直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
9HV0848G10021FAN AXIAL 80X38MM 48VDC WIRE |
0 | - |
|
数据表 |
San Ace 80 | Box | Active | 48VDC | Square - 80mm L x 80mm H | 130.7 CFM (3.66m³/min) | 4.000 in H2O (996.3 Pa) | Ball | 0.508 lb (230.42 g) | Tubeaxial | Locked Rotor Protection | 38.00mm | 69.0dB(A) | 40.8 W | CSA, TUV, UL | 14900 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
11938MA-48P-EA-D0FAN AXIAL 119X38.4MM 48VDC WIRE |
0 | - |
|
数据表 |
11938MA | Box | Obsolete | 48VDC | Square - 119mm L x 119mm H | - | - | Ball | - | Tubeaxial | Auto Restart | 38.40mm | - | - | - | - | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | IP69K - Dust Tight, High Temp Water Jets, Waterproof |
|
|
11938MA-12N-EA-D0FAN AXIAL 119X38.4MM 12VDC WIRE |
0 | - |
|
数据表 |
11938MA | Box | Obsolete | 12VDC | Square - 119mm L x 119mm H | 162.1 CFM (4.59m³/min) | 0.690 in H2O (171.8 Pa) | Ball | - | Tubeaxial | Auto Restart | 38.40mm | 56.5dB(A) | 17.5 W | - | 4200 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | IP69K - Dust Tight, High Temp Water Jets, Waterproof |
|
|
11938MA-12M-EA-D0FAN AXIAL 119X38.4MM 12VDC WIRE |
0 | - |
|
数据表 |
11938MA | Box | Obsolete | 12VDC | Square - 119mm L x 119mm H | 142.0 CFM (3.98m³/min) | 0.550 in H2O (137.0 Pa) | Ball | - | Tubeaxial | Auto Restart | 38.40mm | 53.5dB(A) | 12 W | - | 3700 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | IP69K - Dust Tight, High Temp Water Jets, Waterproof |
|
|
11938MA-24L-EA-D0FAN AXIAL 119X38.4MM 24VDC WIRE |
0 | - |
|
数据表 |
11938MA | Box | Obsolete | 24VDC | Square - 119mm L x 119mm H | 122.2 CFM (3.46m³/min) | 0.410 in H2O (102.1 Pa) | Ball | - | Tubeaxial | Auto Restart | 38.40mm | 49.5dB(A) | 8.4 W | - | 3200 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | IP69K - Dust Tight, High Temp Water Jets, Waterproof |
|
|
11938MA-24M-EA-D0FAN AXIAL 119X38.4MM 24VDC WIRE |
0 | - |
|
数据表 |
11938MA | Box | Obsolete | 24VDC | Square - 119mm L x 119mm H | 142.0 CFM (3.98m³/min) | 0.550 in H2O (137.0 Pa) | Ball | - | Tubeaxial | Auto Restart | 38.40mm | 53.5dB(A) | 12.5 W | - | 3700 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | IP69K - Dust Tight, High Temp Water Jets, Waterproof |
|
|
3312N/2NFAN AXIAL 92X32MM 12VDC WIRE |
0 | - |
|
数据表 |
3300N | Bulk | Active | 12VDC | Square - 92mm L x 92mm H | 47.1 CFM (1.32m³/min) | 0.201 in H2O (50.1 Pa) | Ball | - | Tubeaxial | Speed Sensor (Tach) | 32.00mm | 33.0dB(A) | 1.8 W | CE, CSA, EAC, UL, VDE | 2650 RPM | -4 ~ 167°F (-20 ~ 75°C) | 3 Wire Leads | - |
|
|
3318N/2NDC TUBEAXIAL FAN |
0 | - |
|
数据表 |
3300N | Bulk | Active | 48VDC | Square - 92mm L x 92mm H | 47.1 CFM (1.32m³/min) | 0.201 in H2O (50.1 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 32.00mm | 33.0dB(A) | 1.8 W | CCC, CSA, CE, EAC, VDE, UL | 2650 RPM | -4 ~ 167°F (-20 ~ 75°C) | 3 Wire Leads | - |
|
|
9GV1248J1D01FAN AXIAL 120X38MM 48VDC WIRE |
0 | - |
|
数据表 |
San Ace 120 | Box | Active | 48VDC | Square - 120mm L x 120mm H | 224.0 CFM (6.27m³/min) | 1.450 in H2O (361.2 Pa) | Ball | 0.794 lb (360.15 g) | Tubeaxial | Locked Rotor Sensor | 38.00mm | 64.0dB(A) | 36 W | CSA, TUV, UL | 6400 RPM | -4 ~ 158°F (-20 ~ 70°C) | 3 Wire Leads | - |
|
|
9GV1248J101FAN AXIAL 120X38MM 48VDC WIRE |
0 | - |
|
数据表 |
San Ace 120 | Box | Active | 48VDC | Square - 120mm L x 120mm H | - | - | Ball | 0.794 lb (360.15 g) | Tubeaxial | Speed Sensor (Tach) | 38.00mm | - | 36 W | CSA, TUV, UL | - | - | 3 Wire Leads | - |
