交流直流转换器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 功率(瓦特) | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输入 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 6 | 电流 - 输出 2 | 应用 | 电流 - 输出 5 | 电流 - 输出 3 | 电流 - 输出 4 | 电压 - 隔离 | 效率 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 | 认证机构 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
MVAD065-24AC/DC CONVERTER 24V 65W |
0 | - |
|
数据表 |
MVAD065 (65W) | Box | Obsolete | Open Frame | 1 | 24V | - | - | 65W | - | - | 90 ~ 264 VAC | - | 3 A | - | - | ITE (Commercial), Medical | - | - | - | 3 kV | -10°C ~ 70°C (With Derating) | DC Input Capable, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.30" H (101.6mm x 50.8mm x 33.1mm) | ||
|
|
MVAD065-48AC/DC CONVERTER 48V 65W |
0 | - |
|
数据表 |
MVAD065 (65W) | Box | Obsolete | Open Frame | 1 | 48V | - | - | 65W | - | - | 90 ~ 264 VAC | - | 840 mA | - | - | ITE (Commercial), Medical | - | - | - | 3 kV | -10°C ~ 70°C (With Derating) | DC Input Capable, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.30" H (101.6mm x 50.8mm x 33.1mm) | ||
|
MBC40-1005G-2AC/DC CONVERTER 5.1V 40W |
0 | - |
|
数据表 |
MBC40 (40W) | Box | Obsolete | Open Frame | 1 | 5.1V | - | - | 40W | - | - | 90 ~ 264 VAC | - | 8 A | - | - | Medical | - | - | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Standby Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC40-1015G-2AC/DC CONVERTER 15V 40W |
0 | - |
|
数据表 |
MBC40 (40W) | Box | Obsolete | Open Frame | 1 | 15V | - | - | 40W | - | - | 90 ~ 264 VAC | - | 2.7 A | - | - | Medical | - | - | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Standby Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC40-1048G-2AC/DC CONVERTER 48V 40W |
0 | - |
|
数据表 |
MBC40 (40W) | Box | Obsolete | Open Frame | 1 | 48V | - | - | 40W | - | - | 90 ~ 264 VAC | - | 830 mA | - | - | Medical | - | - | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Standby Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC40-3000G-2AC/DC CNVRTR 5.2V 12.5V -12.8V |
0 | - |
|
数据表 |
MBC40 (40W) | Box | Obsolete | Open Frame | 3 | 5.2V | 12.5V | -12.8V | 40W | - | - | 90 ~ 264 VAC | - | 6 A | - | 1 A | Medical | - | 500 mA | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Standby Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC40-3001G-2AC/DC CNVRTR 5.2V 24V -12.8V 40W |
0 | - |
|
数据表 |
MBC40 (40W) | Box | Obsolete | Open Frame | 3 | 5.2V | 24V | -12.8V | 40W | - | - | 90 ~ 264 VAC | - | 6 A | - | 1 A | Medical | - | 500 mA | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Standby Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC40-3002G-2AC/DC CNVRTR 5.2V 14.6V -14.8V |
0 | - |
|
数据表 |
MBC40 (40W) | Box | Obsolete | Open Frame | 3 | 5.2V | 14.6V | -14.8V | 40W | - | - | 90 ~ 264 VAC | - | 6 A | - | 1.5 A | Medical | - | 500 mA | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Standby Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC40-3003G-2AC/DC CONVERTER 3.3V 5.2V -12.8V |
0 | - |
|
数据表 |
MBC40 (40W) | Box | Obsolete | Open Frame | 3 | 3.3V | 5.2V | -12.8V | 40W | - | - | 90 ~ 264 VAC | - | 6 A | - | 3 A | Medical | - | 500 mA | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Standby Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC60-3003G-2AC/DC CONVERTER 3.3V 5.2V -12.8V |
