交流直流转换器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 功率(瓦特) | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输入 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 6 | 电流 - 输出 2 | 应用 | 电流 - 输出 5 | 电流 - 输出 3 | 电流 - 输出 4 | 电压 - 隔离 | 效率 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 | 认证机构 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NMP1K2-C##CKC-00AC/DC CONVERTER 2X5V 48V 5V 780W |
0 | - |
|
数据表 |
NMP (1200W) | Box | Active | Enclosed | 4 | 5V | 5V | 48V | 780W | 5V | - | 90 ~ 264 VAC, 120 ~ 370 VDC | - | 36 A | - | 36 A | ITE (Commercial), Medical | - | 5 A | 36 A | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 9.84" L x 5.00" W x 1.61" H (250.0mm x 127.0mm x 41.0mm) | ||
|
NMP1K2-C##CKE-00AC/DC CNVRTR 2X5V 48V 12V 840W |
0 | - |
|
数据表 |
NMP (1200W) | Box | Active | Enclosed | 4 | 5V | 5V | 48V | 840W | 12V | - | 90 ~ 264 VAC, 120 ~ 370 VDC | - | 36 A | - | 36 A | ITE (Commercial), Medical | - | 5 A | 20 A | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 9.84" L x 5.00" W x 1.61" H (250.0mm x 127.0mm x 41.0mm) | ||
|
NMP1K2-C##CKH-00AC/DC CNVRTR 2X5V 48V 24V 840W |
0 | - |
|
数据表 |
NMP (1200W) | Box | Active | Enclosed | 4 | 5V | 5V | 48V | 840W | 24V | - | 90 ~ 264 VAC, 120 ~ 370 VDC | - | 36 A | - | 36 A | ITE (Commercial), Medical | - | 5 A | 10 A | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 9.84" L x 5.00" W x 1.61" H (250.0mm x 127.0mm x 41.0mm) | ||
|
NMP1K2-C##CKK-00AC/DC CONVERTER 2X5V 2X48V 840W |
0 | - |
|
数据表 |
NMP (1200W) | Box | Active | Enclosed | 4 | 5V | 5V | 48V | 840W | 48V | - | 90 ~ 264 VAC, 120 ~ 370 VDC | - | 36 A | - | 36 A | ITE (Commercial), Medical | - | 5 A | 5 A | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 9.84" L x 5.00" W x 1.61" H (250.0mm x 127.0mm x 41.0mm) | ||
|
NMP1K2-C##ECC-00AC/DC CONVERTER 5V 12V 2X5V 780W |
0 | - |
|
数据表 |
NMP (1200W) | Box | Active | Enclosed | 4 | 5V | 12V | 5V | 780W | 5V | - | 90 ~ 264 VAC, 120 ~ 370 VDC | - | 36 A | - | 20 A | ITE (Commercial), Medical | - | 36 A | 36 A | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Load Sharing, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 9.84" L x 5.00" W x 1.61" H (250.0mm x 127.0mm x 41.0mm) | ||
|
PSK-S10C-15-TAC/DC CONVERTER 15V 11W |
0 | - |
|
数据表 |
PSK-S10C (10W) | Tray | Obsolete | Enclosed | 1 | 15V | - | - | 11W | - | - | 85 ~ 264 VAC, 100 ~ 370 VDC | - | 700 mA | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -40°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 2.99" L x 1.24" W x 1.09" H (76.0mm x 31.5mm x 27.8mm) | ||
|
NEVO+600SL-5302-DK000AC/DC CNVRTR 2X12V 24V 12V 450W |
0 | - |
|
数据表 |
NEVO+600SL | Box | Active | Enclosed | 4 | 12V | 12V | 24V | 450W | 12V | - | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 5 A | - | 5 A | ITE (Commercial) | - | 7.5 A | 15 A | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
NEVO+600SL-0331-DK000AC/DC CONVERTER 2X24V 5V 425W |
0 | - |
|
数据表 |
NEVO+600SL | Box | Active | Enclosed | 3 | 24V | 24V | 5V | 425W | - | - | 85 ~ 264 VAC, 120 ~ 370 VDC | - | 7.5 A | - | 7.5 A | ITE (Commercial) | - | 25 A | - | 4 kV | -20°C ~ 70°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 3.06" L x 3.06" W x 1.61" H (77.7mm x 77.7mm x 41.0mm) | ||
|
PSK-S10C-24-TAC/DC CONVERTER 24V 11W |
0 | - |
|
数据表 |
PSK-S10C (10W) | Tray | Obsolete | Enclosed | 1 | 24V | - | - | 11W | - | - | 85 ~ 264 VAC, 100 ~ 370 VDC | - | 450 mA | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -40°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 2.99" L x 1.24" W x 1.09" H (76.0mm x 31.5mm x 27.8mm) | ||
|
PSK-S6C-9-TAC/DC CONVERTER 9V 6W |
0 | - |
|
数据表 |
