交流直流转换器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 功率(瓦特) | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输入 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 6 | 电流 - 输出 2 | 应用 | 电流 - 输出 5 | 电流 - 输出 3 | 电流 - 输出 4 | 电压 - 隔离 | 效率 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 | 认证机构 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LM1301-9RGAC/DC CONVERTER 12V 50W |
6 | - |
|
数据表 |
Melcher M (50W) | Bulk | Active | Enclosed, Conformal Coated | 1 | 12V | - | - | 50W | - | - | 85 ~ 264 VAC | - | 4 A | - | - | ITE (Commercial), Railway | - | - | - | 2.8 kV | -40°C ~ 71°C (With Derating) | Adjustable Output, DC Input Capable, Remote On/Off, Remote Sense, Universal Input | Chassis Mount | 6.60" L x 4.37" W x 1.54" H (168.0mm x 111.0mm x 39.0mm) | ||
|
85676EMPARRO67 HYBRID POWER SUPPLY 1- |
4 | - |
|
数据表 |
- | Box | Active | Enclosed | 2 | 24V | 24V | - | 480W | - | - | 90 ~ 265 VAC, 90 ~ 265 VDC | - | 10 A | - | 10 A | Laboratory | - | - | - | - | -25°C ~ 80°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.50" L x 4.33" W x 2.09" H (216.0mm x 110.0mm x 53.0mm) | ||
|
NCP-3200-024O/P +24V133A |
8 | - |
|
数据表 |
NCP-3200 (3.2kW) | Box | Active | Enclosed | 1 | 24V | - | - | 3.192kW | - | - | 90 ~ 264 VAC, 127 ~ 400 VDC | - | 133 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, PMBus™, Remote On/Off, Remote Sense, Universal Input | Rack Mount | 12.83" L x 4.21" W x 1.61" H (325.8mm x 107.0mm x 41.0mm) | ||
|
|
HWS600-12/PVAC/DC CONVERTER 12V 600W |
5 | - |
|
数据表 |
HWS (600W) | Bulk | Active | Enclosed, Conformal Coated | 1 | 12V | - | - | 600W | - | - | 85 ~ 265 VAC | - | 53 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, Remote On/Off, Universal Input | Chassis Mount | 6.50" L x 3.94" W x 3.23" H (165.1mm x 100.0mm x 82.0mm) | ||
|
|
HWS600-24/PVAC/DC CONVERTER 24V 600W |
2 | - |
|
数据表 |
HWS (600W) | Bulk | Active | Enclosed, Conformal Coated | 1 | 24V | - | - | 600W | - | - | 85 ~ 265 VAC | - | 27 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, Remote On/Off, Universal Input | Chassis Mount | 6.50" L x 3.94" W x 3.23" H (165.1mm x 100.0mm x 82.0mm) | ||
|
|
HWS600-48/PVAC/DC CONVERTER 48V 600W |
2 | - |
|
数据表 |
HWS (600W) | Bulk | Active | Enclosed, Conformal Coated | 1 | 48V | - | - | 600W | - | - | 85 ~ 265 VAC | - | 13 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, Remote On/Off, Universal Input | Chassis Mount | 6.50" L x 3.94" W x 3.23" H (165.1mm x 100.0mm x 82.0mm) | ||
|
|
HWS600-12/MEAC/DC CONVERTER 12V 600W |
3 | - |
|
数据表 |
HWS/ME (600W) | Bulk | Active | Enclosed | 1 | 12V | - | - | 600W | - | - | 85 ~ 265 VAC | - | 53 A | - | - | ITE (Commercial), Medical | - | - | - | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, Remote On/Off, Universal Input | Chassis Mount | 6.50" L x 3.94" W x 3.23" H (165.1mm x 100.1mm x 82.0mm) | ||
|
MCC750-1T24AC/DC CONVERTER 24V 756W |
18 | - |
|
数据表 |
MCC750 (750W) | Bulk | Active | Open Frame | 1 | 24V | - | - | 756W | - | - | 85 ~ 305 VAC, 120 ~ 300 VDC | - | 31.5 A | - | - | Medical | - | - | - | 4 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Remote Sense, Universal Input | Chassis Mount | 9.21" L x 4.00" W x 1.61" H (234.0mm x 101.6mm x 41.0mm) | ||
|
MBE1200-1T48AC/DC CONVERTER 48V 1200W |
10 | - |
|
数据表 |
MBE1200 (1200W) | Bulk | Active | Enclosed | 1 | 48V | - | - | 1200W | - | - | 85 ~ 305 VAC, 120 ~ 300 VDC | - | 25 A | - | - | Medical | - | - | - | 4 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Remote Sense, Universal Input | Chassis Mount | 10.30" L x 4.00" W x 1.61" H (261.6mm x 101.6mm x 41.0mm) | ||
|
ABE1200-1T24AC/DC CONVERTER 24V 1200W |
6 | - |
|
数据表 |
ABE1200 (1200W) | Box | Active | Enclosed | 1 | 24V | - | - | 1200W | - | - | 85 ~ 305 VAC, 120 ~ 300 VDC | - | 50 A | - | - | ITE (Commercial) | - | - | - | 4 kV | -20°C ~ 60°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Remote Sense, Universal Input | Chassis Mount | 10.30" L x 4.00" W x 1.61" H (261.6mm x 101.6mm x 41.0mm) | ||
