交流直流转换器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 功率(瓦特) | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输入 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 6 | 电流 - 输出 2 | 应用 | 电流 - 输出 5 | 电流 - 输出 3 | 电流 - 输出 4 | 电压 - 隔离 | 效率 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 | 认证机构 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RACM40-36SK/OF-CTNAC/DC CONVERTER 36V 40W |
0 | - |
|
数据表 |
POWERLINE RACM40-K/OF (40W) | Box | Active | Open Frame | 1 | 36V | - | - | 40W | - | - | 80 ~ 264 VAC, 120 ~ 370 VDC | - | 1.111 A | - | - | Medical | - | - | - | 4 kV | -40°C ~ 85°C (With Derating) | Standby Output, Universal Input | Chassis Mount | 3.08" L x 1.60" W x 1.00" H (78.3mm x 40.6mm x 25.5mm) | ||
|
NEVO+600S-2505-DK000AC/DC CONVERTER 5X12V 300W |
0 | - |
|
数据表 |
NEVO+600S | Box | Active | Enclosed | 5 | 12V | 12V | 12V | 300W | 12V | 12V | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 15 A | - | 5 A | ITE (Commercial) | 5 A | 5 A | 5 A | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
AMES150-48S277NZ-QAC/DC CONVERTER 48V 158W |
2 | - |
|
数据表 |
AMES150-277NZ (158W) | Box | Obsolete | Enclosed, Conformal Coated | 1 | 48V | - | - | 158W | - | - | 85 ~ 305 VAC, 120 ~ 431 VDC | - | 3.3 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output | Chassis Mount | 6.26" L x 3.82" W x 1.18" H (159.0mm x 97.0mm x 30.0mm) | ||
|
NEVO+600S-1025-DK000AC/DC CONVERTER 5V 3X12V 300W |
0 | - |
|
数据表 |
NEVO+600S | Box | Active | Enclosed | 4 | 5V | 12V | 12V | 300W | 12V | - | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 25 A | - | 15 A | ITE (Commercial) | - | 5 A | 5 A | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
AMES150-36S277NZ-PAC/DC CONVERTER 36V 155W |
2 | - |
|
数据表 |
AMES150-277NZ (155W) | Box | Obsolete | Enclosed | 1 | 36V | - | - | 155W | - | - | 85 ~ 305 VAC, 120 ~ 431 VDC | - | 4.3 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output | Chassis Mount | 6.26" L x 3.82" W x 1.18" H (159.0mm x 97.0mm x 30.0mm) | ||
|
NEVO+600S-2042-DK000AC/DC CONVERTER 12V 48V 12V 300W |
0 | - |
|
数据表 |
NEVO+600S | Box | Active | Enclosed | 3 | 12V | 48V | 12V | 300W | - | - | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 15 A | - | 3.75 A | ITE (Commercial) | - | 15 A | - | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
AMES150-36S277NZ-QAC/DC CONVERTER 36V 155W |
2 | - |
|
数据表 |
AMES150-277NZ (155W) | Box | Obsolete | Enclosed, Conformal Coated | 1 | 36V | - | - | 155W | - | - | 85 ~ 305 VAC, 120 ~ 431 VDC | - | 4.3 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output | Chassis Mount | 6.26" L x 3.82" W x 1.18" H (159.0mm x 97.0mm x 30.0mm) | ||
|
NEVO+600S-0415-DK000AC/DC CNVRTR 48V 5V 2X12V 425W |
0 | - |
|
数据表 |
NEVO+600S | Box | Active | Enclosed | 4 | 48V | 5V | 12V | 425W | 12V | - | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 3.75 A | - | 25 A | ITE (Commercial) | - | 5 A | 5 A | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
AMES150-15S277NZ-PAC/DC CONVERTER 15V 150W |
2 | - |
|
数据表 |
AMES150-277NZ (150W) | Box | Obsolete | Enclosed | 1 | 15V | - | - | 150W | - | - | 85 ~ 305 VAC, 120 ~ 431 VDC | - | 10 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output | Chassis Mount | 6.26" L x 3.82" W x 1.18" H (159.0mm x 97.0mm x 30.0mm) | ||
|
NEVO+600SL-0155-DK000AC/DC CONVERTER 5V 4X12V 425W |
