直流无刷风扇（BLDC）
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 气流 | 静压 | 轴承类型 | 重量 | 风扇类型 | 特性 | 宽度 | 噪音 | 功率（瓦特） | 认证机构 | 转速（RPM） | 工作温度 | 端接方式 | 防护等级 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CFM-7010-13-10FAN AXIAL 70X10.6MM 12VDC WIRE |
0 | - |
|
数据表 |
CFM-70 | Tray | Obsolete | 12VDC | Square - 70mm L x 70mm H | 31.1 CFM (0.871m³/min) | 0.160 in H2O (40.0 Pa) | Ball | 0.083 lb (37.65 g) | Tubeaxial | Auto Restart | 10.60mm | 40.6dB(A) | 3.24 W | CE, cURus, TUV | 4400 RPM | 14 ~ 158°F (-10 ~ 70°C) | 2 Wire Leads | - |
|
9GV0312P3J031FAN AXIAL 38X28MM 12VDC WIRE |
0 | - |
|
数据表 |
San Ace 38 | Box | Obsolete | 12VDC | Square - 38mm L x 38mm H | 20.0 CFM (0.560m³/min) | 1.265 in H2O (315.0 Pa) | Ball | 0.111 lb (50.35 g) | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 28.00mm | 54.0dB(A) | 7.2 W | CSA, TUV, UL | 15900 RPM | -4 ~ 140°F (-20 ~ 60°C) | 4 Wire Leads | - |
|
|
9GV0312P3K01FAN AXIAL 38X28MM 12VDC WIRE |
0 | - |
|
数据表 |
San Ace 38 | Box | Obsolete | 12VDC | Square - 38mm L x 38mm H | 23.0 CFM (0.644m³/min) | 1.707 in H2O (425.2 Pa) | Ball | 0.111 lb (50.35 g) | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 28.00mm | 59.0dB(A) | 9.48 W | CSA, TUV, UL | 18200 RPM | -4 ~ 140°F (-20 ~ 60°C) | 4 Wire Leads | - |
|
|
9GV0412P3G031FAN AXIAL 40X28MM 12VDC WIRE |
0 | - |
|
数据表 |
San Ace 40 | Box | Obsolete | 12VDC | Square - 40mm L x 40mm H | 21.1 CFM (0.591m³/min) | 1.044 in H2O (260.0 Pa) | Ball | 0.111 lb (50.35 g) | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 28.00mm | 52.0dB(A) | 5.64 W | CSA, TUV, UL | 13000 RPM | -4 ~ 140°F (-20 ~ 60°C) | 4 Wire Leads | - |
|
|
9GV0412P3J031FAN AXIAL 40X28MM 12VDC WIRE |
0 | - |
|
数据表 |
San Ace 40 | Box | Obsolete | 12VDC | Square - 40mm L x 40mm H | 24.0 CFM (0.672m³/min) | 1.325 in H2O (330.0 Pa) | Ball | 0.111 lb (50.35 g) | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 28.00mm | 55.0dB(A) | 7.2 W | CSA, TUV, UL | 14700 RPM | -4 ~ 140°F (-20 ~ 60°C) | 4 Wire Leads | - |
|
|
9GV0612P1H031FAN AXIAL 60X38MM 12VDC WIRE |
0 | - |
|
数据表 |
San Ace 60 | Box | Obsolete | 12VDC | Square - 60mm L x 60mm H | 76.0 CFM (2.13m³/min) | 2.480 in H2O (617.7 Pa) | Ball | 0.287 lb (130.18 g) | Tubeaxial | PWM Control, Speed Sensor (Tach) | 38.00mm | 63.0dB(A) | 24 W | CSA, TUV, UL | 14500 RPM | -4 ~ 158°F (-20 ~ 70°C) | 4 Wire Leads | - |
|
|
9GV0612P1L01FAN AXIAL 60X38MM 12VDC WIRE |
0 | - |
|
数据表 |
San Ace 60 | Box | Obsolete | 12VDC | Square - 60mm L x 60mm H | 52.6 CFM (1.47m³/min) | 1.170 in H2O (291.4 Pa) | Ball | 0.287 lb (130.18 g) | Tubeaxial | PWM Control, Speed Sensor (Tach) | 38.00mm | 52.0dB(A) | 8.4 W | CSA, TUV, UL | 10000 RPM | -4 ~ 158°F (-20 ~ 70°C) | 4 Wire Leads | - |
|
|
9GV0612P1M031FAN AXIAL 60X38MM 12VDC WIRE |
0 | - |
|
数据表 |
San Ace 60 | Box | Obsolete | 12VDC | Square - 60mm L x 60mm H | 68.0 CFM (1.90m³/min) | 1.990 in H2O (495.7 Pa) | Ball | 0.287 lb (130.18 g) | Tubeaxial | PWM Control, Speed Sensor (Tach) | 38.00mm | 60.0dB(A) | 18 W | CSA, TUV, UL | 13000 RPM | -4 ~ 158°F (-20 ~ 70°C) | 4 Wire Leads | - |
|
|
9RH0624P4J01FAN AXIAL 60X25MM 24VDC WIRE |
0 | - |
|
数据表 |
San Ace 60 | Box | Obsolete | 24VDC | Square - 60mm L x 60mm H | 37.1 CFM (1.04m³/min) | 0.622 in H2O (155.0 Pa) | Ball | 0.199 lb (90.26 g) | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 25.00mm | 44.0dB(A) | 5.76 W | CSA, TUV, UL | 7600 RPM | -4 ~ 140°F (-20 ~ 60°C) | 3 Wire Leads | - |
|
|
9WP0612P4G01FAN AXIAL 60X25MM 12VDC WIRE |
0 | - |
|
数据表 |
San Ace 60W | Box | Obsolete | 12VDC | Square - 60mm L x 60mm H | 27.5 CFM (0.770m³/min) | 0.351 in H2O (87.3 Pa) | Ball | 0.243 lb (110.22 g) | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 25.00mm | 39.0dB(A) | 2.52 W | CSA, TUV, UL | 5600 RPM | -4 ~ 140°F (-20 ~ 60°C) | 4 Wire Leads | IP68 - Dust Tight, Waterproof |