|
85677EMPARRO67 HYBRID 10-100-240/24 7 |
2 | - |
|
数据表 |
- | Box | Active | Enclosed | 2 | 24V | 24V | - | 480W | - | - | 90 ~ 265 VAC, 90 ~ 265 VDC | - | 10 A | - | 10 A | Laboratory | - | - | - | - | -25°C ~ 80°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.50" L x 4.33" W x 2.09" H (216.0mm x 110.0mm x 53.0mm) | ||
|
PES2200-12-080RAAC/DC CONVERTER 12V 2196W |
9 | - |
|
数据表 |
PES2200 (2200W) | Box | Active | Front End | 1 | 12V | - | - | 2196W | - | - | 90 ~ 140 VAC, 180 ~ 264 VAC, 180 ~ 300 VDC | - | 183 A | - | - | ITE (Commercial) | - | - | - | 4.242 kV | 0°C ~ 55°C | Adjustable Output, Load Sharing, PFC, Remote Sense, Standby Output | Rack Mount | 7.68" L x 3.15" W x 1.57" H (195.0mm x 80.0mm x 40.0mm) | ||
|
TEC2600-12-074NAAC/DC CONVERTER 12V 2556W |
9 | - |
|
数据表 |
TEC2600 (2600W) | Box | Active | Front End | 1 | 12V | - | - | 2556W | - | - | 90 ~ 264 VAC, 180 ~ 300 VDC | - | 213 A | - | - | ITE (Commercial) | - | - | - | 3 kV | 0°C ~ 50°C | Adjustable Output, DC Input Capable, Load Sharing, Remote On/Off, Remote Sense, Universal Input | Rack Mount | 7.28" L x 2.89" W x 1.57" H (185.0mm x 73.5mm x 40.0mm) | ||
|
LM1501-9RGAC/DC CONVERTER 15V 50W |
4 | - |
|
数据表 |
Melcher M (50W) | Bulk | Active | Enclosed, Conformal Coated | 1 | 15V | - | - | 50W | - | - | 85 ~ 264 VAC | - | 3.4 A | - | - | ITE (Commercial), Railway | - | - | - | 2.8 kV | -40°C ~ 71°C (With Derating) | Adjustable Output, DC Input Capable, Remote On/Off, Remote Sense, Universal Input | Chassis Mount | 6.60" L x 4.37" W x 1.54" H (168.0mm x 111.0mm x 39.0mm) | ||
|
|
HWS600P-36AC/DC CONVERTER 36V 600W |
3 | - |
|
数据表 |
HWSP600P (600W) | Bulk | Active | Enclosed, Conformal Coated | 1 | 36V | - | - | 600W | - | - | 85 ~ 265 VAC | - | 16.7 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, Remote On/Off, Universal Input | Chassis Mount | 6.50" L x 3.94" W x 3.23" H (165.1mm x 100.1mm x 82.0mm) | ||
|
|
HWS600P-24AC/DC CONVERTER 24V 600W |
2 | - |
|
数据表 |
HWSP600P (600W) | Bulk | Active | Enclosed, Conformal Coated | 1 | 24V | - | - | 600W | - | - | 85 ~ 265 VAC | - | 25 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, Remote On/Off, Universal Input | Chassis Mount | 6.50" L x 3.94" W x 3.23" H (165.1mm x 100.1mm x 82.0mm) | ||
|
LM1601-9RGAC/DC CONVERTER 24V 50W |
9 | - |
|
数据表 |
Melcher M (50W) | Bulk | Active | Enclosed, Conformal Coated | 1 | 24V | - | - | 50W | - | - | 85 ~ 264 VAC | - | 2 A | - | - | ITE (Commercial), Railway | - | - | - | 2.8 kV | -40°C ~ 71°C (With Derating) | Adjustable Output, DC Input Capable, Remote On/Off, Remote Sense, Universal Input | Chassis Mount | 6.60" L x 4.37" W x 1.54" H (168.0mm x 111.0mm x 39.0mm) | ||
|
HFE1600-32AC/DC CONVERTER 32V 1600W |
7 | - |
|
数据表 |
HFE1600 (1600W) | Bulk | Active | Front End | 1 | 32V | - | - | 1600W | - | - | 85 ~ 265 VAC | - | 47 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -20°C ~ 71°C (With Derating) | Adjustable Output, Load Sharing, Remote On/Off, Remote Sense, Universal Input | Rack Mount | 12.61" L x 3.40" W x 1.61" H (320.4mm x 86.2mm x 40.8mm) | ||
|
PFC375-1024GAC/DC CONVERTER 24V 375W |
17 | - |
|
数据表 |
PFC375 (375W) | Bulk | Active | Enclosed | 1 | 24V | - | - | 375W | - | - | 85 ~ 264 VAC | - | 15 A | - | - | ITE (Commercial) | - | - | - | 2.6 kV | 0°C ~ 70°C (With Derating) | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input | Chassis Mount | 9.00" L x 5.00" W x 2.50" H (228.6mm x 127.0mm x 63.5mm) | ||
|
HEP-2300-230AC/DC CONVERTER 380V 3.8KW |
2 | - |
|
数据表 |
HEP-2300 (2.3kW) | Box | Active | Enclosed | 1 | 230V | - | - | 3.8kW | - | - | 90 ~ 305 VAC, 250 ~ 431 VDC | - | 10 A | - | - | ITE (Commercial) | - | - | - | 6 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, IP67, PFC, PMBus™, Remote On/Off | Chassis Mount | 14.76" L x 11.02" W x 3.46" H (375.0mm x 280.0mm x 88.0mm) |
