固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTCDRH104RF-5R25.2 SMD SHIELDED POWER INDUCTOR |
1,008 | - |
|
数据表 |
CTCDRH104RF | Nonstandard | Tape & Reel (TR) | Active | - | - | ±30% | - | 5.7A | - | Shielded | 22mOhm Max | 5.2 µH | - | - | Surface Mount | - | 0.394" L x 0.394" W (10.00mm x 10.00mm) | - | -40°C ~ 100°C | 100 kHz | 0.157" (4.00mm) |
|
B82464D6302M000FIXED IND 3UH 5.77A 0.024OHM SMD |
598 | - |
|
数据表 |
B82464D6 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 5.77 A | 11.75A | - | Shielded | 24mOhm Max | 3 µH | - | - | Surface Mount | AEC-Q200 | 0.409" L x 0.409" W (10.40mm x 10.40mm) | - | -55°C ~ 150°C | 100 kHz | 0.248" (6.30mm) |
|
|
CTCDRH104RF-10010 SMD SHIELDED POWER INDUCTOR |
781 | - |
|
数据表 |
CTCDRH104RF | Nonstandard | Tape & Reel (TR) | Active | - | - | ±30% | - | 4.4A | - | Shielded | 35mOhm Max | 10 µH | - | - | Surface Mount | - | 0.394" L x 0.394" W (10.00mm x 10.00mm) | - | -40°C ~ 100°C | 100 kHz | 0.157" (4.00mm) |
|
|
B82464D6223M000FIXED IND 22UH 2.66A 0.113OHM SM |
597 | - |
|
数据表 |
B82464D6 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 2.66 A | 4.35A | - | Shielded | 113mOhm Max | 22 µH | - | - | Surface Mount | AEC-Q200 | 0.409" L x 0.409" W (10.40mm x 10.40mm) | - | -55°C ~ 150°C | 100 kHz | 0.248" (6.30mm) |
|
|
B82464D6472M000FIXED IND 4.7UH 5.08A 0.031OHM |
595 | - |
|
数据表 |
B82464D6 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 5.08 A | 9.9A | - | Shielded | 31mOhm Max | 4.7 µH | - | - | Surface Mount | AEC-Q200 | 0.409" L x 0.409" W (10.40mm x 10.40mm) | - | -55°C ~ 150°C | 100 kHz | 0.248" (6.30mm) |
|
0402CS-10NXGRWFIXED IND 10NH 480MA 200MOHM SM |
763 | - |
|
数据表 |
0402CS | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | ±2% | 480 mA | - | 0402 | Unshielded | 200mOhm Max | 10 nH | 50 @ 900MHz | 3.9GHz | Surface Mount | AEC-Q200 | 0.047" L x 0.025" W (1.19mm x 0.64mm) | - | -40°C ~ 125°C | 250 MHz | 0.026" (0.66mm) |
|
|
0402CS-1N9XGRWFIXED IND 1.9NH 1.04A 70MOHM SM |
454 | - |
|
数据表 |
0402CS | 0402 (1005 Metric) | Tape & Reel (TR) | Active | Wirewound | Ceramic | ±2% | 1.04 A | - | 0402 | Unshielded | 70mOhm Max | 1.9 nH | 68 @ 900MHz | 11.3GHz | Surface Mount | AEC-Q200 | 0.047" L x 0.025" W (1.19mm x 0.64mm) | - | -40°C ~ 125°C | 250 MHz | 0.026" (0.66mm) |
|
|
B82464D6123M000FIXED IND 12UH 3.31A 0.073OHM SM |
594 | - |
|
数据表 |
B82464D6 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 3.31 A | 5.65A | - | Shielded | 73mOhm Max | 12 µH | - | - | Surface Mount | AEC-Q200 | 0.409" L x 0.409" W (10.40mm x 10.40mm) | - | -55°C ~ 150°C | 100 kHz | 0.248" (6.30mm) |
|
74454115FIXED IND 15UH 1.7A 0.085OHM SMD |
564 | - |
|
数据表 |
WE-PD3 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | - | ±20% | 1.7 A | 3A | - | Shielded | 85mOhm Max | 15 µH | - | 20MHz | Surface Mount | - | 0.500" L x 0.394" W (12.70mm x 10.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.205" (5.20mm) |
|
|
B82464D6473M000FIXED IND 47UH 1.71A 0.274OHM SM |
562 | - |
|
数据表 |
B82464D6 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 1.71 A | 2.95A | - | Shielded | 274mOhm Max | 47 µH | - | - | Surface Mount | AEC-Q200 | 0.409" L x 0.409" W (10.40mm x 10.40mm) | - | -55°C ~ 150°C | 100 kHz | 0.248" (6.30mm) |
