固定电感器
| 图片 | 厂商料号 | 库存情况 | 价格 | 数量 | 数据表 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 供应商设备封装 | 屏蔽 | 直流电阻 (DCR) | 电感 | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 安装类型 | 额定值 | 尺寸 / 尺寸 | 特性 | 工作温度 | 电感频率 - 测试 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
18R105CFIXED IND 1MH 440MA 1 OHM TH Murata Power Solutions Inc. |
989 | - |
|
数据表 |
1800R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | ±10% | 440 mA | - | - | Unshielded | 1Ohm Max | 1 mH | 92 @ 50kHz | 1.82MHz | Through Hole | - | 0.539" Dia (13.70mm) | - | 0°C ~ 70°C | 1 kHz | 0.626" (15.90mm) |
|
19R107CFIXED IND 100MH 70MA 90 OHM TH Murata Power Solutions Inc. |
1,717 | - |
|
数据表 |
1900R | Radial, Vertical Cylinder | Box | Active | Wirewound | - | ±10% | 70 mA | - | - | Unshielded | 90Ohm Max | 100 mH | - | - | Through Hole | - | 0.472" Dia (12.00mm) | - | -40°C ~ 95°C | 1 kHz | 0.827" (21.00mm) |
|
60A363CFIXED IND 36UH 6.4A 20 MOHM SMD Murata Power Solutions Inc. |
276 | - |
|
数据表 |
6000A | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | ±10% | 6.4 A | 8.8A | - | Unshielded | 20mOhm Max | 36 µH | - | 11MHz | Surface Mount | - | 0.866" L x 0.748" W (22.00mm x 19.00mm) | - | -40°C ~ 85°C | 100 kHz | 0.472" (12.00mm) |
|
32331CFIXED IND 330UH 780MA 215MOHM TH Murata Power Solutions Inc. |
299 | - |
|
数据表 |
3200 | Radial, Vertical, 4 Leads (Open) | Tray | Active | Toroidal | - | ±15% | 780 mA | - | - | Unshielded | 215mOhm Max | 330 µH | 3.2 @ 800kHz | 2.3MHz | Through Hole | - | 0.846" L x 0.394" W (21.50mm x 10.00mm) | - | -40°C ~ 125°C | 800 kHz | 0.945" (24.00mm) |
|
83472CFIXED IND 4.7UH 1.1A 130MOHM SMD Murata Power Solutions Inc. |
4,690 | - |
|
数据表 |
8300 | Nonstandard | Tape & Reel (TR) | Active | Toroidal | - | ±20% | 1.1 A | 1.66A | - | Unshielded | 130mOhm Max | 4.7 µH | - | - | Surface Mount | - | 0.307" L x 0.205" W (7.80mm x 5.20mm) | - | -40°C ~ 85°C | - | 0.071" (1.80mm) |
|
60B154CFIXED IND 150UH 6A 38 MOHM SMD Murata Power Solutions Inc. |
285 | - |
|
数据表 |
6000B | Nonstandard | Tray | Active | Wirewound | - | ±15% | 6 A | - | - | Unshielded | 38mOhm Max | 150 µH | - | 3.9MHz | Surface Mount | - | 1.063" L x 0.768" W (27.00mm x 19.50mm) | - | -40°C ~ 85°C | 100 kHz | 0.787" (20.00mm) |
|
|
60B473CFIXED IND 47UH 10.5A 13 MOHM SMD Murata Power Solutions Inc. |
267 | - |
|
数据表 |
6000B | Nonstandard | Tray | Active | Wirewound | - | ±15% | 10.5 A | - | - | Unshielded | 13mOhm Max | 47 µH | - | 7.45MHz | Surface Mount | - | 1.063" L x 0.768" W (27.00mm x 19.50mm) | - | -40°C ~ 85°C | 100 kHz | 0.787" (20.00mm) |
|
1447385CFIXED IND 47UH 8.5A 21 MOHM TH Murata Power Solutions Inc. |
1,953 | - |
|
数据表 |
1400 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | ±15% | 8.5 A | - | - | Unshielded | 21mOhm Max | 47 µH | 33 @ 100kHz | 6.7MHz | Through Hole | - | 1.055" Dia (26.80mm) | - | -40°C ~ 85°C | 1 kHz | 0.610" (15.50mm) |
|
|
1447423CFIXED IND 470UH 2.3A 250 MOHM TH Murata Power Solutions Inc. |
651 | - |
|
数据表 |
1400 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | ±10% | 2.3 A | - | - | Unshielded | 250mOhm Max | 470 µH | 34 @ 50kHz | 2MHz | Through Hole | - | 1.012" Dia (25.70mm) | - | -40°C ~ 85°C | 1 kHz | 0.610" (15.50mm) |
|
|
1422435CFIXED IND 220UH 3.5A 96 MOHM TH Murata Power Solutions Inc. |
354 | - |
|
数据表 |
1400 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | ±10% | 3.5 A | - | - | Unshielded | 96mOhm Max | 220 µH | 22 @ 50kHz | 2.8MHz | Through Hole | - | 1.028" Dia (26.10mm) | - | -40°C ~ 85°C | 1 kHz | 0.610" (15.50mm) |
