直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
08025SA-24R-EA-D0FAN AXIAL 80X25MM 24VDC WIRE |
0 | - |
|
数据表 |
08025SA | Bulk | Active | 24VDC | Square - 80mm L x 80mm H | 60.0 CFM (1.68m³/min) | 0.330 in H2O (82.2 Pa) | Ball | - | Tubeaxial | Auto Restart | 25.00mm | 42.0dB | 4.08 W | - | 4500 RPM | 14 ~ 140°F (-10 ~ 60°C) | 2 Wire Leads | - |
|
|
08025SA-12M-AA-D0FAN AXIAL 80X25MM 12VDC WIRE |
0 | - |
|
数据表 |
08025SA | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 36.0 CFM (1.01m³/min) | 0.120 in H2O (29.9 Pa) | Ball | - | Tubeaxial | Auto Restart | 25.00mm | 26.0dB | 1.08 W | - | 2700 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
08025SA-12L-EA-D0FAN AXIAL 80X25MM 12VDC WIRE |
0 | - |
|
数据表 |
08025SA | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 30.4 CFM (0.851m³/min) | 0.090 in H2O (22.4 Pa) | Ball | - | Tubeaxial | Auto Restart | 25.00mm | 22.0dB | 720 mW | - | 2300 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
CBM-7530BF-230-404DC BLOWER, 49.2 X 49.8 X 20 MM, |
0 | - |
|
数据表 |
CBM-75BF | Box | Active | 24VDC | Square/Rounded - 75.7mm L x 75.7mm H | 9.9 CFM (0.277m³/min) | 0.310 in H2O (77.2 Pa) | Ball | - | Blower | Auto Restart | 24.50mm | 40.4dB(A) | 3.36 W | CE, cURus, TUV | 3000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
|
CFM-4015B-165-256-20DC AXIAL FAN, 40 MM SQUARE, 15 M |
0 | - |
|
数据表 |
CFM-40B | Box | Active | 12VDC | Square - 40mm L x 40mm H | 7.3 CFM (0.204m³/min) | 0.220 in H2O (55.0 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 15.10mm | 25.6dB(A) | 0.96 W | CE, cURus, TUV | 6500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
CFM-4015B-175-287-20DC AXIAL FAN, 40 MM SQUARE, 15 M |
0 | - |
|
数据表 |
CFM-40B | Box | Active | 12VDC | Square - 40mm L x 40mm H | 8.4 CFM (0.235m³/min) | 0.290 in H2O (72.2 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 15.10mm | 28.7dB(A) | 1.2 W | CE, cURus, TUV | 7500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
08025SA-24N-AT-D0FAN AXIAL 80X25MM 24VDC WIRE |
0 | - |
|
数据表 |
08025SA | Bulk | Active | 24VDC | Square - 80mm L x 80mm H | 41.3 CFM (1.16m³/min) | 0.150 in H2O (37.3 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 25.00mm | 30.0dB | 1.92 W | - | 3100 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
, B0502AFB1-8(MS).jpg)
|
B0502AFB1-8 (MS)FAN BLOWER 25X9.8MM 5VDC WIRE |
0 | - |
|
数据表 |
- | - | Obsolete | 5VDC | Square - 25mm L x 25mm H | 1.0 CFM (0.028m³/min) | 0.400 in H2O (99.6 Pa) | Ball | 0.02 lb (9.07 g) | Blower | - | 9.80mm | 37.0dB(A) | 900 mW | - | 14000 RPM | - | 2 Wire Leads | - |
|
EFB0405MD-9B48FAN AXIAL 40X20MM BALL 5VDC WIRE |
0 | - |
|
数据表 |
EFB | Tray | Obsolete | 5VDC | Square - 40mm L x 40mm H | 7.2 CFM (0.202m³/min) | 0.218 in H2O (54.3 Pa) | Ball | 0.073 lb (33.11 g) | Tubeaxial | - | 20.00mm | 24.0dB(A) | 750 mW | CE, CSA, UL, VDE | 6300 RPM | - | 2 Wire Leads | - |
|
|
MF25150V2-1000U-F995VDC FAN 25X15MM TACH |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 25mm L x 25mm H | 2.2 CFM (0.061m³/min) | 0.110 in H2O (27.4 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 15.00mm | 11.3dB(A) | 0.23 W | CCC, CE, cURus, TUV, UKCA | 6800 RPM | - | 3 Wire Leads | - |
