固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTH7F-471K470UH AXIAL PWR LINE INDUCTOR Central Technologies |
17 | - |
|
数据表 |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | ±10% | 320 mA | 590mA | Axial | Unshielded | 1.2Ohm Max | 470 µH | - | 2MHz | Through Hole | - | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - | -55°C ~ 125°C | 1 kHz | - |
|
|
CTH7F-123K12000UH AXIAL PWR LINE INDUCTOR Central Technologies |
15 | - |
|
数据表 |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | ±10% | 50 mA | 110mA | Axial | Unshielded | 30Ohm Max | 12 mH | - | 250kHz | Through Hole | - | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - | -55°C ~ 125°C | 1 kHz | - |
|
|
CTH7F-8R2K8.2UH AXIAL PWR LINE INDUCTOR Central Technologies |
5 | - |
|
数据表 |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | ±10% | 1.3 A | 4.5A | Axial | Unshielded | 30mOhm Max | 8.2 µH | - | 22MHz | Through Hole | - | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - | -55°C ~ 125°C | 1 kHz | - |
|
|
CTH7F-332K3300UH AXIAL PWR LINE INDUCTOR Central Technologies |
5 | - |
|
数据表 |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | ±10% | 130 mA | 220mA | Axial | Unshielded | 6.6Ohm Max | 3.3 mH | - | 600kHz | Through Hole | - | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - | -55°C ~ 125°C | 1 kHz | - |
|
|
CTH7F-392K3900UH AXIAL PWR LINE INDUCTOR Central Technologies |
5 | - |
|
数据表 |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | ±10% | 100 mA | 200mA | Axial | Unshielded | 8.6Ohm Max | 3.9 mH | - | 600kHz | Through Hole | - | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - | -55°C ~ 125°C | 1 kHz | - |
|
|
CTH7F-271K270UH AXIAL PWR LINE INDUCTOR Central Technologies |
5 | - |
|
数据表 |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | ±10% | 400 mA | 770mA | Axial | Unshielded | 560mOhm Max | 270 µH | - | 2MHz | Through Hole | - | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - | -55°C ~ 125°C | 1 kHz | - |
|
|
CTH7F-822K8200UH AXIAL PWR LINE INDUCTOR Central Technologies |
5 | - |
|
数据表 |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | ±10% | 70 mA | 130mA | Axial | Unshielded | 21Ohm Max | 8.2 mH | - | 350kHz | Through Hole | - | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - | -55°C ~ 125°C | 1 kHz | - |
|
|
CTH7F-470K47UH AXIAL PWR LINE INDUCTOR Central Technologies |
5 | - |
|
数据表 |
CTH7F | Axial | Tape & Reel (TR) | Active | - | - | ±10% | 800 mA | 1.8A | Axial | Unshielded | 110mOhm Max | 47 µH | - | 6MHz | Through Hole | - | 0.290" Dia x 0.602" L (7.37mm x 15.30mm) | - | -55°C ~ 125°C | 1 kHz | - |
|
CTSFW7040F-4R7MSMD FLAT WIRE POWER INDUCTOR Central Technologies |
5 | - |
|
数据表 |
CTSFW7040F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | ±20% | 6 A | 7A | - | Shielded | 21.5mOhm Max | 4.7 µH | - | - | Surface Mount | - | 0.291" L x 0.264" W (7.40mm x 6.70mm) | - | -55°C ~ 150°C | 100 kHz | 0.173" (4.40mm) |
|
|
CTSFW7040F-1R0MSMD FLAT WIRE POWER INDUCTOR Central Technologies |
5 | - |
|
数据表 |
CTSFW7040F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | ±20% | 15 A | 19A | - | Shielded | 5.1mOhm Max | 1 µH | - | - | Surface Mount | - | 0.291" L x 0.264" W (7.40mm x 6.70mm) | - | -55°C ~ 150°C | 100 kHz | 0.173" (4.40mm) |
