直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
109P0424G601FAN AXIAL 40X20MM 24VDC WIRE |
52 | - |
|
数据表 |
San Ace 40 | Box | Active | 24VDC | Square - 40mm L x 40mm H | 12.4 CFM (0.347m³/min) | 0.618 in H2O (153.8 Pa) | Ball | 0.101 lb (45.81 g) | Tubeaxial | Speed Sensor (Tach) | 20.00mm | 44.0dB(A) | 3.6 W | CSA, TUV, UL | 12500 RPM | -4 ~ 140°F (-20 ~ 60°C) | 3 Wire Leads | - |
|
AFB1224VHFAN AXIAL 120X25.4MM 24VDC WIRE |
47 | - |
|
数据表 |
AFB | Bulk | Active | 24VDC | Square - 120mm L x 120mm H | 103.7 CFM (2.90m³/min) | 0.371 in H2O (92.5 Pa) | Ball | 0.437 lb (198.00 g) | Tubeaxial | Locked Rotor Protection | 25.40mm | 44.5dB(A) | 5.52 W | CE, CSA, UL, VDE | 3100 RPM | 14 ~ 140°F (-10 ~ 60°C) | 2 Wire Leads | - |
|
|
FFB0824SHEFAN AXIAL 80X38MM 24VDC WIRE |
60 | - |
|
数据表 |
FFB | Bulk | Active | 24VDC | Square - 80mm L x 80mm H | 68.5 CFM (1.92m³/min) | 0.591 in H2O (147.2 Pa) | Ball | 0.375 lb (170.1 g) | Tubeaxial | Locked Rotor Protection | 38.00mm | 48.5dB(A) | 8.16 W | CE, CSA, UL, VDE | 4900 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
109R0612S4011FAN AXIAL 60X25MM 12VDC WIRE |
73 | - |
|
数据表 |
San Ace 60 | Box | Active | 12VDC | Square - 60mm L x 60mm H | 23.0 CFM (0.644m³/min) | 0.228 in H2O (56.8 Pa) | Ball | 0.199 lb (90.26 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 25.00mm | 33.0dB(A) | 2.04 W | CSA, TUV, UL | 4600 RPM | -4 ~ 158°F (-20 ~ 70°C) | 3 Wire Leads | - |
|
|
109R0605F4D01FAN AXIAL 60X25MM BALL 5VDC WIRE |
45 | - |
|
数据表 |
San Ace 60 | Box | Active | 5VDC | Square - 60mm L x 60mm H | 15.5 CFM (0.434m³/min) | 0.118 in H2O (29.4 Pa) | Ball | 0.199 lb (90.26 g) | Tubeaxial | Locked Rotor Sensor | 25.00mm | 24.0dB(A) | 1 W | CSA, TUV, UL | 3200 RPM | -4 ~ 140°F (-20 ~ 60°C) | 3 Wire Leads | - |
|
|
109R0605M401FAN AXIAL 60X25MM BALL 5VDC WIRE |
33 | - |
|
数据表 |
San Ace 60 | Box | Active | 5VDC | Square - 60mm L x 60mm H | 12.7 CFM (0.356m³/min) | 0.079 in H2O (19.6 Pa) | Ball | 0.199 lb (90.26 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 25.00mm | 20.0dB(A) | 650 mW | CSA, TUV, UL | 2600 RPM | -4 ~ 158°F (-20 ~ 70°C) | 3 Wire Leads | - |
|
|
9GA0612H702FAN AXIAL 60X15MM 12VDC WIRE |
80 | - |
|
数据表 |
San Ace 60 | Box | Active | 12VDC | Square - 60mm L x 60mm H | 19.7 CFM (0.552m³/min) | 0.223 in H2O (55.5 Pa) | Ball | 0.111 lb (50.35 g) | Tubeaxial | Locked Rotor Protection | 15.00mm | 34.0dB(A) | 1.2 W | CSA, TUV, UL | 4900 RPM | -4 ~ 158°F (-20 ~ 70°C) | 2 Wire Leads | - |
|
DC1203812L2B-2T0FAN AXIAL 120X38MM 12VDC WIRE |
53 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 120mm L x 120mm H | 114.7 CFM (3.21m³/min) | 0.410 in H2O (102.1 Pa) | Ball | 0.508 lb (230.42 g) | Tubeaxial | Locked Rotor Protection | 38.00mm | 41.0dB(A) | 4.8 W | CE, cURus, TUV | 2600 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
CFM-6025BG68-235-253DC AXIAL FAN, 60 MM SQUARE, 25 M |
89 | - |
|
数据表 |
CFM-60BG68 | Box | Active | 24VDC | Square - 60mm L x 60mm H | 14.7 CFM (0.412m³/min) | 0.150 in H2O (37.3 Pa) | Ball | - | Tubeaxial | Auto Restart | 25.00mm | 25.3dB(A) | 0.96 W | CE, cURus, TUV | 3500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | IP68 - Dust Tight, Waterproof |
|
|
9A0824S4D01FAN AXIAL 80X25MM 24VDC WIRE |
94 | - |
|
数据表 |
