直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
THD1248BE-00FAN AXIAL 120MM 48V |
0 | - |
|
数据表 |
THD | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
6025BF).jpg)
|
CFM-6015BF-235-278-22FAN AXIAL 60X15.5MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-60BF | Box | Active | 24VDC | Square - 60mm L x 60mm H | 15.4 CFM (0.431m³/min) | 0.090 in H2O (22.4 Pa) | Ball | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 15.50mm | 27.8dB(A) | 1.44 W | CE, cURus, TUV | 3500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
THB1248BFAN AXIAL 120X25.4MM 48VDC WIRE |
0 | - |
|
数据表 |
THB | Bulk | Obsolete | 48VDC | Square - 120mm L x 120mm H | 186.6 CFM (5.22m³/min) | 0.962 in H2O (239.6 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 25.40mm | 59.0dB(A) | 19.2 W | CE, cURus, TUV | 5300 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
CFM-6015BF-225-204-22FAN AXIAL 60X15.5MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-60BF | Box | Active | 24VDC | Square - 60mm L x 60mm H | 11.0 CFM (0.308m³/min) | 0.050 in H2O (12.4 Pa) | Ball | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 15.50mm | 20.5dB(A) | 960 mW | CE, cURus, TUV | 2500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
TCA1748ATAGPFAN IMP MTRZD 176.5X69MM 48VDC |
0 | - |
|
数据表 |
TCA | Bulk | Obsolete | 48VDC | Round - 176.5mm Dia | 382.0 CFM (10.70m³/min) | 2.114 in H2O (526.6 Pa) | Ball | - | Motorized Impellers | GR-487 (Salt Fog Protection), Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 69.00mm | 70.8dB(A) | 57.6 W | CE, cURus, TUV | 4000 RPM | -13 ~ 158°F (-25 ~ 70°C) | 4 Wire Leads | IP54 - Dust Protected, Water Resistant |
|
|
EF92251B1-1000U-F9912VDC FAN 92X25MM TACH |
0 | - |
|
数据表 |
EF | Box | Active | 12VDC | Square - 92mm L x 92mm H | 51.3 CFM (1.44m³/min) | 0.170 in H2O (42.3 Pa) | Ball | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 25.00mm | 34.0dB(A) | 1.5 W | CCC, CE, cURus, TUV, UKCA | 3000 RPM | - | 3 Wire Leads | - |
|
|
EFB1548VHGD8NFAN AXIAL 172X150MM 48V |
0 | - |
|
数据表 |
* | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
EF92251B2-1000U-F9912VDC FAN 92X25MM TACH |
0 | - |
|
数据表 |
EF | Box | Active | 12VDC | Square - 92mm L x 92mm H | 44.9 CFM (1.26m³/min) | 0.150 in H2O (37.4 Pa) | Ball | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 25.00mm | 32.0dB(A) | 1.08 W | CCC, CE, cURus, TUV, UKCA | 2700 RPM | - | 3 Wire Leads | - |
|
|
FFC0948BFAN AXIAL 92MM 48V |
0 | - |
|
数据表 |
* | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
EF92251B3-1000U-F9912VDC FAN 92X25MM TACH |
0 | - |
|
数据表 |
EF | Box | Active | 12VDC | Square - 92mm L x 92mm H | 39.5 CFM (1.11m³/min) | 0.120 in H2O (29.9 Pa) | Ball | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 25.00mm | 28.0dB(A) | 0.75 W | CCC, CE, cURus, TUV, UKCA | 2400 RPM | - | 3 Wire Leads | - |
|
|
3312NU-2013312NU-201 |
0 | - |
|
数据表 |
3300NU | Bulk | Active | 12VDC | - | - | - | Ball | - | Tubeaxial | - | - | - | - | - | 2950 RPM | - | 2 Wire Leads | - |