0 | - |
|
数据表 |
MBC60 (60W) | Box | Obsolete | Open Frame | 3 | 3.3V | 5.2V | -12.8V | 60W | - | - | 90 ~ 264 VAC | - | 6 A | - | 3 A | Medical | - | 500 mA | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC60-1005G-2AC/DC CONVERTER 5.1V 60W |
0 | - |
|
数据表 |
MBC60 (60W) | Box | Obsolete | Open Frame | 1 | 5.1V | - | - | 60W | - | - | 90 ~ 264 VAC | - | 10 A | - | - | Medical | - | - | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC60-1015G-2AC/DC CONVERTER 15V 60W |
0 | - |
|
数据表 |
MBC60 (60W) | Box | Obsolete | Open Frame | 1 | 15V | - | - | 60W | - | - | 90 ~ 264 VAC | - | 4.33 A | - | - | Medical | - | - | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC60-1048G-2AC/DC CONVERTER 48V 60W |
0 | - |
|
数据表 |
MBC60 (60W) | Box | Obsolete | Open Frame | 1 | 48V | - | - | 60W | - | - | 90 ~ 264 VAC | - | 1.35 A | - | - | Medical | - | - | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC60-3000G-2AC/DC CNVRTR 5.2V 12.5V -12.8V |
0 | - |
|
数据表 |
MBC60 (60W) | Box | Obsolete | Open Frame | 3 | 5.2V | 12.5V | -12.8V | 60W | - | - | 90 ~ 264 VAC | - | 8 A | - | 3 A | Medical | - | 500 mA | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC60-3001G-2AC/DC CNVRTR 5.2V 24V -12.8V 60W |
0 | - |
|
数据表 |
MBC60 (60W) | Box | Obsolete | Open Frame | 3 | 5.2V | 24V | -12.8V | 60W | - | - | 90 ~ 264 VAC | - | 8 A | - | 1.5 A | Medical | - | 500 mA | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
MBC60-3002G-2AC/DC CNVRTR 5.2V 14.6V -14.8V |
0 | - |
|
数据表 |
MBC60 (60W) | Box | Obsolete | Open Frame | 3 | 5.2V | 14.6V | -14.8V | 60W | - | - | 90 ~ 264 VAC | - | 8 A | - | 2.5 A | Medical | - | 500 mA | - | 4.242 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.20" H (101.6mm x 50.8mm x 30.5mm) | ||
|
|
SWS100-3AC/DC CONVERTER 3.3V 100W |
0 | - |
|
数据表 |
SWS (100W) | Bulk | Obsolete | Enclosed | 1 | 3.3V | - | - | 100W | - | - | 85 ~ 265 VAC | - | 20 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -20°C ~ 74°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | 7.40" L x 3.78" W x 1.77" H (188.0mm x 96.0mm x 45.0mm) | ||
|
HWS100-12AC/DC CONVERTER 12V 100W |
0 | - |
|
数据表 |
HWS (100W) | Bulk | Obsolete | Open Frame | 1 | 12V | - | - | 100W | - | - | 85 ~ 265 VAC | - | 8.5 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Remote Sense, Universal Input | Chassis Mount | 6.30" L x 1.10" W x 3.23" H (160.0mm x 28.0mm x 82.0mm) | ||
|
HWS100-15AC/DC CONVERTER 15V 100W |
0 | - |
|
数据表 |
HWS (100W) | Bulk | Obsolete | Open Frame | 1 | 15V | - | - | 100W | - | - | 85 ~ 265 VAC | - | 7 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Remote Sense, Universal Input | Chassis Mount | 6.30" L x 1.10" W x 3.23" H (160.0mm x 28.0mm x 82.0mm) | ||
|
HWS100-24AC/DC CONVERTER 24V 100W |
0 | - |
|
数据表 |
HWS (100W) | Bulk | Obsolete | Open Frame | 1 | 24V | - | - | 100W | - | - | 85 ~ 265 VAC | - | 4.5 A | - | - | ITE (Commercial) | - | - | - | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Remote Sense, Universal Input | Chassis Mount | 6.30" L x 1.10" W x 3.23" H (160.0mm x 28.0mm x 82.0mm) |