San Cooler 80 | Box | Active | 24VDC | Square - 80mm L x 80mm H | 42.4 CFM (1.19m³/min) | 0.193 in H2O (48.1 Pa) | Ball | 0.199 lb (90.26 g) | Tubeaxial | Locked Rotor Sensor | 25.00mm | 34.0dB(A) | 2.4 W | CSA, TUV, UL | 3400 RPM | -4 ~ 158°F (-20 ~ 70°C) | 3 Wire Leads | - |
|
|
FFB0924VHE-R00FAN AXIAL 92X38MM 24VDC WIRE |
48 | - |
|
数据表 |
FFB | Bulk | Active | 24VDC | Square - 92mm L x 92mm H | 85.5 CFM (2.39m³/min) | 0.406 in H2O (101.1 Pa) | Ball | 0.437 lb (198.00 g) | Tubeaxial | Locked Rotor Sensor | 38.00mm | 47.5dB(A) | 6.72 W | CE, CSA, UL, VDE | 3800 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
9GA0612H701FAN AXIAL 60X15MM 12VDC WIRE |
73 | - |
|
数据表 |
San Ace 60 | Box | Active | 12VDC | Square - 60mm L x 60mm H | 19.7 CFM (0.552m³/min) | 0.223 in H2O (55.5 Pa) | Ball | 0.111 lb (50.35 g) | Tubeaxial | Speed Sensor (Tach) | 15.00mm | 34.0dB(A) | 1.2 W | CSA, TUV, UL | 4900 RPM | -4 ~ 158°F (-20 ~ 70°C) | 3 Wire Leads | - |
|
AFB1224SH-R00FAN AXIAL 120X25.4MM 24VDC WIRE |
83 | - |
|
数据表 |
AFB | Box | Active | 24VDC | Square - 120mm L x 120mm H | 113.1 CFM (3.17m³/min) | 0.430 in H2O (107.1 Pa) | Ball | 0.437 lb (198.00 g) | Tubeaxial | Locked Rotor Sensor | 25.40mm | 46.5dB(A) | 6.72 W | CE, CSA, UL, VDE | 3400 RPM | 14 ~ 140°F (-10 ~ 60°C) | 3 Wire Leads | - |
|
|
109R0624J4011FAN AXIAL 60X25MM 24VDC WIRE |
82 | - |
|
数据表 |
San Ace 60 | Box | Active | 24VDC | Square - 60mm L x 60mm H | 37.1 CFM (1.04m³/min) | 0.622 in H2O (155.0 Pa) | Ball | 0.199 lb (90.26 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 25.00mm | 44.0dB(A) | 5.76 W | CSA, TUV, UL | 7600 RPM | -4 ~ 140°F (-20 ~ 60°C) | 3 Wire Leads | - |
|
|
109R0812G4011FAN AXIAL 80X25MM 12VDC WIRE |
40 | - |
|
数据表 |
San Ace 80 | Box | Active | 12VDC | Square - 80mm L x 80mm H | 53.0 CFM (1.48m³/min) | 0.323 in H2O (80.4 Pa) | Ball | 0.243 lb (110.22 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 25.00mm | 40.0dB(A) | 4.44 W | CSA, TUV, UL | 4500 RPM | -4 ~ 140°F (-20 ~ 60°C) | 3 Wire Leads | - |
|
|
AFB1212LE-F00FAN AXIAL 120X38MM 12VDC WIRE |
72 | - |
|
数据表 |
AFB | Bulk | Active | 12VDC | Square - 120mm L x 120mm H | 84.8 CFM (2.37m³/min) | 0.180 in H2O (44.8 Pa) | Ball | 0.565 lb (256.28 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 38.00mm | 34.0dB(A) | 2.28 W | CE, CSA, UL, VDE | 2000 RPM | 14 ~ 140°F (-10 ~ 60°C) | 3 Wire Leads | - |
|
|
AFB1224VH-F00FAN AXIAL 120X25.4MM 24VDC WIRE |
29 | - |
|
数据表 |
AFB | Bulk | Active | 24VDC | Square - 120mm L x 120mm H | 103.7 CFM (2.90m³/min) | 0.371 in H2O (92.5 Pa) | Ball | 0.437 lb (198.00 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 25.40mm | 44.5dB(A) | 5.52 W | CE, CSA, UL, VDE | 3100 RPM | 14 ~ 140°F (-10 ~ 60°C) | 3 Wire Leads | - |
|
|
CHT8012BX-W38C12V 5.0A 80*38 BALL 4; 114.2CFM |
12 | - |
|
数据表 |
- | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
AFB1224VHE-F00FAN AXIAL 120X38MM 24VDC WIRE |
72 | - |
|
数据表 |
AFB | Bulk | Active | 24VDC | Square - 120mm L x 120mm H | 130.0 CFM (3.64m³/min) | 0.420 in H2O (104.6 Pa) | Ball | 0.565 lb (256.28 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 38.00mm | 48.0dB(A) | 9.12 W | CE, CSA, UL, VDE | 3200 RPM | 14 ~ 140°F (-10 ~ 60°C) | 3 Wire Leads | - |
|
|
11925SA-24P-AAD-0FAN AXIAL 119X25MM 24VDC WIRE |
38 | - |
|
数据表 |
11925SA | Bulk | Active | 24VDC | Square - 119mm L x 119mm H | 102.0 CFM (2.86m³/min) | 0.240 in H2O (59.8 Pa) | Ball | - | Tubeaxial | Auto Restart | 25.00mm | 40.5dB | 4.08 W | - | 2800 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
