固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SDR6603-221MFIXED IND 220UH 200MA 3.2OHM SMD Bourns Inc. |
520 | - |
|
数据表 |
SDR6603 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 200 mA | 220mA | - | Unshielded | 3.2Ohm Max | 220 µH | 33 @ 796kHz | 5.5MHz | Surface Mount | - | 0.260" L x 0.175" W (6.60mm x 4.45mm) | - | -40°C ~ 125°C | 100 kHz | 0.115" (2.92mm) |
|
SRR1206-331KLFIXED IND 330UH 600MA 660MOHM SM Bourns Inc. |
670 | - |
|
数据表 |
SRR1206 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 600 mA | 1A | - | Shielded | 660mOhm Max | 330 µH | 11 @ 796kHz | 3MHz | Surface Mount | - | 0.500" L x 0.500" W (12.70mm x 12.70mm) | - | -40°C ~ 125°C | 1 kHz | 0.256" (6.50mm) |
|
SRR1205-221KLFIXED IND 220UH 650MA 840MOHM SM Bourns Inc. |
662 | - |
|
数据表 |
SRR1205 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 650 mA | 1.3A | - | Shielded | 840mOhm Max | 220 µH | 9 @ 796kHz | 3MHz | Surface Mount | - | 0.500" L x 0.500" W (12.70mm x 12.70mm) | - | -40°C ~ 125°C | 1 kHz | 0.217" (5.50mm) |
|
SRR1005-220YFIXED IND 22UH 1.4A 100 MOHM SMD Bourns Inc. |
642 | - |
|
数据表 |
SRR1005 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±15% | 1.4 A | 1.9A | - | Shielded | 100mOhm Max | 22 µH | 42 @ 2.52MHz | 18MHz | Surface Mount | - | 0.500" L x 0.394" W (12.70mm x 10.00mm) | - | -40°C ~ 125°C | 1 kHz | 0.205" (5.20mm) |
|
|
SRR1206-180MLFIXED IND 18UH 2.5A 50 MOHM SMD Bourns Inc. |
636 | - |
|
数据表 |
SRR1206 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 2.5 A | 4.7A | - | Shielded | 50mOhm Max | 18 µH | 19 @ 2.52MHz | 14MHz | Surface Mount | - | 0.500" L x 0.500" W (12.70mm x 12.70mm) | - | -40°C ~ 125°C | 1 kHz | 0.256" (6.50mm) |
|
|
SRR1206-122KLFIXED IND 1.2MH 250MA 2.65OHM SM Bourns Inc. |
97 | - |
|
数据表 |
SRR1206 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 250 mA | 510mA | - | Shielded | 2.65Ohm Max | 1.2 mH | 10 @ 252kHz | 1.5MHz | Surface Mount | - | 0.500" L x 0.500" W (12.70mm x 12.70mm) | - | -40°C ~ 125°C | 1 kHz | 0.256" (6.50mm) |
|
9230-58-RCFIXED IND 39UH 180MA 3.6 OHM TH Bourns Inc. |
1,000 | - |
|
数据表 |
9230 | Axial | Bulk | Active | Molded | Ferrite | ±10% | 180 mA | - | - | Unshielded | 3.6Ohm Max | 39 µH | 45 @ 2.5MHz | 22MHz | Through Hole | - | 0.095" Dia x 0.250" L (2.41mm x 6.35mm) | - | -55°C ~ 125°C | 2.5 MHz | - |
|
|
9230-74-RCFIXED IND 180UH 79MA 17 OHM TH Bourns Inc. |
1,000 | - |
|
数据表 |
9230 | Axial | Bulk | Active | Molded | Ferrite | ±10% | 79 mA | - | - | Unshielded | 17Ohm Max | 180 µH | 30 @ 790kHz | 10MHz | Through Hole | - | 0.095" Dia x 0.250" L (2.41mm x 6.35mm) | - | -55°C ~ 125°C | 790 kHz | - |
|
9250A-151-RCFIXED IND 150NH 1.47A 37 MOHM TH Bourns Inc. |
930 | - |
|
数据表 |
9250A | Axial | Bulk | Active | Molded | Ferrite | ±10% | 1.47 A | 1.47A | - | Shielded | 37mOhm Max | 150 nH | 51 @ 25MHz | 250MHz | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - | -55°C ~ 125°C | 25 MHz | - |
|
|
SRR1206-221KLFIXED IND 220UH 700MA 460MOHM SM Bourns Inc. |
72 | - |
|
数据表 |
SRR1206 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±10% | 700 mA | 1.2A | - | Shielded | 460mOhm Max | 220 µH | 11 @ 796kHz | 4MHz | Surface Mount | - | 0.500" L x 0.500" W (12.70mm x 12.70mm) | - | -40°C ~ 125°C | 1 kHz | 0.256" (6.50mm) |
