固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRU5028A-100YFIXED IND 10UH 1.8A 85 MOHM SMD Bourns Inc. |
1,736 | - |
|
数据表 |
SRU5028A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 1.8 A | 1.4A | - | Shielded | 85mOhm Max | 10 µH | 18 @ 2.52MHz | 25MHz | Surface Mount | AEC-Q200 | 0.205" L x 0.205" W (5.20mm x 5.20mm) | - | -40°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
CE201210-68NJFIXED IND 68NH 300MA 800MOHM SMD Bourns Inc. |
7,751 | - |
|
数据表 |
CE201210 | 0805 (2012 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±5% | 300 mA | - | 0805 (2012 Metric) | Unshielded | 800mOhm Max | 68 nH | 25 @ 100MHz | 700MHz | Surface Mount | - | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - | -55°C ~ 125°C | 100 MHz | 0.041" (1.03mm) |
|
SRP5020C-3R3MFIXED IND 3.3UH 4A 74 MOHM SMD Bourns Inc. |
2,391 | - |
|
数据表 |
SRP5020C | Nonstandard | Tape & Reel (TR) | Obsolete | - | Metal | ±20% | 4 A | 7A | - | Shielded | 74mOhm Max | 3.3 µH | 20 @ 100kHz | 30MHz | Surface Mount | - | 0.224" L x 0.205" W (5.70mm x 5.20mm) | - | -40°C ~ 125°C | 100 kHz | 0.079" (2.00mm) |
|
SRP7028C-150MFIXED IND 15UH 3A 123 MOHM SMD Bourns Inc. |
985 | - |
|
数据表 |
SRP7028C | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Metal | ±20% | 3 A | 4A | - | Shielded | 123mOhm Max | 15 µH | 20 @ 100kHz | 12MHz | Surface Mount | - | 0.280" L x 0.260" W (7.10mm x 6.60mm) | - | -40°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
|
SRP7028C-3R3MFIXED IND 3.3UH 6A 30 MOHM SMD Bourns Inc. |
583 | - |
|
数据表 |
SRP7028C | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Metal | ±20% | 6 A | 13.5A | - | Shielded | 30mOhm Max | 3.3 µH | 15 @ 100kHz | 25MHz | Surface Mount | - | 0.280" L x 0.260" W (7.10mm x 6.60mm) | - | -40°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
|
SRP7028C-2R2MFIXED IND 2.2UH 8A 18 MOHM SMD Bourns Inc. |
151 | - |
|
数据表 |
SRP7028C | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Metal | ±20% | 8 A | 14A | - | Shielded | 18mOhm Max | 2.2 µH | 15 @ 100kHz | 32MHz | Surface Mount | - | 0.280" L x 0.260" W (7.10mm x 6.60mm) | - | -40°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
SRR0735A-151MFIXED IND 150UH 470MA 930MOHM SM Bourns Inc. |
1,671 | - |
|
数据表 |
SRR0735A | Nonstandard | Tape & Reel (TR) | Not For New Designs | Drum Core, Wirewound | Ferrite | ±20% | 470 mA | 480mA | - | Shielded | 930mOhm Max | 150 µH | - | - | Surface Mount | AEC-Q200 | 0.287" L x 0.287" W (7.30mm x 7.30mm) | - | -40°C ~ 125°C | 1 kHz | 0.146" (3.70mm) |
|
|
SRP7028C-6R8MFIXED IND 6.8UH 4.5A 60MOHM SMD Bourns Inc. |
108 | - |
|
数据表 |
SRP7028C | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Metal | ±20% | 4.5 A | 8.3A | - | Shielded | 60mOhm Max | 6.8 µH | 15 @ 100kHz | 16MHz | Surface Mount | - | 0.280" L x 0.260" W (7.10mm x 6.60mm) | - | -40°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
|
SRU5028A-150YFIXED IND 15UH 1.1A 140 MOHM SMD Bourns Inc. |
1,263 | - |
|
数据表 |
SRU5028A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 1.1 A | 1A | - | Shielded | 140mOhm Max | 15 µH | 18 @ 2.52MHz | 23MHz | Surface Mount | AEC-Q200 | 0.205" L x 0.205" W (5.20mm x 5.20mm) | - | -40°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
SRE6603-682MFIXED IND 6.8MH 40MA 25 OHM SMD Bourns Inc. |
5,267 | - |
|
数据表 |
SRE6603 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 40 mA | 19mA | - | Shielded | 25Ohm Max | 6.8 mH | 50 @ 100kHz | 1MHz | Surface Mount | - | 0.260" L x 0.175" W (6.60mm x 4.45mm) | - | -25°C ~ 105°C | 100 kHz | 0.115" (2.92mm) |
