固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRU6013-330YFIXED IND 33UH 780MA 500MOHM SMD Bourns Inc. |
0 | - |
|
数据表 |
SRU6013 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 780 mA | 580mA | - | Shielded | 500mOhm Max | 33 µH | 10 @ 2.52MHz | 18MHz | Surface Mount | - | 0.256" L x 0.244" W (6.50mm x 6.20mm) | - | -40°C ~ 125°C | 100 kHz | 0.063" (1.60mm) |
|
SRE6603-102MFIXED IND 1MH 150MA 3.4 OHM SMD Bourns Inc. |
0 | - |
|
数据表 |
SRE6603 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | ±20% | 150 mA | 45mA | - | Shielded | 3.4Ohm Max | 1 mH | 40 @ 100kHz | 2MHz | Surface Mount | - | 0.260" L x 0.175" W (6.60mm x 4.45mm) | - | -25°C ~ 105°C | 100 kHz | 0.115" (2.92mm) |
|
2304-V-RCFIXED IND 18UH 17.2A 6 MOHM TH Bourns Inc. |
0 | - |
|
数据表 |
2300 | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | ±15% | 17.2 A | - | - | Unshielded | 6mOhm Max | 18 µH | - | - | Through Hole | - | 1.280" Dia x 0.650" W (32.51mm x 16.51mm) | - | -55°C ~ 105°C | 1 kHz | - |
|
|
2315-V-RCFIXED IND 180UH 4.8A 78 MOHM TH Bourns Inc. |
0 | - |
|
数据表 |
2300 | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | ±15% | 4.8 A | - | - | Unshielded | 78mOhm Max | 180 µH | - | - | Through Hole | - | 1.280" Dia x 0.650" W (32.51mm x 16.51mm) | - | -55°C ~ 105°C | 1 kHz | - |
|
|
2203-V-RCFIXED IND 15UH 11.3A 8 MOHM TH Bourns Inc. |
0 | - |
|
数据表 |
2200 | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | ±15% | 11.3 A | - | - | Shielded | 8mOhm Max | 15 µH | - | - | Through Hole | - | 0.950" Dia x 0.550" W (24.13mm x 13.97mm) | - | -55°C ~ 105°C | 1 kHz | - |
|
|
2213-V-RCFIXED IND 120UH 3.3A 98 MOHM TH Bourns Inc. |
0 | - |
|
数据表 |
2200 | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | ±15% | 3.3 A | - | - | Shielded | 98mOhm Max | 120 µH | - | - | Through Hole | - | 0.950" Dia x 0.550" W (24.13mm x 13.97mm) | - | -55°C ~ 105°C | 1 kHz | - |
|
|
2208-V-RCFIXED IND 39UH 7.1A 22 MOHM TH Bourns Inc. |
0 | - |
|
数据表 |
2200 | Radial, Vertical (Open) | Bulk | Active | Toroidal | Iron Powder | ±15% | 7.1 A | - | - | Shielded | 22mOhm Max | 39 µH | - | - | Through Hole | - | 0.950" Dia x 0.550" W (24.13mm x 13.97mm) | - | -55°C ~ 105°C | 1 kHz | - |
|
9250-393FIXED IND 39UH 205MA 1.93 OHM TH Bourns Inc. |
0 | - |
|
数据表 |
9250 | Axial | Bulk | Obsolete | Drum Core, Wirewound | Ferrite | ±10% | 205 mA | 180mA | - | Shielded | 1.93Ohm Max | 39 µH | 50 @ 2.5MHz | 29MHz | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - | -55°C ~ 105°C | 2.5 MHz | - |
|
|
9250-473FIXED IND 47UH 195MA 2.11 OHM TH Bourns Inc. |
0 | - |
|
数据表 |
9250 | Axial | Bulk | Obsolete | Drum Core, Wirewound | Ferrite | ±10% | 195 mA | 175mA | - | Shielded | 2.11Ohm Max | 47 µH | 50 @ 2.5MHz | 27MHz | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - | -55°C ~ 105°C | 2.5 MHz | - |
|
|
9250-333FIXED IND 33UH 240MA 1.37 OHM TH Bourns Inc. |
0 | - |
|
数据表 |
9250 | Axial | Bulk | Obsolete | Drum Core, Wirewound | Ferrite | ±10% | 240 mA | 190mA | - | Shielded | 1.37Ohm Max | 33 µH | 45 @ 2.5MHz | 34MHz | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - | -55°C ~ 105°C | 2.5 MHz | - |