PSK-S6C (6W) | Tray | Obsolete | Enclosed | 1 | 9V | - | - | 6W | - | - | 85 ~ 264 VAC, 100 ~ 370 VDC | - | 660 mA | - | - | ITE (Commercial) | - | - | - | 4 kV | -40°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 2.99" L x 1.24" W x 0.95" H (76.0mm x 31.5mm x 24.2mm) | ||
|
VOF-60C-S5AC/DC CONVERTER 5V 50W |
0 | - |
|
数据表 |
VOF-60C (60W) | Tray | Not For New Designs | Open Frame | 1 | 5V | - | - | 50W | - | - | 85 ~ 264 VAC, 100 ~ 370 VDC | - | 10 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -25°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 3.00" L x 2.00" W x 1.18" H (76.2mm x 50.8mm x 30.0mm) | ||
|
VOF-60C-S9AC/DC CONVERTER 9V 59W |
0 | - |
|
数据表 |
VOF-60C (60W) | Tray | Not For New Designs | Open Frame | 1 | 9V | - | - | 59W | - | - | 85 ~ 264 VAC, 100 ~ 370 VDC | - | 6.6 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -25°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 3.00" L x 2.00" W x 1.18" H (76.2mm x 50.8mm x 30.0mm) | ||
|
VOF-60C-S15AC/DC CONVERTER 15V 60W |
0 | - |
|
数据表 |
VOF-60C (60W) | Tray | Not For New Designs | Open Frame | 1 | 15V | - | - | 60W | - | - | 85 ~ 264 VAC, 100 ~ 370 VDC | - | 4 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -25°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 3.00" L x 2.00" W x 1.18" H (76.2mm x 50.8mm x 30.0mm) | ||
|
AMES100-5S277NZ-QAC/DC CONVERTER 5V 90W |
2 | - |
|
数据表 |
AMES100-277NZ (90W) | Box | Obsolete | Enclosed, Conformal Coated | 1 | 5V | - | - | 90W | - | - | 85 ~ 305 VAC, 120 ~ 430 VDC | - | 18 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output | Chassis Mount | 5.08" L x 3.82" W x 1.18" H (129.0mm x 97.0mm x 30.0mm) | ||
|
VOF-65C-S9AC/DC CONVERTER 9V 59W |
0 | - |
|
数据表 |
VOF-65C (65W) | Tray | Not For New Designs | Open Frame | 1 | 9V | - | - | 59W | - | - | 85 ~ 264 VAC, 100 ~ 370 VDC | - | 6.6 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -25°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 3.00" L x 2.00" W x 1.18" H (76.2mm x 50.8mm x 30.0mm) | ||
|
RPS-500-24-SFAC/DC CONVERTER 24V 499W |
37 | - |
|
数据表 |
RPS-500 (500W) | Box | Active | Enclosed | 1 | 24V | - | - | 499W | - | - | 80 ~ 264 VAC, 113 ~ 370 VDC | - | 20.8 A | - | - | Medical | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.30" L x 3.39" W x 1.69" H (160.0mm x 86.0mm x 43.0mm) | ||
|
VOF-65C-S15AC/DC CONVERTER 15V 65W |
0 | - |
|
数据表 |
VOF-65C (65W) | Tray | Not For New Designs | Open Frame | 1 | 15V | - | - | 65W | - | - | 85 ~ 264 VAC, 100 ~ 370 VDC | - | 4.34 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -25°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 3.00" L x 2.00" W x 1.18" H (76.2mm x 50.8mm x 30.0mm) | ||
|
LM100-20B15AC/DC CONVERTER 15V 105W |
5 | - |
|
数据表 |
LM100-20Bxx (100W) | Box | Not For New Designs | Enclosed | 1 | 15V | - | - | 105W | - | - | 85 ~ 264 VAC, 120 ~ 373 VDC | - | 7 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Standby Output, Universal Input | Chassis Mount | 5.08" L x 3.82" W x 1.18" H (129.0mm x 97.0mm x 30.0mm) | ||
|
RPS-500-48-SFAC/DC CONVERTER 48V 499W |
36 | - |
|
数据表 |
RPS-500 (500W) | Box | Active | Enclosed | 1 | 48V | - | - | 499W | - | - | 80 ~ 264 VAC, 113 ~ 370 VDC | - | 10.4 A | - | - | Medical | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote Sense, Standby Output, Universal Input | Chassis Mount | 6.30" L x 3.39" W x 1.69" H (160.0mm x 86.0mm x 43.0mm) | ||
|
LM100-23B15AC/DC CONVERTER 15V 105W |
0 | - |
|
数据表 |
305RAC / LM-23B | Box | Not For New Designs | Enclosed | 1 | 15V | - | - | 105W | - | - | 85 ~ 305 VAC, 120 ~ 431 VDC | - | 7 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, Standby Output, Universal Input | Chassis Mount | 5.08" L x 3.82" W x 1.18" H (129.0mm x 97.0mm x 30.0mm) |