|
|
9GV1248J1011FAN AXIAL 120X38MM 48VDC WIRE |
0 | - |
|
数据表 |
San Ace 120 | Box | Active | 48VDC | Square - 120mm L x 120mm H | 224.0 CFM (6.27m³/min) | 1.450 in H2O (361.2 Pa) | Ball | 0.794 lb (360.15 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 38.00mm | 64.0dB(A) | 36 W | CSA, TUV, UL | 6400 RPM | -4 ~ 158°F (-20 ~ 70°C) | 3 Wire Leads | - |
|
4412MLFAN AXIAL 119X38MM 12VDC WIRE |
0 | - |
|
数据表 |
4400 | Bulk | Obsolete | 12VDC | Square - 119mm L x 119mm H | 99.0 CFM (2.77m³/min) | - | Ball | 0.604 lb (273.97 g) | Tubeaxial | - | 38.00mm | 46.0dB(A) | 3 W | - | 3000 RPM | -4 ~ 176°F (-20 ~ 80°C) | 2 Wire Leads | IP54 - Dust Protected, Water Resistant |
|
|
4418LFAN AXIAL 119X38MM 48VDC WIRE |
0 | - |
|
数据表 |
4400 | Bulk | Active | 48VDC | Square - 119mm L x 119mm H | 88.4 CFM (2.47m³/min) | - | Ball | 0.553 lb (250.84 g) | Tubeaxial | Locked Rotor Protection | 38.00mm | 37.0dB(A) | 2.5 W | - | 2700 RPM | -4 ~ 167°F (-20 ~ 75°C) | 2 Wire Leads | - |
|
CFM-A751BF-235-533-20FAN AXIAL 172X51.5MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-A7BF | Box | Active | 24VDC | Rectangular/Rounded - 172mm L x 151.5mm H | 252.9 CFM (7.08m³/min) | 0.650 in H2O (161.9 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 51.50mm | 53.3dB(A) | 24.24 W | CE, cURus, TUV | 3500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
19040215AFAN AXIAL 127X38.1MM 12V GL12S7Z |
0 | - |
|
数据表 |
Galaxy | Box | Active | 12VDC | Square - 127mm L x 127mm H | 190.0 CFM (5.32m³/min) | - | Ball | - | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 38.10mm | 58.9dB(A) | 30 W | CE, UL | 4150 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
9HV0848G1D001FAN AXIAL 80X38MM 48VDC WIRE |
0 | - |
|
数据表 |
San Ace 80 | Box | Active | 48VDC | Square - 80mm L x 80mm H | 130.7 CFM (3.66m³/min) | 4.000 in H2O (996.3 Pa) | Ball | 0.508 lb (230.42 g) | Tubeaxial | Locked Rotor Sensor | 38.00mm | 69.0dB(A) | 40.8 W | CSA, TUV, UL | 14900 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
9HV0848G1001FAN AXIAL 80X38MM 48VDC WIRE |
0 | - |
|
数据表 |
San Ace 80 | Box | Active | 48VDC | Square - 80mm L x 80mm H | 130.7 CFM (3.66m³/min) | 4.000 in H2O (996.3 Pa) | Ball | 0.508 lb (230.42 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 38.00mm | 69.0dB(A) | 40.8 W | CSA, TUV, UL | 14900 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
9HV0848G10011FAN AXIAL 80X38MM 48VDC WIRE |
0 | - |
|
数据表 |
San Ace 80 | Box | Active | 48VDC | Square - 80mm L x 80mm H | 130.7 CFM (3.66m³/min) | 4.000 in H2O (996.3 Pa) | Ball | 0.508 lb (230.42 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 38.00mm | 69.0dB(A) | 40.8 W | CSA, TUV, UL | 14900 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
GE80254B1-000U-AE9FAN AXIAL 80X25MM 48VDC WIRE |
0 | - |
|
数据表 |
GE | Bulk | Obsolete | 48VDC | Square - 80mm L x 80mm H | 60.0 CFM (1.68m³/min) | 0.410 in H2O (102.1 Pa) | Ball | 0.231 lb (104.78 g) | Tubeaxial | Auto Restart | 25.00mm | 47.5dB(A) | 5.48 W | CE, CUR, TUV, UL | 4800 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | IP68 - Dust Tight, Waterproof |
|
|
9GV1248P1J011FAN AXIAL 120X38MM 48VDC WIRE |
0 | - |
|
数据表 |
San Ace 120 | Box | Active | 48VDC | Square - 120mm L x 120mm H | 224.0 CFM (6.27m³/min) | 1.450 in H2O (361.2 Pa) | Ball | 0.794 lb (360.15 g) | Tubeaxial | PWM Control, Speed Sensor (Tach) | 38.00mm | 64.0dB(A) | 36 W | CSA, TUV, UL | 6400 RPM | -4 ~ 158°F (-20 ~ 70°C) | 4 Wire Leads | - |
