.4 Pa) | Ball | 0.024 lb (10.89 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 10.00mm | 22.0dB(A) | 700 mW | - | 7000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
AFB03512MA-CR00AXIAL SQUARE-35MM L X 35MM H X10 |
0 | - |
|
数据表 |
AFB | Bulk | Active | 12VDC | Square - 35mm L x 35mm H | 4.3 CFM (0.120m³/min) | 0.076 in H2O (18.9 Pa) | Ball | - | Tubeaxial | Locked Rotor Sensor | 10.00mm | 17.0dB(A) | 0.6 W | cURus, TUV | 5800 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
AFB03512LA-CF00AXIAL SQUARE-35MM L X 35MM H X10 |
0 | - |
|
数据表 |
AFB | Bulk | Active | 12VDC | Square - 35mm L x 35mm H | 3.4 CFM (0.095m³/min) | 0.048 in H2O (11.9 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 10.00mm | 13.0dB(A) | 0.36 W | cURus, TUV | 4500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
AFB03512LA-CR00AXIAL SQUARE-35MM L X 35MM H X10 |
0 | - |
|
数据表 |
AFB | Bulk | Active | 12VDC | Square - 35mm L x 35mm H | 3.4 CFM (0.095m³/min) | 0.048 in H2O (11.9 Pa) | Ball | - | Tubeaxial | Locked Rotor Sensor | 10.00mm | 13.0dB(A) | 0.36 W | cURus, TUV | 4500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
DC0701512J2B-BT0FAN AXIAL 70X15MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 70mm L x 70mm H | 21.1 CFM (0.591m³/min) | 0.090 in H2O (22.4 Pa) | Ball | 0.32 lb (145.15 g) | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 15.00mm | 27.0dB(A) | 1.2 W | CE, cURus, TUV | 2800 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
