固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PFC3519QM-451K04E-00CHOKE COMMON MODE |
148 | - |
|
数据表 |
PFC | Radial, Horizontal, 8 Leads | Bulk | Active | Drum Core, Wirewound | Ferrite | ±10% | 3.7 A | - | - | Unshielded | - | 450 µH | - | - | Through Hole | - | 1.457" L x 1.181" W (37.00mm x 30.00mm) | Choke Coils for PFC (Pin Terminal Type) | -30°C ~ 120°C | 50 kHz | 0.827" (21.00mm) |
|
750316867FIXED IND 125UH 39.6 MOHM TH |
146 | - |
|
数据表 |
- | 11-DIP Module | Tray | Active | - | - | ±10% | - | 12A | - | Unshielded | 39.6mOhm Max | 125 µH | - | - | Through Hole | - | 1.400" L x 1.470" W (35.56mm x 37.34mm) | - | -40°C ~ 125°C | 10 kHz | 1.350" (34.29mm) |
|
IHLP8787MZER820M51FIXED IND 82UH 10.2A 34.2MOHM SM |
470 | - |
|
数据表 |
IHLP-8787MZ-51 | Nonstandard | Tape & Reel (TR) | Active | Molded | - | ±20% | 10.2 A | 9A | - | Shielded | 34.2mOhm Max | 82 µH | - | 2.07MHz | Surface Mount | - | 0.885" L x 0.866" W (22.48mm x 22.00mm) | - | -55°C ~ 155°C | 100 kHz | 0.512" (13.00mm) |
|
ER1641-472KRFIXED IND 4.7UH 380MA 550MOHM TH |
556 | - |
|
数据表 |
Military, MIL-PRF-39010/02, ER1641 | Axial | Tape & Reel (TR) | Active | - | Iron | ±10% | 380 mA | - | - | Unshielded | 550mOhm Max | 4.7 µH | 44 @ 7.9MHz | 70MHz | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - | -55°C ~ 105°C | 7.9 MHz | - |
.jpg)
|
LQP03TN75NJ02DFIXED IND 75NH 100MA 10 OHM SMD |
0 | - |
|
数据表 |
LQP03 | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Thick Film | Non-Magnetic | ±5% | 100 mA | - | 0201 (0603 Metric) | Unshielded | 10Ohm Max | 75 nH | 8 @ 300MHz | 1GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 300 MHz | 0.013" (0.33mm) |
|
|
ER1641-822KSFIXED IND 8.2UH 245MA 1.32OHM TH |
405 | - |
|
数据表 |
Military, MIL-PRF-39010/02, ER1641 | Axial | Tape & Reel (TR) | Active | - | Iron | ±10% | 245 mA | - | - | Unshielded | 1.32Ohm Max | 8.2 µH | 50 @ 7.9MHz | 50MHz | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - | -55°C ~ 105°C | 7.9 MHz | - |
|
|
LQP03TN91NJ02DFIXED IND 91NH 80MA 10 OHM SMD |
0 | - |
|
数据表 |
LQP03 | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Thick Film | Non-Magnetic | ±5% | 80 mA | - | 0201 (0603 Metric) | Unshielded | 10Ohm Max | 91 nH | 8 @ 300MHz | 900MHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 300 MHz | 0.013" (0.33mm) |
|
|
LQP03TNR11J02DFIXED IND 110NH 80MA 12 OHM SMD |
0 | - |
|
数据表 |
LQP03 | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Thick Film | Non-Magnetic | ±5% | 80 mA | - | 0201 (0603 Metric) | Unshielded | 12Ohm Max | 110 nH | 8 @ 300MHz | 800MHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 300 MHz | 0.013" (0.33mm) |
|
BSCQ0006030322NJHRINDUCTOR RF |
0 | - |
|
数据表 |
BSCQ | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±5% | - | 190mA | 0201 | Unshielded | 1.29Ohm Max | 22 nH | 12 @ 500MHz | 1.9GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
|
BSCQ0006030322NJ00INDUCTOR RF |
0 | - |
|
数据表 |
BSCQ | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±5% | 190 mA | - | 0201 | Unshielded | 1.29Ohm Max | 22 nH | 14 @ 500MHz | 1.9GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
