直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AFB0612MCFAN AXIAL 60X13MM 12VDC WIRE |
0 | - |
|
数据表 |
AFB | Box | Active | 12VDC | Square - 60mm L x 60mm H | 18.2 CFM (0.510m³/min) | 0.119 in H2O (29.6 Pa) | Ball | 0.074 lb (33.56 g) | Tubeaxial | Locked Rotor Protection | 13.00mm | 28.0dB(A) | 1.32 W | CE, CSA, UL, VDE | 3600 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
DC0701524H2B-2T2FAN 70X15MM 24VDC MOLEX 22-01-10 |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Square - 70mm L x 70mm H | 33.5 CFM (0.938m³/min) | 0.220 in H2O (54.8 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection | 15.00mm | 39.0dB(A) | 6 W | CE, cURus | 4300 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Position Rectangular Connector | - |
|
|
DC0801524H2B-BT0FAN 80X15MM 24VDC PWM/TACH |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Square - 80mm L x 80mm H | 37.6 CFM (1.05m³/min) | 0.150 in H2O (37.3 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 15.00mm | 36.0dB(A) | 3.84 W | CE, cURus | 3600 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
DC0701524M2B-2T2FAN 70X15MM 24VDC MOLEX 22-01-10 |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Square - 70mm L x 70mm H | 29.6 CFM (0.829m³/min) | 0.170 in H2O (42.3 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection | 15.00mm | 35.0dB(A) | 4.08 W | CE, cURus | 3800 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Position Rectangular Connector | - |
|
G5015E24B-RSRFAN AXIAL 50X15MM 24VDC WIRE |
0 | - |
|
数据表 |
G5015 | Bulk | Active | 24VDC | Square - 50mm L x 50mm H | 16.0 CFM (0.448m³/min) | 0.220 in H2O (54.8 Pa) | Ball | 0.077 lb (34.93 g) | Tubeaxial | Thermal Overload Protector (TOP) | 15.00mm | 34.0dB(A) | - | CE, cUL, TUV, UL | 6500 RPM | - | 2 Wire Leads | - |
|
|
G5015H05B-RSRFAN AXIAL 50X15MM BALL 5VDC WIRE |
0 | - |
|
数据表 |
G5015 | Bulk | Active | 5VDC | Square - 50mm L x 50mm H | 13.0 CFM (0.364m³/min) | 0.170 in H2O (42.3 Pa) | Ball | 0.077 lb (34.93 g) | Tubeaxial | Thermal Overload Protector (TOP) | 15.00mm | 29.0dB(A) | - | CE, cUL, TUV, UL | 5500 RPM | - | 2 Wire Leads | - |
|
G5015M12B-RSRFAN AXIAL 50X15MM 12VDC WIRE |
0 | - |
|
数据表 |
G5015 | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 11.0 CFM (0.308m³/min) | 0.110 in H2O (27.4 Pa) | Ball | 0.077 lb (34.93 g) | Tubeaxial | Thermal Overload Protector (TOP) | 15.00mm | 24.0dB(A) | - | CE, cUL, TUV, UL | 4500 RPM | - | 2 Wire Leads | - |
|
|
G5015M24B-RSRFAN AXIAL 50X15MM 24VDC WIRE |
0 | - |
|
数据表 |
G5015 | Bulk | Active | 24VDC | Square - 50mm L x 50mm H | 11.0 CFM (0.308m³/min) | 0.110 in H2O (27.4 Pa) | Ball | 0.077 lb (34.93 g) | Tubeaxial | Thermal Overload Protector (TOP) | 15.00mm | 24.0dB(A) | - | CE, cUL, TUV, UL | 4500 RPM | - | 2 Wire Leads | - |
|
|
G5015S24B-RSRFAN AXIAL 50X15MM 24VDC WIRE |
0 | - |
|
数据表 |
G5015 | Bulk | Active | 24VDC | Square - 50mm L x 50mm H | 5.0 CFM (0.140m³/min) | 0.040 in H2O (10.0 Pa) | Ball | 0.077 lb (34.93 g) | Tubeaxial | Thermal Overload Protector (TOP) | 15.00mm | 20.0dB(A) | - | CE, cUL, TUV, UL | 2500 RPM | - | 2 Wire Leads | - |
|
|
G8020E12B1-RSRFAN AXIAL 80X20.8MM 12VDC WIRE |
0 | - |
|
数据表 |
G8020 | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 49.0 CFM (1.37m³/min) | 0.200 in H2O (49.8 Pa) | Ball | 0.185 lb (83.91 g) | Tubeaxial | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 20.80mm | 37.0dB(A) | - | CE, cUL, TUV, UL | 4000 RPM | - | 3 Wire Leads | - |
