直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
OD1238-12HBVXE10AFAN 12VDC 120X38MM PWM/TACH Orion Fans |
33 | - |
|
数据表 |
OD1238 | Box | Active | 12VDC | Square - 120mm L x 120mm H | 235.5 CFM (6.59m³/min) | 1.600 in H2O (398.6 Pa) | Ball | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 38.00mm | 60.6dB(A) | 46.3 W | CE, cURus, TUV, UR | 4925 RPM | -4 ~ 149°F (-20 ~ 65°C) | 4 Wire Leads | - |
|
|
OD1238-24HBVXE10AFAN 24VDC 120X38MM PWM/TACH Orion Fans |
21 | - |
|
数据表 |
OD1238 | Box | Active | 24VDC | Square - 120mm L x 120mm H | 235.5 CFM (6.59m³/min) | 1.600 in H2O (398.6 Pa) | Ball | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 38.00mm | 60.4dB(A) | 46.3 W | CE, cURus, TUV, UR | 4925 RPM | -4 ~ 149°F (-20 ~ 65°C) | 4 Wire Leads | - |
|
|
OD1238-48HBVXEFAN AXIAL 120X38MM 48VDC WIRE Orion Fans |
58 | - |
|
数据表 |
OD1238 | Box | Active | 48VDC | Square - 120mm L x 120mm H | 235.5 CFM (6.59m³/min) | 1.600 in H2O (398.6 Pa) | Ball | - | Tubeaxial | Auto Restart | 38.00mm | 60.6dB(A) | 45.1 W | CE, cURus, TUV, UR | 4925 RPM | -4 ~ 149°F (-20 ~ 65°C) | 2 Wire Leads | - |
|
|
OD1238-12MBVXE10AFAN 12VDC 120X38MM PWM/TACH Orion Fans |
37 | - |
|
数据表 |
OD1238 | Box | Active | 12VDC | Square - 120mm L x 120mm H | 215.0 CFM (6.02m³/min) | 1.300 in H2O (323.6 Pa) | Ball | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 38.00mm | 58.2dB(A) | 34.2 W | CE, cURus, TUV, UR | 4450 RPM | -4 ~ 149°F (-20 ~ 65°C) | 4 Wire Leads | - |
|
|
OD1238-48H3BVXE10AFAN 48VDC 120X38MM PWM/TACH Orion Fans |
22 | - |
|
数据表 |
OD1238 | Box | Active | 48VDC | Square - 120mm L x 120mm H | 285.2 CFM (7.99m³/min) | 2.300 in H2O (572.9 Pa) | Ball | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 38.00mm | 64.6dB(A) | 77.7 W | CE, cURus, TUV, UR | 5980 RPM | -4 ~ 149°F (-20 ~ 65°C) | 4 Wire Leads | - |
|
OD3010-12LBFAN AXIAL 30X10.2MM 12VDC WIRE Orion Fans |
0 | - |
|
数据表 |
OD3010 | Bulk | Active | 12VDC | Square - 30mm L x 30mm H | 3.5 CFM (0.098m³/min) | 0.210 in H2O (52.3 Pa) | Ball | - | Tubeaxial | - | 10.20mm | 23.1dB(A) | - | cURus, TUV | 8000 RPM | -4 ~ 149°F (-20 ~ 65°C) | 2 Wire Leads | - |
|
OD172SAP-48HTBFAN AXIAL 172X51MM 48VDC TERM Orion Fans |
10 | - |
|
数据表 |
OD172SAP | Bulk | Active | 48VDC | Rectangular/Rounded - 172mm L x 150mm H | 235.0 CFM (6.58m³/min) | 0.770 in H2O (191.8 Pa) | Ball | - | Tubeaxial | Auto Restart | 51.00mm | 52.0dB(A) | 24 W | CE, cURus, TUV, UR | 3200 RPM | -13 ~ 149°F (-25 ~ 65°C) | 2 Terminals | - |
|
OD172SAP-48HHTB01AFAN AXIAL 172X51MM 48VDC TERM Orion Fans |
22 | - |
|
数据表 |
OD172SAP | Bulk | Active | 48VDC | Rectangular/Rounded - 172mm L x 150mm H | 300.0 CFM (8.40m³/min) | 0.950 in H2O (237.0 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 51.00mm | 56.0dB(A) | 49.4 W | CE, cURus, TUV, UR | 3850 RPM | -13 ~ 149°F (-25 ~ 65°C) | 3 Terminals | - |
|
OD1225-24LBFAN AXIAL 120X25MM 24VDC WIRE Orion Fans |
0 | - |
|
数据表 |
OD1225 | Box | Active | 24VDC | Square - 120mm L x 120mm H | 70.0 CFM (1.96m³/min) | 0.150 in H2O (37.3 Pa) | Ball | 0.341 lb (154.67 g) | Tubeaxial | Auto Restart | 25.00mm | 25.0dB(A) | 2.4 W | CE, cURus, TUV, UR | 1900 RPM | -4 ~ 149°F (-20 ~ 65°C) | 2 Wire Leads | - |
|
OD254AP-48LTBFAN AXIAL 254X89MM 48VDC TERM Orion Fans |
14 | - |
|
数据表 |
OD254AP | Bulk | Active | 48VDC | Round - 254mm Dia | 550.0 CFM (15.40m³/min) | 0.370 in H2O (92.2 Pa) | Ball | - | Tubeaxial | Auto Restart | 89.00mm | 39.4dB(A) | 24 W | CE, cURus, TUV, UR | 1650 RPM | -4 ~ 149°F (-20 ~ 65°C) | 2 Terminals | - |
