固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
WLCM1005Z0J9N1TBINDUCTOR FIXED 9.1NH 0402 |
0 | - |
|
数据表 |
CM | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±5% | 500 mA | - | 0402 | Unshielded | 300mOhm Max | 9.1 nH | 8 @ 100MHz | 3.4GHz | Surface Mount | - | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - | -55°C ~ 125°C | 100 MHz | 0.024" (0.60mm) |
|
|
WLCM1005Z0S2N4TBINDUCTOR FIXED 2.4NH 0402 |
0 | - |
|
数据表 |
CM | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±0.3nH | 800 mA | - | 0402 | Unshielded | 130mOhm Max | 2.4 nH | 8 @ 100MHz | 10GHz | Surface Mount | - | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - | -55°C ~ 125°C | 100 MHz | 0.024" (0.60mm) |
|
|
WLCM1005Z0S2N2TBINDUCTOR FIXED 2.2NH 0402 |
0 | - |
|
数据表 |
CM | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±0.3nH | 900 mA | - | 0402 | Unshielded | 130mOhm Max | 2.2 nH | 8 @ 100MHz | 10GHz | Surface Mount | - | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - | -55°C ~ 125°C | 100 MHz | 0.024" (0.60mm) |
|
|
WLCM0603TGJ5N6TBINDUCTOR FIXED 5.6NH 0201 |
0 | - |
|
数据表 |
CM | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±5% | 300 mA | - | 0201 | Unshielded | 440mOhm Max | 5.6 nH | 12 @ 500MHz | 6GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
|
WLCM0603TGH8N2TBINDUCTOR FIXED 8.2NH 0201 |
0 | - |
|
数据表 |
CM | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±3% | 250 mA | - | 0201 | Unshielded | 620mOhm Max | 8.2 nH | 12 @ 500MHz | 4.8GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
|
WLCM0603TGH9N1TBINDUCTOR FIXED 9.1NH 0201 |
0 | - |
|
数据表 |
CM | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±3% | 250 mA | - | 0201 | Unshielded | 650mOhm Max | 9.1 nH | 12 @ 500MHz | 4.5GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
|
WLCM1005Z0G27NTBINDUCTOR FIXED 27NH 0402 |
0 | - |
|
数据表 |
CM | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±2% | 300 mA | - | 0402 | Unshielded | 800mOhm Max | 27 nH | 8 @ 100MHz | 1.7GHz | Surface Mount | - | 0.039" L x 0.020" W (1.00mm x 0.50mm) | - | -55°C ~ 125°C | 100 MHz | 0.024" (0.60mm) |
|
|
WLCM0603TGH5N6TBINDUCTOR FIXED 5.6NH 0201 |
0 | - |
|
数据表 |
CM | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±3% | 300 mA | - | 0201 | Unshielded | 440mOhm Max | 5.6 nH | 12 @ 500MHz | 6GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
|
WLCM0603TGH12NTBINDUCTOR FIXED 12NH 0201 |
0 | - |
|
数据表 |
CM | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±3% | 250 mA | - | 0201 | Unshielded | 750mOhm Max | 12 nH | 11 @ 500MHz | 3.7GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
|
WLCM0603TGH15NTBINDUCTOR FIXED 15NH 0201 |
0 | - |
|
数据表 |
CM | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±3% | 250 mA | - | 0201 | Unshielded | 850mOhm Max | 15 nH | 11 @ 500MHz | 3.1GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
|
WLCM0603TNH10NTBINDUCTOR FIXED 10NH 0201 |
0 | - |
|
数据表 |
CM | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±3% | 250 mA | - | 0201 | Unshielded | 700mOhm Max | 10 nH | 14 @ 500MHz | 3.2GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
|
WLCM0603TGH10NTBINDUCTOR FIXED 10NH 0201 |
0 | - |
|
数据表 |
CM | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±3% | 250 mA | - | 0201 | Unshielded | 700mOhm Max | 10 nH | 11 @ 500MHz | 4GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
|
WLCM0603TGH22NTBINDUCTOR FIXED 22NH 0201 |
0 | - |
|
数据表 |
CM | 0201 (0603 Metric) | Tape & Reel (TR) | Active | Multilayer | Ceramic | ±3% | 150 mA | - | 0201 | Unshielded | 1.2Ohm Max | 22 nH | 9 @ 500MHz | 2.5GHz | Surface Mount | - | 0.024" L x 0.012" W (0.60mm x 0.30mm) | - | -55°C ~ 125°C | 500 MHz | 0.013" (0.33mm) |
|
UP1B-6R8-RFIXED IND 6.8UH 1.7A 89.7MOHM SM |
677 | - |
|
数据表 |
UNI-PAC™ | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.7 A | 2.2A | - | Unshielded | 89.7mOhm Max | 6.8 µH | - | - | Surface Mount | - | 0.350" L x 0.240" W (8.89mm x 6.10mm) | - | -40°C ~ 85°C | 100 kHz | 0.197" (5.00mm) |
|
744787047FIXED IND 4.7UH 3.3A 29 MOHM SMD |
670 | - |
|
数据表 |
WE-PD2SR | 2-SMD | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 3.3 A | 3.6A | - | Shielded | 29mOhm Max | 4.7 µH | - | 42MHz | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.177" (4.50mm) |
|
|
744787012FIXED IND 1.2UH 4.85A 13MOHM SMD |
632 | - |
|
数据表 |
WE-PD2SR | 2-SMD | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 4.85 A | 6A | - | Shielded | 13mOhm Max | 1.2 µH | - | 110MHz | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.177" (4.50mm) |
|
|
744787121FIXED IND 120UH 730MA 643MOHM SM |
483 | - |
|
数据表 |
WE-PD2SR | 2-SMD | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 730 mA | 800mA | - | Shielded | 643mOhm Max | 120 µH | - | 4.5MHz | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.177" (4.50mm) |
|
|
744787180FIXED IND 18UH 2.15A 78 MOHM SMD |
387 | - |
|
数据表 |
WE-PD2SR | 2-SMD | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 2.15 A | 1.9A | - | Shielded | 78mOhm Max | 18 µH | - | 15MHz | Surface Mount | AEC-Q200 | 0.307" L x 0.276" W (7.80mm x 7.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.177" (4.50mm) |
|
SD7030-3R3-RFIXED IND 3.3UH 3.7A 24 MOHM SMD |
339 | - |
|
数据表 |
SD7030 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±30% | 3.7 A | 3A | - | Shielded | 24mOhm Max | 3.3 µH | - | - | Surface Mount | - | 0.276" L x 0.276" W (7.00mm x 7.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.118" (3.00mm) |
|
VCMI105T-220MS5FIXED IND 22UH 5.3A 69 MOHM SMD |
245 | - |
|
数据表 |
VCMI105T | Nonstandard | Tape & Reel (TR) | Active | - | Metal | ±3% | 5.3 A | 6.6A | - | Unshielded | 69mOhm Max | 22 µH | - | - | Surface Mount | - | 0.427" L x 0.394" W (10.85mm x 10.00mm) | - | -55°C ~ 155°C | 100 kHz | 0.197" (5.00mm) |