|
|
G8020E24B1-RSR-TTLFAN AXIAL 80X20.8MM 24VDC WIRE |
0 | - |
|
数据表 |
G8020 | Bulk | Active | 24VDC | Square - 80mm L x 80mm H | 49.0 CFM (1.37m³/min) | 0.200 in H2O (49.8 Pa) | Ball | 0.185 lb (83.91 g) | Tubeaxial | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 20.80mm | 37.0dB(A) | - | CE, cUL, TUV, UL | 4000 RPM | - | 3 Wire Leads | - |
|
|
G8020H12B1-RSRFAN AXIAL 80X20.8MM 12VDC WIRE |
0 | - |
|
数据表 |
G8020 | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 43.0 CFM (1.20m³/min) | 0.170 in H2O (42.3 Pa) | Ball | 0.185 lb (83.91 g) | Tubeaxial | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 20.80mm | 33.0dB(A) | - | CE, cUL, TUV, UL | 3500 RPM | - | 3 Wire Leads | - |
|
|
G8020L12B1-RSRFAN AXIAL 80X20.8MM 12VDC WIRE |
0 | - |
|
数据表 |
G8020 | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 31.0 CFM (0.868m³/min) | 0.100 in H2O (24.9 Pa) | Ball | 0.185 lb (83.91 g) | Tubeaxial | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 20.80mm | 25.0dB(A) | - | CE, cUL, TUV, UL | 2500 RPM | - | 3 Wire Leads | - |
|
|
G8020S12B1-RSRFAN AXIAL 80X20.8MM 12VDC WIRE |
0 | - |
|
数据表 |
G8020 | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 24.0 CFM (0.672m³/min) | 0.060 in H2O (14.9 Pa) | Ball | 0.185 lb (83.91 g) | Tubeaxial | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 20.80mm | 22.0dB(A) | - | CE, cUL, TUV, UL | 2000 RPM | - | 3 Wire Leads | - |
|
G8020E24B1-RSR-WSFAN AXIAL 80X20.8MM 24VDC WIRE |
0 | - |
|
数据表 |
G8020 | Bulk | Active | 24VDC | Square - 80mm L x 80mm H | 49.0 CFM (1.37m³/min) | 0.200 in H2O (49.8 Pa) | Ball | 0.185 lb (83.91 g) | Tubeaxial | Alarm Sensor, Speed Sensor (Tach), Thermal Overload Protector (TOP) | 20.80mm | 37.0dB(A) | - | CE, cUL, TUV, UL | 4000 RPM | - | 4 Wire Leads | - |
|
|
G8020M24B2-FSR-WSFAN AXIAL 80X20.8MM 24VDC WIRE |
0 | - |
|
数据表 |
G8020 | Bulk | Active | 24VDC | Square - 80mm L x 80mm H | 38.0 CFM (1.06m³/min) | 0.130 in H2O (32.4 Pa) | Ball | 0.185 lb (83.91 g) | Tubeaxial | Alarm Sensor, Locked Rotor Sensor, Thermal Overload Protector (TOP) | 20.80mm | 29.0dB(A) | - | CE, cUL, TUV, UL | 3000 RPM | - | 4 Wire Leads | - |
|
|
G8025E12B2-FSRFAN 80X25MM BALL 12VDC WIRE |
0 | - |
|
数据表 |
G8025 | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | - | - | Ball | - | - | Locked Rotor Sensor | 25.00mm | - | - | CE, cUL, TUV, UL | - | - | 3 Wire Leads | - |
|
|
G8025H12B2-FSRFAN 80X25MM BALL 12VDC WIRE |
0 | - |
|
数据表 |
G8025 | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | - | - | Ball | - | - | Locked Rotor Sensor | 25.00mm | - | - | CE, cUL, TUV, UL | - | - | 3 Wire Leads | - |
|
|
2004KL-01W-B39-B00FAN AXIAL 50X10MM BALL 5VDC WIRE |
0 | - |
|
数据表 |
2004KL | Box | Active | 5VDC | Square - 50mm L x 50mm H | 6.4 CFM (0.179m³/min) | 0.064 in H2O (16.0 Pa) | Ball | 0.044 lb (19.96 g) | Tubeaxial | Locked Rotor Sensor | 10.00mm | 23.0dB | 500 mW | CE, CSA, UL, VDE | 3500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
2004KL-01W-B39-B50FAN AXIAL 50X10MM BALL 5VDC WIRE |
0 | - |
|
数据表 |
2004KL | Box | Active | 5VDC | Square - 50mm L x 50mm H | 6.4 CFM (0.179m³/min) | 0.064 in H2O (16.0 Pa) | Ball | 0.044 lb (19.96 g) | Tubeaxial | Speed Sensor (Tach) | 10.00mm | 23.0dB | 500 mW | CE, CSA, UL, VDE | 3500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
