直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CBM-979433S-225-467-22FAN BLOWER 97X33MM 24VDC WIRE |
0 | - |
|
数据表 |
CBM-97S | Box | Active | 24VDC | Rectangular/Rounded - 97mm L x 94.8mm H | 15.1 CFM (0.423m³/min) | 0.280 in H2O (69.7 Pa) | Sleeve | - | Blower | Auto Restart, PWM Control, Speed Sensor (Tach) | 33.00mm | 39.5dB(A) | 4.32 W | CE, cURus, TUV | 2500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
|
CBM-979433S-125-467-22FAN BLOWER 97X33MM 12VDC WIRE |
0 | - |
|
数据表 |
CBM-97S | Box | Active | 12VDC | Rectangular/Rounded - 97mm L x 94.8mm H | 15.1 CFM (0.423m³/min) | 0.280 in H2O (69.7 Pa) | Sleeve | - | Blower | Auto Restart, PWM Control, Speed Sensor (Tach) | 33.00mm | 39.5dB(A) | 4.56 W | CE, cURus, TUV | 2500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 4 Wire Leads | - |
|
CFM-8020BF-155-444FAN AXIAL 80X20MM 12VDC WIRE |
0 | - |
|
数据表 |
CFM-80BF | Box | Active | 12VDC | Square - 80mm L x 80mm H | 53.9 CFM (1.51m³/min) | 0.350 in H2O (87.2 Pa) | Ball | - | Tubeaxial | Auto Restart | 20.00mm | 44.5dB(A) | 5.4 W | CE, cURus, TUV | 5500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
CFM-8020V-230-350FAN AXIAL 80X20MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-80V | Tray | Obsolete | 24VDC | Square - 80mm L x 80mm H | 33.1 CFM (0.927m³/min) | 0.160 in H2O (40.0 Pa) | omniCOOL™ Magnetic Sleeve | 0.145 lb (65.77 g) | Tubeaxial | Auto Restart | 20.00mm | 35.0dB(A) | 1.42 W | CE, cURus, TUV | 3000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
MF30101V2-1000U-G99FAN AXIAL 30X10MM 12VDC WIRE |
0 | - |
|
数据表 |
MagLev® MF | Bulk | Active | 12VDC | Square - 30mm L x 30mm H | 4.6 CFM (0.129m³/min) | 0.140 in H2O (34.9 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 10.00mm | 20.0dB(A) | 390 mW | CE, CUR, TUV, UL | 8600 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
AFB0505LB-F00FAN AXIAL 50X15MM BALL 5VDC WIRE |
0 | - |
|
数据表 |
AFB | Bulk | Obsolete | 5VDC | Square - 50mm L x 50mm H | 9.9 CFM (0.277m³/min) | 0.126 in H2O (31.4 Pa) | Ball | 0.071 lb (32.21 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 15.00mm | 24.0dB(A) | 750 mW | CE, CSA, UL, VDE | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
FFB0948SHE-R00FAN AXIAL 92X38MM 48VDC WIRE |
0 | - |
|
数据表 |
FFB | Bulk | Obsolete | 48VDC | Square - 92mm L x 92mm H | 100.3 CFM (2.81m³/min) | 0.572 in H2O (142.5 Pa) | Ball | 0.437 lb (198.00 g) | Tubeaxial | Locked Rotor Sensor | 38.00mm | 52.5dB(A) | 9.6 W | CE, CSA, UL, VDE | 4400 RPM | 14 ~ 140°F (-10 ~ 60°C) | 3 Wire Leads | - |
|
|
09225SA-24Q-AL-D0DC AXIAL FAN |
0 | - |
|
数据表 |
09225SA | Box | Active | 24VDC | Square - 92mm L x 92mm H | 65.6 CFM (1.84m³/min) | 0.293 in H2O (73.0 Pa) | Ball | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 25.00mm | 40.0dB | 3.12 W | - | 3900 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
09225SA-24Q-AT-D0DC AXIAL FAN |
0 | - |
|
数据表 |
09225SA | Box | Active | 24VDC | Square - 92mm L x 92mm H | 65.6 CFM (1.84m³/min) | 0.293 in H2O (73.0 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 25.00mm | 40.0dB | 3.12 W | - | 3900 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
EE80251B3-000U-A99Thermal Products |
0 | - |
|
数据表 |
- | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
UF3H3-710 V2FAN AXIAL 17X3MM VAPO 3VDC |
0 | - |
|
数据表 |
