直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CFM-9225C-230-356-22FAN AXIAL 92X25MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-92C | Box | Active | 24VDC | Square - 92mm L x 92mm H | 50.0 CFM (1.40m³/min) | 0.150 in H2O (37.3 Pa) | omniCOOL™ Magnetic Sleeve | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 25.00mm | 35.6dB(A) | 3.6 W | CE, cURus, TUV | 3000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
CFM-9225C-225-317-22FAN AXIAL 92X25MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-92C | Box | Active | 24VDC | Square - 92mm L x 92mm H | 41.7 CFM (1.17m³/min) | 0.110 in H2O (27.4 Pa) | omniCOOL™ Magnetic Sleeve | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 25.00mm | 31.7dB(A) | 1.92 W | CE, cURus, TUV | 2500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
CBM-5015BF-165-428-22DC BLOWER, 51.7 X 51.25 X 14.9 M |
0 | - |
|
数据表 |
CBM-50BF | Box | Active | 12VDC | Rectangular/Rounded - 51.6mm L x 51.2mm H | 4.1 CFM (0.115m³/min) | 0.930 in H2O (231.7 Pa) | Ball | - | Blower | Auto Restart, PWM Control, Speed Sensor (Tach) | 15.00mm | 42.8dB(A) | 2.16 W | CE, cURus, TUV | 6500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
CFM-6025BF-175-439-20FAN AXIAL 60X25.4MM 12VDC WIRE |
0 | - |
|
数据表 |
CFM-60BF | Box | Active | 12VDC | Square - 60mm L x 60mm H | 35.9 CFM (1.01m³/min) | 0.500 in H2O (124.5 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 25.40mm | 44.0dB(A) | 6.48 W | CE, cURus, TUV | 7500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
DC0501512U2B-3T0FAN AXIAL 50X15MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 50mm L x 50mm H | - | - | Ball | 0.084 lb (38.1 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 15.00mm | - | - | CE, cURus, TUV | - | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
DC0701512H2B-3T0FAN AXIAL 70X15MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 70mm L x 70mm H | 33.5 CFM (0.938m³/min) | 0.220 in H2O (54.8 Pa) | Ball | 0.32 lb (145.15 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 15.00mm | 39.0dB(A) | 3 W | CE, cURus, TUV | 4300 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
DC0701512M2B-3T0FAN AXIAL 70X15MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 70mm L x 70mm H | 29.6 CFM (0.829m³/min) | 0.170 in H2O (42.3 Pa) | Ball | 0.32 lb (145.15 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 15.00mm | 35.0dB(A) | 2.04 W | CE, cURus, TUV | 3800 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
DC0602012M2B-3T0FAN AXIAL 60X20MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 60mm L x 60mm H | 16.4 CFM (0.459m³/min) | 0.190 in H2O (47.3 Pa) | Ball | 0.111 lb (50.35 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 20.00mm | 29.0dB(A) | 1.32 W | CE, cURus, TUV | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
DC0601512U2B-3T0FAN AXIAL 60X15MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 60mm L x 60mm H | 26.5 CFM (0.742m³/min) | 0.230 in H2O (57.3 Pa) | Ball | 0.098 lb (44.45 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 15.00mm | 37.0dB(A) | 2.04 W | CE, cURus, TUV | 5000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
DC0601012M2B-3T0FAN AXIAL 60X10.5MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 60mm L x 60mm H | 17.1 CFM (0.479m³/min) | 0.120 in H2O (29.9 Pa) | Ball | 0.089 lb (40.37 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 10.50mm | 33.0dB(A) | 2.04 W | CE, cURus, TUV | 4200 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
DC0602012U2B-3T0FAN AXIAL 60X20MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 60mm L x 60mm H | 19.6 CFM (0.549m³/min) | 0.270 in H2O (67.3 Pa) | Ball | 0.111 lb (50.35 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 20.00mm | 33.0dB(A) | 2.04 W | CE, cURus, TUV | 4800 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
DC0602012H2B-3T0FAN AXIAL 60X20MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 60mm L x 60mm H | 18.1 CFM (0.507m³/min) | 0.230 in H2O (57.3 Pa) | Ball | 0.111 lb (50.35 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 20.00mm | 31.0dB(A) | 1.56 W | CE, cURus, TUV | 4400 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
DC0502012H2B-3T0FAN AXIAL 50X20MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 50mm L x 50mm H | 20.3 CFM (0.568m³/min) | 0.300 in H2O (74.7 Pa) | Ball | 0.089 lb (40.37 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 20.00mm | 38.0dB(A) | 2.52 W | CE, cURus, TUV | 7000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
DC0601012U2B-3T0FAN AXIAL 60X10.5MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 60mm L x 60mm H | 19.9 CFM (0.557m³/min) | 0.160 in H2O (39.8 Pa) | Ball | 0.089 lb (40.37 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 10.50mm | 37.0dB(A) | 2.4 W | CE, cURus, TUV | 4900 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
DC0502012M2B-3T0FAN AXIAL 50X20MM 12VDC WIRE |
0 | - |
|
数据表 |
- | Box | Active | 12VDC | Square - 50mm L x 50mm H | 17.6 CFM (0.493m³/min) | 0.250 in H2O (62.3 Pa) | Ball | 0.089 lb (40.37 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 20.00mm | 36.0dB(A) | 2.52 W | CE, cURus, TUV | 6400 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
DC0601024U2B-2T0FAN 60X10MM 24VDC |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 19.9 CFM (0.557m³/min) | 0.160 in H2O (39.8 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection | 10.50mm | 37.0dB(A) | 4.8 W | CE, cURus | 4900 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
DC0701524H2B-2T0FAN 70X15MM 24VDC |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Square - 70mm L x 70mm H | 33.5 CFM (0.938m³/min) | 0.220 in H2O (54.8 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection | 15.00mm | 39.0dB(A) | 6 W | CE, cURus | 4300 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
DC0601005U2B-2T0FAN 60X10MM 5VDC |
0 | - |
|
数据表 |
- | Bulk | Active | 5VDC | Square - 60mm L x 60mm H | 19.9 CFM (0.557m³/min) | 0.160 in H2O (39.8 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection | 10.50mm | 37.0dB(A) | 1 W | CE, cURus | 4900 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
DC0602024H2B-2T0FAN 60X20MM 24VDC |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 18.1 CFM (0.507m³/min) | 0.230 in H2O (57.3 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection | 20.00mm | 31.0dB(A) | 2.88 W | CE, cURus | 4400 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
DC0601024M2B-2T0FAN 60X10MM 24VDC |
0 | - |
|
数据表 |
- | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 17.1 CFM (0.479m³/min) | 0.120 in H2O (29.9 Pa) | Ball | - | Tubeaxial | Locked Rotor Protection | 10.50mm | 33.0dB(A) | 4.08 W | CE, cURus | 4200 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