|
|
W1G300-EC24-03W1G300-EC24-03 |
0 | - |
|
数据表 |
* | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
4414FL-5524414FL-552 |
0 | - |
|
数据表 |
* | Bulk | Active | 24VDC | Square - 119mm L x 119mm H | - | - | Ball | - | Tubeaxial | Locked Rotor Protection | 25.40mm | 55.0dB(A) | 1.2 W | CE, CSA, UL, VDE | 1600 RPM | -4 ~ 167°F (-20 ~ 75°C) | 2 Wire Leads | - |
|
U65HN-024KS-6FAN BLOWER 73.8X66MM 24VDC |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Rectangular/Rounded - 73.8mm L x 66.3mm H | 15.4 CFM (0.431m³/min) | 38.139 in H2O (9500.0 Pa) | - | - | Blower | Hall Sensor, Motor Winding, NTC Thermistor | 66.00mm | 47.0dB(A) | 90 W | CE | 60000 RPM | -4 ~ 122°F (-20 ~ 50°C) | 10 Position Rectangular Connector | IP10 |
|
U71HL-024KM-4FAN BLOWER 73X86MM 24VDC WIRE |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Rectangular/Rounded - 73mm L x 69mm H | 16.6 CFM (0.465m³/min) | 27.701 in H2O (6900.0 Pa) | - | - | Blower | Locked Rotor Protection, Speed Sensor (Tach), Speed Control (SP) | 86.00mm | 63.0dB(A) | 63 W | CE | 36600 RPM | -4 ~ 113°F (-20 ~ 45°C) | 4 Wire Leads | IP40 |
|
U65MN-024KS-5FAN BLOWER 73.7X44.6MM 24VDC |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Rectangular/Rounded - 73.7mm L x 66.4mm H | 12.0 CFM (0.336m³/min) | 21.679 in H2O (5400.0 Pa) | - | - | Blower | Hall Sensor, Motor Winding, NTC Thermistor | 44.60mm | 47.0dB(A) | 45 W | CE | 42000 RPM | -4 ~ 122°F (-20 ~ 50°C) | 10 Position Rectangular Connector | IP10 |
|
CFM-9225C-120-269-22FAN AXIAL 92X25MM 12VDC WIRE |
0 | - |
|
数据表 |
CFM-92C | Box | Active | 12VDC | Square - 92mm L x 92mm H | 33.4 CFM (0.935m³/min) | 0.070 in H2O (17.4 Pa) | omniCOOL™ Magnetic Sleeve | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 25.00mm | 26.9dB(A) | 1.08 W | CE, cURus, TUV | 2000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
U71MX-024KX-4FAN BLOWER 74.1X59MM 24VDC WIRE |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Rectangular/Rounded - 74.1mm L x 69.4mm H | 13.9 CFM (0.389m³/min) | 16.46 in H2O (4100.0 Pa) | Ball | - | Blower | Locked Rotor Protection, Speed Sensor (Tach), Speed Control (SP) | 59.00mm | 47.0dB(A) | 25 W | CE | 28900 RPM | -4 ~ 122°F (-20 ~ 50°C) | 4 Wire Leads | - |
|
CFM-8025C-225-290-22FAN AXIAL 80X25MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-80C | Box | Active | 24VDC | Square - 80mm L x 80mm H | 30.9 CFM (0.865m³/min) | 0.090 in H2O (22.4 Pa) | omniCOOL™ Magnetic Sleeve | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 25.00mm | 29.0dB(A) | 1.92 W | CE, cURus, TUV | 2500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
R1225Y24BPLB2-7FAN AXIAL 120X25MM 24VDC WIRE |
0 | - |
|
数据表 |
R | Bulk | Active | 24VDC | Square - 120mm L x 120mm H | 129.4 CFM (3.62m³/min) | 0.534 in H2O (133.0 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection | 25.00mm | 51.0dB(A) | 7.92 W | CE, cURus | 4200 RPM | - | 2 Wire Leads | - |