|
74454133FIXED IND 33UH 1.2A 0.16OHM SMD |
519 | - |
|
数据表 |
WE-PD3 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | - | ±15% | 1.2 A | 1.8A | - | Shielded | 160mOhm Max | 33 µH | - | 12MHz | Surface Mount | - | 0.500" L x 0.394" W (12.70mm x 10.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.205" (5.20mm) |
|
|
B82464D6103M000FIXED IND 10UH 3.71A 0.058OHM SM |
390 | - |
|
数据表 |
B82464D6 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | ±20% | 3.71 A | 6.15A | - | Shielded | 58mOhm Max | 10 µH | - | - | Surface Mount | AEC-Q200 | 0.409" L x 0.409" W (10.40mm x 10.40mm) | - | -55°C ~ 150°C | 100 kHz | 0.248" (6.30mm) |
|
|
74454220FIXED IND 220UH 450MA 0.8OHM SMD |
334 | - |
|
数据表 |
WE-PD3 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | - | ±10% | 450 mA | 700mA | - | Shielded | 800mOhm Max | 220 µH | - | 4.5MHz | Surface Mount | - | 0.500" L x 0.394" W (12.70mm x 10.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.205" (5.20mm) |
|
|
PG0434.202NLFIXED IND 2UH 23A 2.9 MOHM SMD |
830 | - |
|
数据表 |
PG0434NL | Nonstandard | Tray | Active | Wirewound | - | ±20% | 23 A | 24A | - | Shielded | 2.9mOhm Max | 2 µH | - | - | Surface Mount | - | 0.571" L x 0.512" W (14.50mm x 13.00mm) | - | -40°C ~ 130°C | 100 kHz | 0.256" (6.50mm) |
|
|
PG0434.282NLFIXED IND 2.8UH 19A 4.2 MOHM SMD |
830 | - |
|
数据表 |
PG0434NL | Nonstandard | Tray | Active | Wirewound | - | ±20% | 19 A | 20A | - | Shielded | 4.2mOhm Max | 2.8 µH | - | - | Surface Mount | - | 0.571" L x 0.512" W (14.50mm x 13.00mm) | - | -40°C ~ 130°C | 100 kHz | 0.256" (6.50mm) |
|
|
PG0434.401NLFIXED IND 450NH 45A 0.8 MOHM SMD |
830 | - |
|
数据表 |
PG0434NL | Nonstandard | Tray | Active | Wirewound | - | ±20% | 45 A | 48A | - | Shielded | 0.8mOhm Max | 450 nH | - | - | Surface Mount | - | 0.571" L x 0.512" W (14.50mm x 13.00mm) | - | -40°C ~ 130°C | 100 kHz | 0.256" (6.50mm) |
|
PAL6374.121HLTIND POWER BEAD TLVR |
1,470 | - |
|
数据表 |
PAL6374.XXXHLT | Nonstandard | Tape & Reel (TR) | Active | - | - | ±15% | 71 A | 66A | - | Unshielded | 0.45mOhm Max | 120 nH | - | - | Surface Mount | - | 0.472" L x 0.236" W (12.00mm x 6.00mm) | - | -40°C ~ 130°C | 100 kHz | 0.472" (12.00mm) |
|
SNT-S10CMC 1.5UH 3A 2LN TH |
698 | - |
|
数据表 |
SNT | Vertical, 2 PC Pin | Bulk | Active | Toroidal | Nickel Zinc Ferrite (NiZn) | - | 3 A | - | Nonstandard, 2 Lead | Unshielded | 25mOhm | 1.5 µH | - | - | Through Hole | - | 0.374" L x 0.197" W (9.50mm x 5.00mm) | - | -20°C ~ 60°C | 100 kHz | 0.500" (12.70mm) |
|
CTAF05TJSMD AIR CORE INDUCTOR |
330 | - |
|
数据表 |
ctaf | - | Tape & Reel (TR) | Active | Wirewound | - | ±5% | - | - | - | - | 3.9mOhm | 18.5 nH | - | 2.5GHz | Surface Mount | - | - | - | -40°C ~ 85°C | - | - |
|
SBCP-14HY332BFIXED IND 3.3MH 330MA 2.42OHM TH |
525 | - |
|
数据表 |
SBCP | Radial, Vertical Cylinder (Open) | Bulk | Active | Drum Core, Wirewound | Ferrite | ±10% | 330 mA | 570mA | - | Unshielded | 2.42Ohm Max | 3.3 mH | - | - | Through Hole | - | 0.472" Dia (12.00mm) | - | -20°C ~ 105°C | 10 kHz | 0.591" (15.00mm) |