MagLev® UF, Mighty Mini | Bulk | Active | 3VDC | Square - 17mm L x 17mm H | 0.575 CFM (0.016m³/min) | 0.085 in H2O (21.2 Pa) | Vapo-Bearing™ | 0.003 lb (1.36 g) | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 3.00mm | 32.0dB(A) | 100 mW | CE | 13000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Position Rectangular Connector | IP55 - Dust Protected, Water Resistant |
|
|
EFB0612LA-F00FAN AXIAL 60X10MM 12VDC WIRE |
0 | - |
|
数据表 |
EFB | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 13.4 CFM (0.375m³/min) | 0.065 in H2O (16.2 Pa) | Ball | 0.062 lb (28.12 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 10.00mm | 24.5dB(A) | 840 mW | CE, CSA, UL, VDE | 3000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
EFB0612HA-R00FAN AXIAL 60X10MM 12VDC WIRE |
0 | - |
|
数据表 |
EFB | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 18.0 CFM (0.504m³/min) | 0.132 in H2O (32.9 Pa) | Ball | 0.062 lb (28.12 g) | Tubeaxial | Locked Rotor Sensor | 10.00mm | 33.0dB(A) | 1.44 W | CE, CSA, UL, VDE | 4200 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
EFB0412HHD-F00FAN AXIAL 40X20MM 12VDC WIRE |
0 | - |
|
数据表 |
EFB | Bulk | Active | 12VDC | Square - 40mm L x 40mm H | 9.4 CFM (0.263m³/min) | 0.354 in H2O (88.2 Pa) | Ball | 0.073 lb (33.11 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 20.00mm | 30.5dB(A) | 1.2 W | CE, CSA, UL, VDE | 8200 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
AFB0512MB-AFAN AXIAL 50X15MM 12VDC WIRE |
0 | - |
|
数据表 |
AFB | Bulk | Active | 12VDC | Square - 50mm L x 50mm H | 15.3 CFM (0.428m³/min) | 0.177 in H2O (44.1 Pa) | Ball | 0.071 lb (32.21 g) | Tubeaxial | Locked Rotor Protection | 15.00mm | 30.0dB(A) | 1.2 W | CE, CSA, UL, VDE | 5300 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
EFB0612HHA-R00FAN AXIAL 60X10MM 12VDC WIRE |
0 | - |
|
数据表 |
EFB | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 21.2 CFM (0.594m³/min) | 0.132 in H2O (32.9 Pa) | Ball | 0.062 lb (28.12 g) | Tubeaxial | Locked Rotor Sensor | 10.00mm | 36.5dB(A) | 2.16 W | CE, CSA, UL, VDE | 4200 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
EFB0424VHD-R00FAN AXIAL 40X20MM 24VDC WIRE |
0 | - |
|
数据表 |
EFB | Bulk | Active | 24VDC | Square - 40mm L x 40mm H | 10.1 CFM (0.283m³/min) | 0.416 in H2O (103.6 Pa) | Ball | 0.073 lb (33.11 g) | Tubeaxial | Locked Rotor Sensor | 20.00mm | 32.5dB(A) | 2.16 W | CE, CSA, UL, VDE | 9000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
EFB0424VHD-F00FAN AXIAL 40X20MM 24VDC WIRE |
0 | - |
|
数据表 |
EFB | Bulk | Active | 24VDC | Square - 40mm L x 40mm H | 10.1 CFM (0.283m³/min) | 0.416 in H2O (103.6 Pa) | Ball | 0.073 lb (33.11 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 20.00mm | 32.5dB(A) | 2.16 W | CE, CSA, UL, VDE | 9000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
AFB0512HDFAN AXIAL 50X20MM 12VDC WIRE |
0 | - |
|
数据表 |
AFB | Bulk | Obsolete | 12VDC | Square - 50mm L x 50mm H | 15.8 CFM (0.442m³/min) | 0.182 in H2O (45.3 Pa) | Ball | 0.085 lb (38.56 g) | Tubeaxial | Locked Rotor Protection | 20.00mm | 33.0dB(A) | 1.2 W | CE, CSA, UL, VDE | 5600 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
AFB0624MB-R00FAN AXIAL 60X15MM 24VDC WIRE |
0 | - |
|
数据表 |
AFB | Box | Obsolete | 24VDC | Square - 60mm L x 60mm H | 13.5 CFM (0.378m³/min) | 0.119 in H2O (29.6 Pa) | Ball | 0.098 lb (44.45 g) | Tubeaxial | Locked Rotor Sensor | 15.00mm | 29.0dB(A) | 1.44 W | CE, CSA, UL, VDE | 3500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