0 | - |
|
数据表 |
NEVO+600SL | Box | Active | Enclosed | 5 | 5V | 12V | 12V | 425W | 12V | 12V | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 25 A | - | 5 A | ITE (Commercial) | 5 A | 5 A | 5 A | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
AMES150-15S277NZ-QAC/DC CONVERTER 15V 150W |
1 | - |
|
数据表 |
AMES150-277NZ (150W) | Box | Obsolete | Enclosed, Conformal Coated | 1 | 15V | - | - | 150W | - | - | 85 ~ 305 VAC, 120 ~ 431 VDC | - | 10 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output | Chassis Mount | 6.26" L x 3.82" W x 1.18" H (159.0mm x 97.0mm x 30.0mm) | ||
|
NEVO+600S-4043-DK000AC/DC CONVERTER 2X48V 24V 300W |
0 | - |
|
数据表 |
NEVO+600S | Box | Active | Enclosed | 3 | 48V | 48V | 24V | 300W | - | - | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 3.75 A | - | 3.75 A | ITE (Commercial) | - | 7.5 A | - | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
VGS-75C-24-AAC/DC CONVERTER 24V 77W |
0 | - |
|
数据表 |
VGS-75C | Box | Not For New Designs | Enclosed | 1 | 24V | - | - | 77W | - | - | 85 ~ 264 VAC, 120 ~ 373 VDC | - | 3.2 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 3.90" L x 3.82" W x 1.18" H (99.0mm x 97.0mm x 30.0mm) | ||
|
NEVO+600S-2204-DK000AC/DC CONVERTER 2X12V 48V 300W |
0 | - |
|
数据表 |
NEVO+600S | Box | Active | Enclosed | 3 | 12V | 12V | 48V | 300W | - | - | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 15 A | - | 15 A | ITE (Commercial) | - | 3.75 A | - | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
AMES150-15SNZ-PAC/DC CONVERTER 15V 150W |
0 | - |
|
数据表 |
AMES150-NZ (150W) | Active | Enclosed | 1 | 13.5 ~ 18V | - | - | 150W | - | - | 90 ~ 264 VAC, 240 ~ 370 VDC | - | 10 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 6.26" L x 3.82" W x 1.18" H (159.0mm x 97.0mm x 30.0mm) | |||
|
NEVO+600S-0455-DK000AC/DC CONVERTER 48V 4X12V 450W |
0 | - |
|
数据表 |
NEVO+600S | Box | Active | Enclosed | 5 | 48V | 12V | 12V | 450W | 12V | 12V | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 3.75 A | - | 5 A | ITE (Commercial) | 5 A | 5 A | 5 A | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
AMES150-12SNZ-PAC/DC CONVERTER 12V 150W |
0 | - |
|
数据表 |
AMES150-NZ (150W) | Active | Enclosed | 1 | 10.2 ~ 13.8V | - | - | 150W | - | - | 90 ~ 264 VAC, 240 ~ 370 VDC | - | 12.5 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 6.26" L x 3.82" W x 1.18" H (159.0mm x 97.0mm x 30.0mm) | |||
|
NEVO+600S-1031-DK000AC/DC CONVERTER 5V 24V 5V 275W |
0 | - |
|
数据表 |
NEVO+600S | Box | Active | Enclosed | 3 | 5V | 24V | 5V | 275W | - | - | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 25 A | - | 7.5 A | ITE (Commercial) | - | 25 A | - | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
NEVO+600S-4053-DK000AC/DC CNVRTR 48V 2X12V 24V 300W |
0 | - |
|
数据表 |
NEVO+600S | Box | Active | Enclosed | 4 | 48V | 12V | 12V | 300W | 24V | - | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 3.75 A | - | 5 A | ITE (Commercial) | - | 5 A | 7.5 A | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
NEVO+600SL-4054-DK000AC/DC CNVRTR 48V 2X12V 48V 450W |
0 | - |
|
数据表 |
NEVO+600SL | Box | Active | Enclosed | 4 | 48V | 12V | 12V | 450W | 48V | - | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 3.75 A | - | 5 A | ITE (Commercial) | - | 5 A | 3.75 A | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) |
