交流直流转换器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 功率（瓦特） | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输入 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 6 | 电流 - 输出 2 | 应用 | 电流 - 输出 5 | 电流 - 输出 3 | 电流 - 输出 4 | 电压 - 隔离 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AMEOF350-48SHAMJZ-BAC/DC CONVERTER 48V 200W aimtec |
0 | - |
|
数据表 |
AMEOF350-HAMJZ (200W ) | Box | Active | Open Frame | 1 | 48V | - | - | 200W (350W Forced Air) | - | - | 90 ~ 264 VAC, 127 ~ 373 VDC | - | 7.3 A | - | - | Household Appliances, ITE (Commercial), Medical | - | - | - | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.00" H (127.0mm x 76.2mm x 25.4mm) |
|
AMEL20-5S277HAVZ-STAC/DC CONVERTER 5V 20W aimtec |
0 | - |
|
数据表 |
AMEL20-277HAVZ (20W) | Obsolete | Enclosed | 1 | 5V | - | - | 20W | - | - | 85 ~ 305 VAC, 100 ~ 430 VDC | - | 4 A | - | - | Household Appliances, ITE (Commercial), Medical | - | - | - | 4 kV | -40°C ~ 85°C (With Derating) | DC Input Capable, Universal Input | Chassis Mount | 2.99" L x 1.24" W x 1.29" H (75.9mm x 31.5mm x 32.8mm) | |
|
AMESP320-24S277NZ-PAC/DC CONVERTER 24V 322W aimtec |
0 | - |
|
数据表 |
AMESP320-NZ (322W) | Box | Active | Enclosed | 1 | 20 ~ 26.4V | - | - | 321W | - | - | 90 ~ 305 VAC, 127 ~ 430 VDC | - | 13.4 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 3 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Universal Input | Chassis Mount | 8.46" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm) |
|
|
AMEOF350-27SHAMJZ-FAC/DC CONVERTER 27V 200W aimtec |
0 | - |
|
数据表 |
AMEOF350-HAMJZ (200W ) | Obsolete | Enclosed | 1 | 27V | - | - | 200W (351W Forced Air) | - | - | 90 ~ 264 VAC, 127 ~ 373 VDC | - | 13 A | - | - | Household Appliances, ITE (Commercial), Medical | - | - | - | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Universal Input | Chassis Mount | 5.12" L x 3.39" W x 1.38" H (130.0mm x 86.1mm x 35.1mm) | |
|
AMES15-12S277NZAC/DC CONVERTER 12V 16W aimtec |
0 | - |
|
数据表 |
AMES15-277NZ (16W) | Obsolete | Enclosed | 1 | 12V | - | - | 16W | - | - | 85 ~ 305 VAC, 100 ~ 430 VDC | - | 1.3 A | - | - | ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 2.56" L x 2.16" W x 0.98" H (65.0mm x 54.9mm x 24.9mm) | |
|
|
AMEOF350-24SHAMJZ-FAC/DC CONVERTER 24V 200W aimtec |
0 | - |
|
数据表 |
AMEOF350-HAMJZ (200W ) | Obsolete | Enclosed | 1 | 24V | - | - | 200W (350W Forced Air) | - | - | 90 ~ 264 VAC, 127 ~ 373 VDC | - | 14.6 A | - | - | Household Appliances, ITE (Commercial), Medical | - | - | - | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Universal Input | Chassis Mount | 5.12" L x 3.39" W x 1.38" H (130.0mm x 86.1mm x 35.1mm) | |
|
AMEL15-12S277HAVZ-STAC/DC CONVERTER 12V 15W aimtec |
0 | - |
|
数据表 |
AMEL15-277HAVZ (15W) | Obsolete | Enclosed | 1 | 12V | - | - | 15W | - | - | 85 ~ 305 VAC, 100 ~ 430 VDC | - | 1.25 A | - | - | Household Appliances, ITE (Commercial), Medical | - | - | - | 4 kV | -40°C ~ 85°C (With Derating) | DC Input Capable, Universal Input | Chassis Mount | 2.99" L x 1.24" W x 1.27" H (75.9mm x 31.5mm x 32.3mm) | |
|
AMEL10-12S277HAVZ-STAC/DC CONVERTER 12V 9.9W aimtec |
0 | - |
|
数据表 |
AMEL10-277HAVZ (10W) | Obsolete | Enclosed | 1 | 12V | - | - | 9.9W | - | - | 85 ~ 305 VAC, 100 ~ 430 VDC | - | 830 mA | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -40°C ~ 85°C (With Derating) | DC Input Capable, Universal Input | Chassis Mount | 2.99" L x 1.24" W x 1.17" H (75.9mm x 31.5mm x 29.7mm) | |
|
AMES100-1224DNZAC/DC CONVERTER 12V 24V 96W aimtec |
0 | - |
|
数据表 |
AMES100-NZ (96W) | Box | Active | Enclosed | 2 | 12V | 24V | - | 96W | - | - | 90 ~ 264 VAC, 120 ~ 373 VDC | - | 4 A | - | 2 A | Household Appliances | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 6.26" L x 3.82" W x 1.18" H (159.0mm x 97.0mm x 30.0mm) |
|
AMES75-24SNZ-PAC/DC CONVERTER 24V 77W aimtec |
0 | - |
|
数据表 |
AMES75-NZ | Box | Active | Enclosed | 1 | 21.6 ~ 28.8V | - | - | 76.8W | - | - | 90 ~ 305 VAC, 127 ~ 430 VDC | - | 3.2 A | - | - | Household Appliances, ITE (Commercial) | - | - | - | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 3.90" L x 3.82" W x 1.18" H (99.0mm x 97.0mm x 30.0mm) |
