固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CIH10T1N0SNCFIXED IND 1NH 800MA 50 MOHM SMD |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±0.3nH | 800 mA | - | - | Unshielded | 50mOhm Max | 1 nH | 8 @ 100MHz | 10GHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T1N5SNCFIXED IND 1.5NH 800MA 100MOHM SM |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±0.3nH | 800 mA | - | - | Unshielded | 100mOhm Max | 1.5 nH | 8 @ 100MHz | 6GHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T3N9SNCFIXED IND 3.9NH 800MA 140MOHM SM |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±0.3nH | 800 mA | - | - | Unshielded | 140mOhm Max | 3.9 nH | 10 @ 100MHz | 6GHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T5N6SNCFIXED IND 5.6NH 800MA 180MOHM SM |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±0.3nH | 800 mA | - | - | Unshielded | 180mOhm Max | 5.6 nH | 10 @ 100MHz | 4GHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T10NJNCFIXED IND 10NH 600MA 260MOHM SMD |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 600 mA | - | - | Unshielded | 260mOhm Max | 10 nH | 12 @ 100MHz | 3.4GHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T12NJNCFIXED IND 12NH 600MA 280MOHM SMD |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 600 mA | - | - | Unshielded | 280mOhm Max | 12 nH | 12 @ 100MHz | 2.6GHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T15NJNCFIXED IND 15NH 500MA 320MOHM SMD |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 500 mA | - | - | Unshielded | 320mOhm Max | 15 nH | 12 @ 100MHz | 2.3GHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T18NJNCFIXED IND 18NH 500MA 350MOHM SMD |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 500 mA | - | - | Unshielded | 350mOhm Max | 18 nH | 12 @ 100MHz | 2GHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T22NJNCFIXED IND 22NH 500MA 400MOHM SMD |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 500 mA | - | - | Unshielded | 400mOhm Max | 22 nH | 12 @ 100MHz | 1.6GHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T27NJNCFIXED IND 27NH 500MA 450MOHM SMD |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 500 mA | - | - | Unshielded | 450mOhm Max | 27 nH | 12 @ 100MHz | 1.4GHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T47NJNCFIXED IND 47NH 400MA 770MOHM SMD |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 400 mA | - | - | Unshielded | 770mOhm Max | 47 nH | 12 @ 100MHz | 900MHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T68NJNCFIXED IND 68NH 350MA 850MOHM SMD |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 350 mA | - | - | Unshielded | 850mOhm Max | 68 nH | 12 @ 100MHz | 700MHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10T82NJNCFIXED IND 82NH 350MA 950MOHM SMD |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 350 mA | - | - | Unshielded | 950mOhm Max | 82 nH | 12 @ 100MHz | 600MHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
|
CIH10TR10JNCFIXED IND 100NH 350MA 1 OHM SMD |
0 | - |
|
数据表 |
CIH10T | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Multilayer | - | ±5% | 350 mA | - | - | Unshielded | 1Ohm Max | 100 nH | 12 @ 100MHz | 600MHz | Surface Mount | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | -55°C ~ 125°C | 100 MHz | - |
|
0412CDMCBDS-1R0MCFIXED IND 1UH 4.5A 40 MOHM SMD |
0 | - |
|
数据表 |
0412CDMCB/DS | 2-SMD | Tape & Reel (TR) | Obsolete | Wirewound | - | ±20% | 4.5 A | 5.3A | SMD | Shielded | 40mOhm | 1 µH | - | - | Surface Mount | - | 0.177" L x 0.161" W (4.50mm x 4.10mm) | - | -40°C ~ 105°C | 100 kHz | 0.047" (1.20mm) |
|
0410CDMCBDS-1R5MCFIXED IND 1.5UH 3.4A 66 MOHM SMD |
0 | - |
|
数据表 |
0410CDMCB/DS | 2-SMD | Tape & Reel (TR) | Obsolete | Wirewound | - | ±20% | 3.4 A | 2.5A | SMD | Shielded | 66mOhm | 1.5 µH | - | - | Surface Mount | - | 0.177" L x 0.161" W (4.50mm x 4.10mm) | - | -40°C ~ 105°C | 100 kHz | 0.047" (1.20mm) |
|
0420CDMCBDS-R22MCFIXED IND 220NH 10.1A 5.3MOHM SM |
0 | - |
|
数据表 |
0420CDMCB/DS | 2-SMD | Tape & Reel (TR) | Obsolete | Wirewound | - | ±20% | 10.1 A | 15A | SMD | Shielded | 5.3mOhm | 220 nH | - | - | Surface Mount | - | 0.177" L x 0.161" W (4.50mm x 4.10mm) | - | -40°C ~ 105°C | 100 kHz | 0.079" (2.00mm) |
|
|
0420CDMCBDS-220MCFIXED IND 22UH 1.3A 316 MOHM SMD |
0 | - |
|
数据表 |
0420CDMCB/DS | 2-SMD | Tape & Reel (TR) | Obsolete | Wirewound | - | ±20% | 1.3 A | 1.6A | SMD | Shielded | 316mOhm | 22 µH | - | - | Surface Mount | - | 0.177" L x 0.161" W (4.50mm x 4.10mm) | - | -40°C ~ 105°C | 100 kHz | 0.079" (2.00mm) |
|
|
0420CDMCBDS-1R0MCFIXED IND 1UH 5.5A 17 MOHM SMD |
0 | - |
|
数据表 |
0420CDMCB/DS | 2-SMD | Tape & Reel (TR) | Obsolete | Wirewound | - | ±20% | 5.5 A | 6.8A | SMD | Shielded | 17mOhm | 1 µH | - | - | Surface Mount | - | 0.177" L x 0.161" W (4.50mm x 4.10mm) | - | -40°C ~ 105°C | 100 kHz | 0.079" (2.00mm) |
|
|
0410CDMCBDS-3R3MCFIXED IND 3.3UH 2.2A 165MOHM SMD |
0 | - |
|
数据表 |
0410CDMCB/DS | 2-SMD | Tape & Reel (TR) | Obsolete | Wirewound | - | ±20% | 2.2 A | 1.8A | SMD | Shielded | 165mOhm | 3.3 µH | - | - | Surface Mount | - | 0.177" L x 0.161" W (4.50mm x 4.10mm) | - | -40°C ~ 105°C | 100 kHz | 0.047" (1.20mm) |