|
BSCQ0006030322NHHRINDUCTOR RF |
0 | - |
|
数据表 |
BSCQ | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±3% | - | 190mA | 0201 | Unshielded | 1.29Ohm Max | 22 nH | 12 @ 500MHz | 1.9GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
SRR4028-100YFIXED IND 10UH 1.19A 110MOHM SMD |
16,324 | - |
|
数据表 |
SRR4028 | 1919 (4848 Metric) | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 1.19 A | 1A | - | Shielded | 110mOhm Max | 10 µH | 11.26 @ 2.52MHz | 34MHz | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | - | -40°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
|
ER1641-562KSFIXED IND 5.6UH 335MA 720MOHM TH |
291 | - |
|
数据表 |
Military, MIL-PRF-39010/02, ER1641 | Axial | Tape & Reel (TR) | Active | - | Iron | ±10% | 335 mA | - | - | Unshielded | 720mOhm Max | 5.6 µH | 44 @ 7.9MHz | 65MHz | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - | -55°C ~ 105°C | 7.9 MHz | - |
|
LQW03AW3N9C00DFIXED IND 3.9NH 650MA 70MOHM SMD |
14,379 | - |
|
数据表 |
LQW03 | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Wirewound | - | ±0.2nH | 650 mA | - | - | Unshielded | 70mOhm Max | 3.9 nH | 48 @ 900MHz | 11GHz | Surface Mount | - | 0.021" L x 0.016" W (0.53mm x 0.40mm) | - | -55°C ~ 125°C | 100 MHz | 0.018" (0.45mm) |
|
BSCH0006030368NJ00INDUCTOR RF |
0 | - |
|
数据表 |
BSCH | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±5% | 80 mA | - | 0201 | Unshielded | 2.66Ohm Max | 68 nH | 4 @ 100MHz | 1.1GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 100 MHz | 0.013" (0.33mm) |
|
M27/367-45FIXED IND 1MH 240MA 6.9 OHM SMD |
677 | - |
|
数据表 |
Military, MIL-PRF-27/367, MIL4922 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±15% | 240 mA | 240mA | - | Unshielded | 6.9Ohm Max | 1 mH | - | - | Surface Mount | - | 0.520" L x 0.250" W (13.21mm x 6.35mm) | - | -55°C ~ 130°C | 1 kHz | 0.230" (5.84mm) |
|
DR74-102-RFIXED IND 1MH 270MA 3.89 OHM SMD |
12,653 | - |
|
数据表 |
DR | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 270 mA | 310mA | - | Shielded | 3.89Ohm | 1 mH | - | - | Surface Mount | - | 0.299" L x 0.299" W (7.60mm x 7.60mm) | - | -40°C ~ 125°C | 100 kHz | 0.171" (4.35mm) |
|
|
BSCH0006030382NJ00INDUCTOR RF |
0 | - |
|
数据表 |
BSCH | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±5% | 70 mA | - | 0201 | Unshielded | 3.37Ohm Max | 82 nH | 4 @ 100MHz | 1GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 100 MHz | 0.013" (0.33mm) |
|
L0603100GGSTRFIXED IND 10NH 300MA 450MOHM SMD |
10,666 | - |
|
数据表 |
Accu-L® | 0603 (1608 Metric) | Tape & Reel (TR) | Active | Thin Film | Non-Magnetic | ±2% | 300 mA | - | 0603 (1608 Metric) | Unshielded | 450mOhm Max | 10 nH | 28 @ 450MHz | 3.5GHz | Surface Mount | - | 0.063" L x 0.032" W (1.60mm x 0.81mm) | - | -55°C ~ 125°C | 450 MHz | 0.028" (0.71mm) |
|
|
ER1641-912JSFIXED IND 9.1UH 220MA 1.62OHM TH |
498 | - |
|
数据表 |
Military, MIL-PRF-39010/02, ER1641 | Axial | Tape & Reel (TR) | Active | - | Iron | ±5% | 220 mA | - | - | Unshielded | 1.62Ohm Max | 9.1 µH | 50 @ 7.9MHz | 46MHz | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - | -55°C ~ 105°C | 7.9 MHz | - |