|
3159/ME80251V3-000U-G99FAN AXIAL 80X25MM VAPO 12VDC |
0 | - |
|
数据表 |
MagLev® ME | Bulk | Obsolete | 12VDC | Square - 80mm L x 80mm H | 33.0 CFM (0.924m³/min) | 0.110 in H2O (27.4 Pa) | Vapo-Bearing™ | 0.165 lb (74.84 g) | Tubeaxial, Case Fan | Auto Restart, Speed Sensor (Tach) | 25.00mm | 28.0dB(A) | 1.1 W | CE, CUR, TUV, UL | 2600 RPM | 14 ~ 158°F (-10 ~ 70°C) | LP4 Assembly | - |
|
CFM-8015BF-140-363-20FAN AXIAL 80X15.4MM 12VDC WIRE |
0 | - |
|
数据表 |
CFM-80BF | Box | Active | 12VDC | Square - 80mm L x 80mm H | 46.5 CFM (1.30m³/min) | 0.180 in H2O (44.8 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 15.40mm | 36.3dB(A) | 5.4 W | CE, cURus, TUV | 4000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
CFM-6010B-150-326-20DC AXIAL FAN, 60 MM SQUARE, 10 M |
0 | - |
|
数据表 |
CFM-60B | Box | Active | 12VDC | Square - 60mm L x 60mm H | 18.1 CFM (0.507m³/min) | 0.150 in H2O (37.3 Pa) | Ball | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 10.50mm | 33.8dB(A) | 2.76 W | CE, cURus, TUV | 5000 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
CFM-6025BF-235-274-20FAN AXIAL 60X25.4MM 24VDC WIRE |
0 | - |
|
数据表 |
CFM-60CF | Box | Active | 24VDC | Square - 60mm L x 60mm H | 16.8 CFM (0.470m³/min) | 0.110 in H2O (27.4 Pa) | omniCOOL™ Magnetic Sleeve | - | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 25.40mm | 27.5dB(A) | 1.44 W | CE, cURus, TUV | 3500 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
3610KL-04W-B19-D00FAN AXIAL 92X25MM 12VDC WIRE |
0 | - |
|
数据表 |
3610KL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 26.5 CFM (0.742m³/min) | 0.057 in H2O (14.2 Pa) | Ball | 0.209 lb (94.8 g) | Tubeaxial | Locked Rotor Sensor | 25.00mm | 25.0dB | 880 mW | CE, CSA, UL, VDE | 1750 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
3610KL-04W-B19-D50FAN AXIAL 92X25MM 12VDC WIRE |
0 | - |
|
数据表 |
3610KL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 26.5 CFM (0.742m³/min) | 0.057 in H2O (14.2 Pa) | Ball | 0.209 lb (94.8 g) | Tubeaxial | Speed Sensor (Tach) | 25.00mm | 25.0dB | 880 mW | CE, CSA, UL, VDE | 1750 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
3610KL-04W-B19-G00FAN AXIAL 92X25MM 12VDC WIRE |
0 | - |
|
数据表 |
3610KL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 26.5 CFM (0.742m³/min) | 0.057 in H2O (14.2 Pa) | Ball | 0.209 lb (94.8 g) | Tubeaxial | Locked Rotor Sensor | 25.00mm | 25.0dB | 880 mW | CE, CSA, UL, VDE | 1750 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
3610KL-04W-B19-G50FAN AXIAL 92X25MM 12VDC WIRE |
0 | - |
|
数据表 |
3610KL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 26.5 CFM (0.742m³/min) | 0.057 in H2O (14.2 Pa) | Ball | 0.209 lb (94.8 g) | Tubeaxial | Speed Sensor (Tach) | 25.00mm | 25.0dB | 880 mW | CE, CSA, UL, VDE | 1750 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
3610KL-04W-B29-D00FAN AXIAL 92X25MM 12VDC WIRE |
0 | - |
|
数据表 |
3610KL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 33.5 CFM (0.938m³/min) | 0.081 in H2O (20.1 Pa) | Ball | 0.209 lb (94.8 g) | Tubeaxial | Locked Rotor Sensor | 25.00mm | 29.5dB | 1.32 W | CE, CSA, UL, VDE | 2100 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
|
|
3610KL-04W-B29-D50FAN AXIAL 92X25MM 12VDC WIRE |
0 | - |
|
数据表 |
3610KL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 33.5 CFM (0.938m³/min) | 0.081 in H2O (20.1 Pa) | Ball | 0.209 lb (94.8 g) | Tubeaxial | Speed Sensor (Tach) | 25.00mm | 29.5dB | 1.32 W | CE, CSA, UL, VDE | 2100 RPM | 14 ~ 158°F (-10 ~ 70°C) | 3 Wire Leads | - |
