固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AS40-R22K-RC.22UH 10% AXIAL SHIELDED IND. Allied Components International |
0 | - |
|
数据表 |
AS40 | Axial | Bag | Active | - | - | ±10% | 1.1 A | 1.1A | Axial | Shielded | 67mOhm Max | 220 nH | 49 @ 25MHz | 250MHz | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - | -55°C ~ 125°C | 25 MHz | - |
|
|
AS40-272J-RC2700UH 5% AXIAL SHIELDED IND. Allied Components International |
0 | - |
|
数据表 |
AS40 | Axial | Bag | Active | - | - | ±10% | 40 mA | 25mA | Axial | Shielded | 47.3Ohm Max | 2.7 mH | 45 @ 250kHz | 920kHz | Through Hole | - | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) | - | -55°C ~ 125°C | 250 kHz | - |
|
PCS2D14-100T-RC10UH 30% POWER CHIP INDUCTOR Allied Components International |
0 | - |
|
数据表 |
- | Nonstandard | Tape & Reel (TR) | Active | - | - | ±30% | 760 mA | 700mA | - | Shielded | 294mOhm Max | 10 µH | - | - | Surface Mount | - | 0.126" L x 0.126" W (3.20mm x 3.20mm) | - | -35°C ~ 100°C | 100 kHz | 0.061" (1.55mm) |
|
PCS3D16-100T-RC10UH 30% POWER CHIP INDUCTOR Allied Components International |
0 | - |
|
数据表 |
- | Nonstandard | Tape & Reel (TR) | Active | - | - | ±30% | 550 mA | - | - | Shielded | 210mOhm Max | 10 µH | - | - | Surface Mount | - | 0.157" L x 0.157" W (4.00mm x 4.00mm) | - | -30°C ~ 100°C | 100 kHz | 0.071" (1.80mm) |
|
HTC220LL-8R2M-RC8.2UH 30% HRZMNT TOROIDAL CHOKE Allied Components International |
0 | - |
|
数据表 |
- | Radial, Horizontal (Open) | Tray | Active | Toroidal | - | ±20% | 15.1 A | - | Radial | Unshielded | 5mOhm Max | 8.2 µH | - | - | Through Hole | - | 1.100" Dia (27.94mm) | - | -55°C ~ 125°C | 1 kHz | 0.550" (13.97mm) |
|
VTCB5825-300-40A30UH 15% @ 40A VERT.MNT. TOROID Allied Components International |
0 | - |
|
数据表 |
- | Radial, Vertical (Open) | Box | Active | Toroidal | - | ±15% | 40 A | - | Radial, Vertical (Open) | Unshielded | 6mOhm Max | 30 µH | - | - | Through Hole | - | 2.283" L x 0.984" W (58.00mm x 25.00mm) | - | -40°C ~ 125°C | 100 kHz | 2.559" (65.00mm) |
|
PCS5D28-8R2N-RC8.2UH 30% POWER CHIP SHIELDED Allied Components International |
0 | - |
|
数据表 |
- | Nonstandard | Tape & Reel (TR) | Active | - | - | ±30% | 1.6 A | - | - | Shielded | 53mOhm Max | 8.2 µH | - | - | Surface Mount | - | 0.224" L x 0.224" W (5.70mm x 5.70mm) | - | -30°C ~ 100°C | 10 kHz | 0.118" (3.00mm) |
|
|
HTC220LL-471L-RC470UH 30% HRZMNT TOROIDAL CHOKE Allied Components International |
0 | - |
|
数据表 |
- | Radial, Horizontal (Open) | Tray | Active | Toroidal | - | ±15% | 3.7 A | - | Radial | Unshielded | 92mOhm Max | 470 µH | - | - | Through Hole | - | 1.100" Dia (27.94mm) | - | -55°C ~ 125°C | 1 kHz | 0.550" (13.97mm) |
|
|
VTC220LL-102L-RC1000UH30% VRTMNT TOROIDAL CHOKE Allied Components International |
0 | - |
|
数据表 |
- | Radial, Vertical (Open) | Tray | Active | Toroidal | - | ±15% | 2.4 A | - | Radial | Unshielded | 216mOhm Max | 1 mH | - | - | Through Hole | - | 1.100" Dia x 0.550" L (27.94mm x 13.97mm) | - | -55°C ~ 125°C | 1 kHz | - |
|
PCS124-101M-RC100UH 20% POWER CHIP SHIELDED Allied Components International |
0 | - |
|
数据表 |
- | Nonstandard | Tape & Reel (TR) | Active | - | - | ±20% | 1.2 A | - | - | Shielded | 308mOhm Max | 100 µH | - | - | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | - | -40°C ~ 100°C | 100 kHz | 0.177" (4.50mm) |
