固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CSAB1260A-330MSMD MOLDING POWER CHOKE CODACA |
380 | - |
|
数据表 |
CSAB1260A | 2-SMD | Cut Tape (CT) | Active | Molded | Alloy Powder | ±20% | 5.3 A | 6A | 2-SMD | Shielded | 75mOhm Max | 33 µH | - | - | Surface Mount | AEC-Q200 | 0.504" L x 0.543" W (12.80mm x 13.80mm) | Low DCR, Low Loss | -40°C ~ 125°C | 100 kHz | 0.236" (6.00mm) |
|
|
CSAB1260A-101MSMD MOLDING POWER CHOKE CODACA |
2,679 | - |
|
数据表 |
CSAB1260A | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | ±20% | 3.1 A | 3.5A | - | Shielded | 200mOhm Max | 100 µH | - | - | Surface Mount | AEC-Q200 | 0.543" L x 0.496" W (13.80mm x 12.60mm) | - | -40°C ~ 125°C | 100 kHz | 0.236" (6.00mm) |
|
|
CSAB1265A-1R0MSMD MOLDING POWER CHOKE CODACA |
380 | - |
|
数据表 |
CSAB1265A | 2-SMD | Cut Tape (CT) | Active | Molded | Alloy Powder | ±20% | 31 A | 42A | 2-SMD | Shielded | 2.1mOhm Max | 1 µH | - | - | Surface Mount | AEC-Q200 | 0.504" L x 0.543" W (12.80mm x 13.80mm) | Low DCR, Low Loss | -40°C ~ 125°C | 100 kHz | 0.248" (6.30mm) |
|
|
CSAB1265A-3R3MSMD MOLDING POWER CHOKE CODACA |
365 | - |
|
数据表 |
CSAB1265A | 2-SMD | Cut Tape (CT) | Active | Molded | Alloy Powder | ±20% | 18.5 A | 26A | 2-SMD | Shielded | 5.8mOhm Max | 3.3 µH | - | - | Surface Mount | AEC-Q200 | 0.504" L x 0.543" W (12.80mm x 13.80mm) | Low DCR, Low Loss | -40°C ~ 125°C | 100 kHz | 0.248" (6.30mm) |
|
|
CSAB1260A-220MSMD MOLDING POWER CHOKE CODACA |
250 | - |
|
数据表 |
CSAB1260A | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | ±20% | 6.8 A | 7.5A | - | Shielded | 39.5mOhm Max | 22 µH | - | - | Surface Mount | AEC-Q200 | 0.543" L x 0.496" W (13.80mm x 12.60mm) | - | -40°C ~ 125°C | 100 kHz | 0.236" (6.00mm) |
|
CSBX0640-2R2MSMD HIGH CURRENT POWER INDUCTOR CODACA |
983 | - |
|
数据表 |
CSBX0640 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | ±20% | 9 A | 16A | - | Shielded | 12.1mOhm Max | 2.2 µH | - | - | Surface Mount | AEC-Q200 | 0.276" L x 0.272" W (7.00mm x 6.90mm) | High Saturation | -40°C ~ 125°C | 100 kHz | 0.157" (4.00mm) |
|
CSBL0640-2R2MSMD HIGH CURRENT POWER INDUCTOR CODACA |
975 | - |
|
数据表 |
CSBL0640 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | ±20% | 9 A | 13A | - | Shielded | 12.1mOhm Max | 2.2 µH | - | - | Surface Mount | AEC-Q200 | 0.276" L x 0.272" W (7.00mm x 6.90mm) | - | -50°C ~ 150°C | 100 kHz | 0.157" (4.00mm) |
|
|
CSBL0640-1R0MSMD HIGH CURRENT POWER INDUCTOR CODACA |
958 | - |
|
数据表 |
CSBL0640 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | ±20% | 15.5 A | 19A | - | Shielded | 4.5mOhm Max | 1 µH | - | - | Surface Mount | AEC-Q200 | 0.276" L x 0.272" W (7.00mm x 6.90mm) | - | -50°C ~ 150°C | 100 kHz | 0.146" (3.70mm) |
|
|
CSBL0640-1R5MSMD HIGH CURRENT POWER INDUCTOR CODACA |
955 | - |
|
数据表 |
CSBL0640 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | ±20% | 11.5 A | 14A | - | Shielded | 6.2mOhm Max | 1.5 µH | - | - | Surface Mount | AEC-Q200 | 0.276" L x 0.272" W (7.00mm x 6.90mm) | - | -50°C ~ 150°C | 100 kHz | 0.157" (4.00mm) |
|
|
CSBX0640-4R7MSMD HIGH CURRENT POWER INDUCTOR CODACA |
955 | - |
|
数据表 |
CSBX0640 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | ±20% | 6.4 A | 11A | - | Shielded | 21.2mOhm Max | 4.7 µH | - | - | Surface Mount | AEC-Q200 | 0.276" L x 0.272" W (7.00mm x 6.90mm) | High Saturation | -40°C ~ 125°C | 100 kHz | 0.157" (4.00mm) |
