固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRR1280-102KFIXED IND 1MH 680MA 1.7 OHM SMD Bourns Inc. |
5,113 | - |
|
数据表 |
SRR1280 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 680 mA | 800mA | - | Shielded | 1.7Ohm Max | 1 mH | 40 @ 252kHz | 1.3MHz | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | - | -40°C ~ 125°C | 100 kHz | 0.315" (8.00mm) |
|
|
SRR1280-221KFIXED IND 220UH 1.6A 400MOHM SMD Bourns Inc. |
3,493 | - |
|
数据表 |
SRR1280 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 1.6 A | 1.7A | - | Shielded | 400mOhm Max | 220 µH | 24 @ 796kHz | 3.4MHz | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | - | -40°C ~ 125°C | 100 kHz | 0.315" (8.00mm) |
|
SRR1050A-101YFIXED IND 100UH 1.35A 255MOHM SM Bourns Inc. |
3,017 | - |
|
数据表 |
SRR1050A | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 1.35 A | 1.35A | - | Shielded | 255mOhm Max | 100 µH | - | 4.2MHz | Surface Mount | AEC-Q200 | 0.402" L x 0.394" W (10.20mm x 10.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.201" (5.10mm) |
|
SRR1260-470MFIXED IND 47UH 2.6A 86 MOHM SMD Bourns Inc. |
2,692 | - |
|
数据表 |
SRR1260 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 2.6 A | 2.5A | - | Shielded | 86mOhm Max | 47 µH | 22 @ 2.52MHz | 7.63MHz | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | - | -40°C ~ 125°C | 100 kHz | 0.256" (6.50mm) |
|
|
SRR1260-102KFIXED IND 1MH 680MA 1.7 OHM SMD Bourns Inc. |
2,596 | - |
|
数据表 |
SRR1260 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 680 mA | 600mA | - | Shielded | 1.7Ohm Max | 1 mH | 30 @ 252kHz | 1.8MHz | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | - | -40°C ~ 125°C | 100 kHz | 0.256" (6.50mm) |
|
|
SRR1280-180MFIXED IND 18UH 4.8A 35 MOHM SMD Bourns Inc. |
3,058 | - |
|
数据表 |
SRR1280 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 4.8 A | 4.6A | - | Shielded | 35mOhm Max | 18 µH | 24 @ 2.52MHz | 12MHz | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | - | -40°C ~ 125°C | 100 kHz | 0.315" (8.00mm) |
|
|
SRR1280-181KFIXED IND 180UH 1.75A 300MOHM SM Bourns Inc. |
2,554 | - |
|
数据表 |
SRR1280 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 1.75 A | 1.88A | - | Shielded | 300mOhm Max | 180 µH | 24 @ 796kHz | 4MHz | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | - | -40°C ~ 125°C | 100 kHz | 0.315" (8.00mm) |
|
|
SRR1260-100MFIXED IND 10UH 5.5A 20 MOHM SMD Bourns Inc. |
1,725 | - |
|
数据表 |
SRR1260 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 5.5 A | 5.5A | - | Shielded | 20mOhm Max | 10 µH | 32 @ 2.52MHz | 21MHz | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | - | -40°C ~ 125°C | 100 kHz | 0.256" (6.50mm) |
|
PM3316-151M-RCFIXED IND 150UH 800MA 590MOHM SM Bourns Inc. |
6,499 | - |
|
数据表 |
PM3316 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 800 mA | 1A | - | Unshielded | 590mOhm | 150 µH | 30 @ 50kHz | 6MHz | Surface Mount | - | 0.500" L x 0.394" W (12.70mm x 10.00mm) | - | -55°C ~ 125°C | 1 kHz | 0.209" (5.30mm) |
|
SRR1210-680MFIXED IND 68UH 3A 102 MOHM SMD Bourns Inc. |
126,347 | - |
|
数据表 |
SRR1210 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 3 A | 2.7A | - | Shielded | 102mOhm Max | 68 µH | 12 @ 2.52MHz | 3.8MHz | Surface Mount | - | 0.472" L x 0.472" W (12.00mm x 12.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.394" (10.00mm) |