|
|
MF30150V1-1000U-S995VDC FAN 30X15MM TACH/PWM |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 30mm L x 30mm H | 6.0 CFM (0.168m³/min) | 0.170 in H2O (42.3 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 15.00mm | 27.0dB(A) | 0.7 W | CCC, CE, cURus, TUV, UKCA | 9500 RPM | - | 4 Wire Leads | - |
|
|
MF30150V3-1000U-F995VDC FAN 30X15MM TACH |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 30mm L x 30mm H | 2.8 CFM (0.078m³/min) | 0.050 in H2O (12.4 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 15.00mm | 9.8dB(A) | 0.23 W | CCC, CE, cURus, TUV, UKCA | 5200 RPM | - | 3 Wire Leads | - |
|
|
MF30150V2-1000U-F995VDC FAN 30X15MM TACH |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 30mm L x 30mm H | 4.9 CFM (0.137m³/min) | 0.120 in H2O (29.9 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 15.00mm | 20.0dB(A) | 0.4 W | CCC, CE, cURus, TUV, UKCA | 7300 RPM | - | 3 Wire Leads | - |
|
|
MF25150V1-1000U-S995VDC FAN 25X15MM TACH/PWM |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 25mm L x 25mm H | 3.1 CFM (0.087m³/min) | 0.160 in H2O (39.8 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 15.00mm | 20.0dB(A) | 0.43 W | CCC, CE, cURus, TUV, UKCA | 10000 RPM | - | 4 Wire Leads | - |
|
|
MF25150V1-1000U-F995VDC FAN 25X15MM TACH |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 25mm L x 25mm H | 3.1 CFM (0.087m³/min) | 0.160 in H2O (39.8 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 15.00mm | 20.0dB(A) | 0.43 W | CCC, CE, cURus, TUV, UKCA | 10000 RPM | - | 3 Wire Leads | - |
|
|
MF30150V2-1000U-S995VDC FAN 30X15MM TACH/PWM |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 30mm L x 30mm H | 4.9 CFM (0.137m³/min) | 0.120 in H2O (29.9 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 15.00mm | 20.0dB(A) | 0.4 W | CCC, CE, cURus, TUV, UKCA | 7300 RPM | - | 4 Wire Leads | - |
|
|
MF25150V3-1000U-F995VDC FAN 25X15MM TACH |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 25mm L x 25mm H | 1.3 CFM (0.036m³/min) | 0.040 in H2O (10.0 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 15.00mm | 4.5dB(A) | 0.18 W | CCC, CE, cURus, TUV, UKCA | 5300 RPM | - | 3 Wire Leads | - |
|
|
MF30150V3-1000U-S995VDC FAN 30X15MM TACH/PWM |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 30mm L x 30mm H | 2.8 CFM (0.078m³/min) | 0.050 in H2O (12.4 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 15.00mm | 9.8dB(A) | 0.23 W | CCC, CE, cURus, TUV, UKCA | 5200 RPM | - | 4 Wire Leads | - |
|
|
MF25150V2-1000U-S995VDC FAN 25X15MM TACH/PWM |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 25mm L x 25mm H | 2.2 CFM (0.061m³/min) | 0.110 in H2O (27.4 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 15.00mm | 11.3dB(A) | 0.23 W | CCC, CE, cURus, TUV, UKCA | 6800 RPM | - | 4 Wire Leads | - |
|
|
MF30150V1-1000U-F995VDC FAN 30X15MM TACH |
0 | - |
|
数据表 |
MF | Box | Active | 5VDC | Square - 30mm L x 30mm H | 6.0 CFM (0.168m³/min) | 0.170 in H2O (42.3 Pa) | Vapo-Bearing™ | - | Tubeaxial | Auto Restart, Locked Rotor Sensor | 15.00mm | 27.0dB(A) | 0.7 W | CCC, CE, cURus, TUV, UKCA | 9500 RPM | - | 3 Wire Leads | - |
