固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CDRH60D45BT150NP-470MCFIXED IND 47UH 1.4A 156MOHM SMD Sumida America Components Inc. |
7,901 | - |
|
数据表 |
CDRH60D45B/T150 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±20% | 1.4 A | 1.28A | - | Shielded | 156mOhm | 47 µH | - | - | Surface Mount | AEC-Q200 | 0.260" L x 0.248" W (6.60mm x 6.30mm) | - | -55°C ~ 150°C | 100 kHz | 0.189" (4.80mm) |
|
CDRH3D16NP-330NCFIXED IND 33UH 320MA 675MOHM SMD Sumida America Components Inc. |
116 | - |
|
数据表 |
CDRH3D16 | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±30% | 320 mA | - | - | Shielded | 675mOhm Max | 33 µH | - | - | Surface Mount | - | 0.150" L x 0.150" W (3.80mm x 3.80mm) | - | -40°C ~ 100°C | 100 kHz | 0.071" (1.80mm) |
|
0512CDMCCDS-2R2MCFIXED IND 2.2UH 3.6A 72.6MOHM SM Sumida America Components Inc. |
3,076 | - |
|
数据表 |
0512CDMCC/DS | Nonstandard | Tape & Reel (TR) | Active | Molded | Metal | ±20% | 3.6 A | 4.8A | SMD | Shielded | 72.6mOhm Max | 2.2 µH | - | - | Surface Mount | - | 0.213" L x 0.205" W (5.40mm x 5.20mm) | - | -55°C ~ 125°C | 100 kHz | 0.047" (1.20mm) |
|
CDRH8D43HPNP-220NCFIXED IND 22UH 1.5A 125 MOHM SMD Sumida America Components Inc. |
1,700 | - |
|
数据表 |
CDRH8D43/HP | Nonstandard | Tape & Reel (TR) | Active | - | Ferrite | ±30% | 1.5 A | 3A | - | Shielded | 125mOhm Max | 22 µH | - | - | Surface Mount | - | 0.315" L x 0.315" W (8.00mm x 8.00mm) | - | -40°C ~ 100°C | 100 kHz | 0.185" (4.70mm) |
|
CDRH127L125NP-7R5NCFIXED IND 7.5UH 7A 16.3MOHM SMD Sumida America Components Inc. |
1,448 | - |
|
数据表 |
CDRH127/L125 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | ±30% | 7 A | 9.2A | - | Shielded | 16.3mOhm Max | 7.5 µH | - | - | Surface Mount | AEC-Q200 | 0.472" L x 0.472" W (12.00mm x 12.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.315" (8.00mm) |
|
CDRH127L125NP-471MCFIXED IND 470UH 950MA 731MOHM SM Sumida America Components Inc. |
783 | - |
|
数据表 |
CDRH127/L125 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | ±20% | 950 mA | 1.2A | - | Shielded | 731mOhm Max | 470 µH | - | - | Surface Mount | AEC-Q200 | 0.472" L x 0.472" W (12.00mm x 12.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.315" (8.00mm) |
|
CDRH127L125NP-331MCFIXED IND 330UH 1.18A 478MOHM SM Sumida America Components Inc. |
185 | - |
|
数据表 |
CDRH127/L125 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | ±20% | 1.18 A | 1.42A | - | Shielded | 478mOhm Max | 330 µH | - | - | Surface Mount | AEC-Q200 | 0.472" L x 0.472" W (12.00mm x 12.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.315" (8.00mm) |
|
CDRH127L125NP-681MCFIXED IND 680UH 750MA 1.102 OHM Sumida America Components Inc. |
594 | - |
|
数据表 |
CDRH127/L125 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | ±20% | 750 mA | 980mA | - | Shielded | 1.102Ohm Max | 680 µH | - | - | Surface Mount | AEC-Q200 | 0.472" L x 0.472" W (12.00mm x 12.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.315" (8.00mm) |
|
CDRH127L125NP-102MCFIXED IND 1MH 640MA 1.495OHM SMD Sumida America Components Inc. |
497 | - |
|
数据表 |
CDRH127/L125 | Nonstandard | Tape & Reel (TR) | Active | Drum Core | Ferrite | ±20% | 640 mA | 830mA | - | Shielded | 1.495Ohm Max | 1 mH | - | - | Surface Mount | AEC-Q200 | 0.472" L x 0.472" W (12.00mm x 12.00mm) | - | -40°C ~ 125°C | 100 kHz | 0.315" (8.00mm) |
|
CDRH127L125NP-4R7NCFIXED IND 4.7UH 7.8A 13MOHM SMD Sumida America Components Inc. |
497 | - |
|
数据表 |
CDRH127/L125 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Drum Core | Ferrite | ±30% | 7.8 A | 12.3A | - | Shielded | 13mOhm Max | 4.7 µH | - | - | Surface Mount | AEC-Q200 | 0.492" L x 0.492" W (12.50mm x 12.50mm) | - | -40°C ~ 125°C | 100 kHz | 0.315" (8.00mm) |
